Williams Sound PPA R19 Istruzioni per il montaggio
FRM 396B ©2005 Williams Sound Corp.
Williams Sound ®
Helping People Hear
Personal PA™Receiver, PPA R19
Instructions For Use & Care
SAFETY INFORMATION
Hearing Safety:
This product is designed to amplify
sounds to a high volume level which
could potentially cause hearing dam-
age if used improperly. To protect your
hearing and the hearing of others:
1. Make sure the volume is turned
down before putting on the ear-
phone or headphone before adjust-
ing the volume to a comfortable
level.
2. Set the volume level at the mini-
mum setting that you need to hear.
3. Do not allow children or other
unauthorized persons to have access
to this product.
BATTERY SAFETY & DISPOSAL
Do not attempt to recharge dispos-
able batteries, which may explode,
release dangerous chemicals, cause
burns, or other serious harm to the
user or product.
PACEMAKER SAFETY
1. Before using this product with a pace-
maker or other medical device, con-
sult your physician or the manufactur-
er of your pacemaker or other medical
device.
2. If you have a pacemaker or other med-
ical device, make sure that you are using
this product in accordance with safety
guidelines established by your physician
or the pacemaker manufacturer.
CAUTION! CAUTION!
CAUTION!
2
Williams Sound ®
Helping People Hear
RECYCLING INSTRUCTIONS
Help Williams Sound protect the environment! Please take the time to dispose of your
equipment properly.
Product Recycling:
Please do NOT dispose of your Williams Sound equipment in the household trash. Please
take the equipment to a electronics recycling center; OR, return the product to the factory
for proper disposal.
Battery Recycling:
Please do NOT dispose of used batteries in the household trash. Please take the batteries
to a retail or community collection point for recycling.
8/16/05
3
Williams Sound ®
Helping People Hear
7. To turn the receiver off, rotate
the Volume control knob until it
clicks off. The ON indicator
should not be lit. Turn the
receiver off when it is not in
use.
Earpad Cleaning
Do not immerse the earphone in
water or other cleaning agent. Foam
pads may be removed and washed
with a mild laundry soap solution,
rinsed thoroughly, and air-dried.
Foam pads may also be replaced
with new pads.
EAR Channel
12
Volume
Lo HiMid
2
Off Max
Tone
R19 Receiver Control Panel
OPERATING INSTRUCTIONS
1. Install the batteries.
2. Plug the earphone into the EAR
jack on the receiver’s control
panel.
3. Use the earphone in your best
ear.
4. Turn the receiver on by rotating
the Volume control knob. The
ON indicator should be lit.
5. Select the channel you’d like
by using the slide switch channel
selector on the control panel.
Standard channels are 33 (72.9
MHz) and 53 (75.7 MHz).
Make sure the receiver frequency
matches the transmitter
frequency.
6. Adjust for comfortable volume
and tone.
4
Williams Sound ®
Helping People Hear
BATTERIES
The PPA R19 Receiver can use two (2)
disposable AA batteries (BAT 001) or
two (2) AA rechargeable batteries
(BAT 026).
Caution: Do not attempt to recharge
disposable batteries. They may rupture,
causing injury. Do not open batteries or
dispose of batteries in fire.
Installation and Replacement
1. Open the battery compartment by
using a coin in the slot on the
receiver’s bottom.
2. Press the batteries into place,
observing proper polarity.
3. When the sound becomes weak or
distorted, replace the batteries.
Recharging
Rechargeable batteries must be charged
overnight before using them the first
time. The BAT 026 rechargeable batter-
ies can be charged with the CHG 200
Drop–in Charger. To recharge:
1. Plug the wall transformer into a
110 V wall outlet and the
CHG 200.
2. Place one or two R19 Receivers in
the CHG 200. Make sure the
receivers have been turned off.
3. Allow the receivers to charge for
approximately 14 hours.
It’s best to let the batteries fully dis-
charge before recharging. Fully
charged batteries will usually provide
50 hours of use per charge and can be
recharged approximately 300–500
times.
Note: The BAT 026 provides longer
life than other rechargeables. Do not
substitute other rechargeable batteries
and chargers.
Additional Frequencies
The R19 Receiver operates on fixed
crystals and tuning for the R19 receiver
is highly stable over the life of the
receiver.
If alternate frequencies are necessary,
return the receivers to your dealer for
new crystals. There are 10 standard
frequencies available.
5
Williams Sound ®
Helping People Hear
LIMITED WARRANTY
Williams Sound products are engineered,
designed and manufactured under careful-
ly controlled conditions to provide you
with many years of reliable service.
Williams Sound warrants the PPA R19
receiver against defects in materials and
workmanship for FIVE (5) years. During
the first five years from the purchase date,
we will promptly repair or replace the
PPA R19 receiver.
Earphones, headphones, batteries, cables,
carry cases, and all other accessory prod-
ucts carry a 90-day warranty.
WILLIAMS SOUND HAS NO CON-
TROL OVER THE CONDITIONS
UNDER WHICH THIS PRODUCT IS
USED. WILLIAMS SOUND, THERE
WHETHER A CLAIM FOR SUCH
DAMAGES IS BASED UPON WAR-
RANTY, CONTRACT, TORT OR OTH-
ERWISE. THE SOLE REMEDY FOR
ANY DEFECT, FAILURE OR MAL-
FUNCTION OF THE PRODUCT IS
REPLACEMENT OF THE PRODUCT.
NO PERSON HAS ANY AUTHORITY
TO BIND WILLIAMS SOUND TO ANY
REPRESENTATION OR WARRANTY
WITH RESPECT TO THE PPA R19
RECEIVER. UNAUTHORIZED
REPAIRS OR MODIFICATIONS WILL
VOID THE WARRANTY.
The exclusions and limitations set out
above are not intended to, and should not
be construed so as to contravene mandato-
ry provisions of applicable law. If any
part or term of this Disclaimer of
Warranty is held to be illegal, unenforce-
able or in conflict with applicable law by
a court of competent jurisdiction, the
validity of the remaining portions of this
Disclaimer of Warranty shall not be
affected, and all rights and obligations
shall be construed and enforced as if this
Limited Warranty did not contain the par-
ticular part or term held to be invalid.
FRM 396B ©2005, Williams Sound Corp.
Williams Sound Corp.
10321 West 70th St., Eden Prairie, MN 55344
U.S.A. 800-843-3544 / 952-943-2252 / FAX: 952-943-2174
If you experience difficulty with your system, call Toll-Free for Customer Assistance:
1-800-843-3544
If it is necessary to return the system for service, your Customer Service Representative will
give you a Return Authorization Number (RA) and shipping instructions.
Pack the system carefully and send it to:
Williams Sound Corp.
Attn: Repair Dept.
10321 West 70th Street
Eden Prairie, MN 55344
