Williams Sound ®

Helping People Hear

WIR RX295 Receiver: 95 kHz, 250 kHz, Stereo

Instructions For Use & Care

SAFETY INFORMATION

Hearing Safety:

This product is designed to amplify

sounds to a high volume level which

could potentially cause hearing dam-

age if used improperly. To protect your

hearing and the hearing of others:

1. Make sure the volume is turned

down before putting on the ear-

phone or headphone before adjust-

ing the volume to a comfortable

level.

2. Set the volume level at the mini-

mum setting that you need to hear.

3. Do not allow children or other

unauthorized persons to have access

to this product.

BATTERY SAFETY & DISPOSAL

Do not attempt to recharge dispos-

able batteries, which may explode,

release dangerous chemicals, cause

burns, or other serious harm to the

user or product.

PACEMAKER SAFETY

1. Beforeusing this product with a pace-

maker or other medical device, con-

sult your physician or the manufactur-

er of your pacemaker or other medical

device.

2. If you have a pacemaker or other med-

ical device, make sure that you are using

this product in accordance with safety

guidelines established by your physician

or the pacemaker manufacturer.

CAUTION!

Williams Sound ®

Helping People Hear

RECYCLING INSTRUCTIONS

Help Williams Sound protect the environment! Please take the time to dispose of your

equipment properly.

Product Recycling:

Please do NOT dispose of your Williams Sound equipment in the household trash. Please

take the equipment to a electronics recycling center; OR, return the product to the factory

for proper disposal.

Battery Recycling:

Please do NOT dispose of used batteries in the household trash. Please take the batteries

to a retail or community collection point for recycling.

8/23/05

Williams Sound ®

Helping People Hear

Before you begin using the RX295 receiver, make sure the IR transmitter being used is

transmitting on 95 kHz or 250 kHz frequencies. Make sure the audio source is on, and the

receiver battery is fully charged (charging time 14 hours).

The RX295 Receiver has an automatic on/off function. When you put the receiver on, it turns

on. When you take the receiver off, it turns off. Use the 3-position selection switch to choose

from 95 kHz, stereo, or 250 kHz mode. Rotate the Volume Control to adjust the volume to a

comfortable listening level.

A dual detector infrared “eye” is located in the front of the receiver. Do not cover it up or

you will lose reception. Make sure the “SOUND PLUS” label is facing away from you

when you put the receiver on.

The RX295 Receiver should be charged when not in use.

Optional chargers: Single unit receiver charger, model CHG 950. Multi-battery (BAT

AP97A) 21 unit charger, model CHG 2100.

Sound Plus

BAT AP97A

Rechargeable NiMH Battery

Volume Control Knob

Frequency Selection

Switch: 95 kHz,

Stereo, 250 kHz

Front View

OPERATING INSTRUCTIONS

Williams Sound ®

Helping People Hear

Balance Control: Use a small screwdriver to adjust the loudness balance between the Left

and Right earphones.

Tone Control: Use a small screwdriver to adjust the tone between the Left and Right

earphone. Turn the screwdriver clockwise to lower the pitch, counterclockwise to increase

the pitch.

Ear Cushions: Replacement ear cushions are available from your Williams Sound dealer,

Part number EAR 031.

Specifications:

Weight: 2.1 oz (60 g) with batteries

Material and Color: ABS plastic, Black and Grey

Battery Type, Life: BAT AP97A NiMH Battery Pack, 6 hours

Modulation Frequency: 95 kHz or stereo or 250 kHz

Frequency Response: 200 Hz to 8 kHz, ± 5 dB

Signal to Noise Ratio: 60 dB at 10 m

Controls: Volume control thumbwheel; 3-position

selection switch (95 kHz, stereo, 250 kHz);

Screwdriver adjust balance control

Acoustic Output: 112 dB MAX SSPL90 with 2 cc coupler

Compatibility: Compatible with 95 kHz and 250 kHz IR

transmitters: WIR TX95, WIR TX800,

WIR TX850, WIR TX10

Power Switch: Built into receiver “arms”

On Indicator: Green LED

Ear pads: Uses EAR 031 foam cushions

Warranty: 5 years (1 year on battery)

Approvals: CE

BAL

–

Tone Controls Balance Control

Rear View

Williams Sound ®

Helping People Hear

LIMITED WARRANTY

Williams Sound products are engineered,

designed and manufactured under careful-

ly controlled conditions to provide you

with many years of reliable service.

Williams Sound warrants the WIR RX295

Receiver against defects in materials and

workmanship for FIVE (5) years. During

the first five years from the purchase date,

we will promptly repair or replace the

WIR RX295 Receiver.

Earphones, headphones, batteries, cables,

carry cases, and all other accessory prod-

ucts carry a 90-day warranty.

WILLIAMS SOUND HAS NO CON-

TROL OVER THE CONDITIONS

UNDER WHICH THIS PRODUCT IS

USED. WILLIAMS SOUND, THERE-

FORE, DISCLAIMS ALL WARRANTIES

NOT SET FORTH ABOVE, BOTH

EXPRESS AND IMPLIED, WITH

RESPECT TO THE WIR RX295

RECEIVER, INCLUDING BUT NOT

LIMITED TO, ANY IMPLIED WAR-

RANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PUR-

POSE. WILLIAMS SOUND SHALL

NOT BE LIABLE TO ANY PERSON OR

ENTITY FOR ANY MEDICAL

EXPENSES OR ANY DIRECT, INCI-

DENTAL OR CONSEQUENTIAL DAM-

AGES CAUSED BY ANY USE,

DEFECT,

FAILURE OR MALFUNCTION OF THE

PRODUCT, WHETHER A CLAIM FOR

SUCHDAMAGES IS BASED UPON

WARRANTY, CONTRACT, TORT OR

OTHERWISE. THE SOLE REMEDY

FOR ANY DEFECT, FAILURE OR MAL-

FUNCTION OF THE PRODUCT IS

REPLACEMENT OF THE PRODUCT.

NO PERSON HAS ANY AUTHORITY

TO BIND WILLIAMS SOUND TO ANY

REPRESENTATION OR WARRANTY

WITH RESPECT TO THE WIR RX295

RECEIVER. UNAUTHORIZED

REPAIRS OR MODIFICATIONS WILL

VOID THE WARRANTY.

The exclusions and limitations set out

above are not intended to, and should not

be construed so as to contravene mandatory

provisions of applicable law. If any part or

term of this Disclaimer of Warranty is held

to be illegal, unenforceable or in conflict

with applicable law by a court of compe-

tent jurisdiction, the validity of the remain-

ing portions of this Disclaimer of Warranty

shall not be affected, and all rights and

obligations shall be construed and enforced

as if this Limited Warranty did not contain

the particular part or term held to be

invalid.

Williams Sound Corp.

10321 West 70th St., Eden Prairie, MN 55344

U.S.A. 800-843-3544 / 952-943-2252 / FAX: 952-943-2174

If you experience difficulty with your system, call Toll-Free for Customer Assistance:

1-800-843-3544

If it is necessary to return the system for service, your Customer Service Representative

will give you a Return Authorization Number (RA) and shipping instructions.

Pack the system carefully and send it to:

Williams Sound Corp.

Attn: Repair Dept.

10321 West 70th Street

Eden Prairie, MN 55344
