Xante Accel-a-Writer 812 Manuale utente
__________________________________________ Installation 2-1
Chapter 2 - Installation
Chapter Overview
Printer Location
Package Contents
Printer Setup
Unpacking the Printer
Installing Options
Installing the Toner Cartridge
Loading the Paper Cassette
Loading the Fold Down Tray
Connecting the Power Cord
Starting the Printer
Printing the Start-up Page
Selecting an Interface
Connecting in a Macintosh Environment
Connecting in a PC Environment
Connecting to Ethernet
Connecting a Hard Disk
2-2 Installationbb_________________________________________
Notes
__________________________________________ Installation 2-3
Introduction
This chapter covers setting up your new Accel-a-Writer 812 printer.
It includes finding the right location, unpacking the printer, installing
toner and paper, connecting the power cord, printing a start-up page,
and selecting an interface.
Printer Location
Before unpacking your Accel-a-Writer 812, you need to choose a
good location. This area should meet the following guidelines:
• Be on a level, sturdy surface capable of supporting 43 lbs
(19.4 kg) with the toner and main cassette or 56 lbs (25.4
kg) with the addition of the optional lower cassette
• Have an area of approximately 24" x 50" (624 mm x 1292
mm) so there is sufficient clearance for operation and
maintenance
• Maintain a temperature of 50˚ to 90.5˚ Fahrenheit (10˚ to
32.5˚ Celsius) without rapid changes
• Maintain a relative humidity between 20% and 80%
• Be away from direct sunlight, open flames, refrigerators,
water faucets, humidifiers, heaters, or similar equipment
• Be away from strong vibrations or electromagnetic fields
• Maintain proper host-printer distance for communication:
within 10 feet (3 m) for parallel; within 25 feet (7.5 m) for
serial; within 1000 feet for LocalTalk
• Be close to a grounded electrical outlet with the proper
voltage
• Be on a separate outlet without appliances and office
machines such as air conditioners, copiers, and shredders
which can produce noise on the line
2-4 Installationbb_________________________________________
Note: Do not use ammonia-based cleaners on or around the
printer as they react chemically with the toner. Also,
like most laser printers and photocopiers, this one
produces a small amount of ozone, so choose a well
ventilated area.
Package Contents
Your printer package normally consists of two, separately shipped
boxes. The larger box, which you have opened already, contains the
following items:
• Accel-a-Writer 812 printer
• 250 sheet letter or A4 paper cassette
• Power cord
•Accel-a-Writer 812 User’s Guide (this manual)
• XANTÉ Utilities, PSPrinter driver, and other software
The smaller box contains:
• Toner cartridge for the Accel-a-Writer 812
Optional items from the following list ship separately.
• Additional paper cassettes
• 500 sheet cassette feeder
Note: If you order optional RAM, Ethernet, or resolution
upgrades when you order the printer, they will be
installed before the printer ships.
If you do not receive your full shipment or if anything is damaged,
immediately contact XANTÉ Customer Support at 800-926-8393
in the US and Canada, at 95-800-926-8393 in Mexico, or at
334-342-4846 elsewhere.
__________________________________________ Installation 2-5
Printer Setup
Printer setup covers
• Unpacking the printer
• Installing optional equipment
• Installing the toner cartridge
• Loading the paper cassette
• Loading the fold down tray
• Connecting the power cord
• Starting the printer
Before you begin this setup, take a few minutes to familiarize
yourself with the printer. The following illustrations, figures 2.1 and
2.2, provide an overview of the front and back of your printer.
ONLINE FORM FEED TRAYSELECT
ENTER MENU
RESET TEST
DATA MANUAL READY
Top Cover
Output Tray Air VentAir Vent
Power
Switch
250 Sheet
Cassette
Multi-Purpose
Tray
Front Panel
Fig. 2.1 Front View of the Printer
2-6 Installationbb_________________________________________
Rear Cover
Latch
Power Receptacle
Rear Cover
Interface Ports
Fig. 2.2 Rear View of the Printer
Unpacking the Printer
Various packing materials protect your printer during shipping.
These materials include plastic, tape, polystyrene, cardboard, and
shipping spacers—all of which must be removed. You may want to
save these materials in case you ever have to move or ship the
printer.
1. Remove everything except the printer in its protective
bag from the shipping box.
__________________________________________ Installation 2-7
Warning! The printer weighs approximately 37 lbs (16.8 kg)
without the toner, cassettes, and media installed. Have
someone help you lift it.
2. Lift the printer out of the box.
3. Remove the plastic wrap from around the printer.
4. Remove the tape securing the rear cover, the fold down tray,
and the cassette.
5. Pull the paper cassette straight out from the printer (fig. 2.3).
Fig. 2.3 Remove the Cassette from the Printer
2-8 Installationbb_________________________________________
6. Remove the packing tape and cardboard.
7. Push down on the plate in the bottom of the cassette and
remove the plastic packing spacers (fig. 2.4). Then place the
cassette back into the printer for now.
Fig. 2.4 Remove the Cassette Spacers
__________________________________________ Installation 2-9
8. Press the raised finger grips on each side of the top cover (fig.
2.5) and lift up and back approximately 180°to open it.
ONLINE FORM FEED TRAY SELECT
ENTER MENU
RESET TEST
DATA MANUAL READY
Fig. 2.5 Open the Top Cover
9. Remove the packing tape and cardboard from inside the top of
the printer (fig. 2.6).
Fig. 2.6 Remove the Tape and Cardboard inside the Top
2-10 Installationbb_________________________________________
10. Open the rear cover by pressing the release lever and tilting the
cover out and down (fig. 2.7).
Fig. 2.7 Open the Rear Cover
