DSP100-05
Product information
DSP100-05_V1.1_PI_2021-01_EN Subject to technical changes Page 1 of 2
Front view
Remote display for cold locations, display height 14mm
Features
Display of representative wares temperature of the associated field module
Status displays for cooling, defrosting and fan
Snap-in installation in refrigeration units
Connection to field module by 0.5m cable with prefabricated plug
Writing conventions
WARNING
Avoid the described hazard: otherwise there is danger from electric voltage
that could lead to death or serious physical injury.
For your safety
For safe operation and to avoid personal injury and equipment damage through operator error, always
read these instructions, become familiar with the device, and follow all safety instructions on the
product and in this document, as well as the safety guidelines of Wurm GmbH & Co. KG Elektronische
Systeme. Keep these instructions ready to hand for quick reference and pass them on with the device
if the product is sold.
Wurm GmbH & Co. KG Elektronische Systeme accepts no liability in case of improper use or use for
other than the intended purpose.
These instructions are intended for "service technicians".
The DSP100-05 is a remote display for cold locations.
WARNING
Danger to life from electric shock and/or fire!
Connection of the device should be carried out only by a qualified electrician.
Use only the correct tools for all work.
Never expose the device to moisture, for example due to condensation or cleaning
agents.
Take the device out of operation if it is faulty or damaged and is therefore compromising
safe operation.
Do not open the device.
Do not repair the device yourself. If the device requires repairs, send it in with an exact
description of the fault.
