__________________________________________ Installation 2-1
Chapter 2 - Installation
Chapter Overview
Printer Location
Package Contents
Printer Setup
Unpacking the Printer
Installing Options
Installing the Toner Cartridge
Loading the Paper Cassette
Loading the Fold Down Tray
Connecting the Power Cord
Starting the Printer
Printing the Start-up Page
Selecting an Interface
Connecting in a Macintosh Environment
Connecting in a PC Environment
Connecting to Ethernet
Connecting a Hard Disk
2-2 Installationbb_________________________________________
Notes
__________________________________________ Installation 2-3
Introduction
This chapter covers setting up your new Accel-a-Writer 8200 printer.
It includes finding the right location, unpacking the printer, installing
toner and paper, connecting the power cord, printing a start-up page,
and connecting to an interface.
Printer Location
Before unpacking your Accel-a-Writer 8200, you need to choose a
good location. This area should meet the following guidelines:
• Be on a level, sturdy surface capable of supporting 60 lbs
(27.24 kg)
• Have an area of approximately 25" x 49" (644 mm x
1250 mm) so there is sufficient clearance for operation
and maintenance
• Maintain a temperature of 50˚ to 90.5˚ Fahrenheit (10˚ to
32.5˚ Celsius) without rapid changes
• Maintain a relative humidity between 20% and 80%
• Be away from direct sunlight, open flames, refrigerators,
water faucets, humidifiers, heaters, or similar equipment
• Be away from strong vibrations or electromagnetic fields
• Maintain proper host-printer distance for communication:
within 10 feet (3 m) for parallel; within 25 feet (7.5 m) for
serial; within 1000 feet (305 m) for LocalTalk
• Be close to a grounded electrical outlet with the proper
voltage
Note: Do not use ammonia-based cleaners on or around the
printer; they react chemically with the toner. Also, like most
laser printers and photocopiers, this one produces a small
amount of ozone, so choose a well ventilated area.
2-4 Installationbb_________________________________________
Package Contents
Your printer package, which you have opened already, contains the
following items:
• Accel-a-Writer 8200 printer
• 250 sheet letter or A4 paper cassette
• 250 sheet ledger (11" x 17") or A3 paper cassette
• Cassette cover
• Power cord
•Accel-a-Writer 8200 User’s Guide (this manual)
• XANTÉ Utilities, PSPrinter driver, and other software disks
• Toner cartridge for the Accel-a-Writer 8200 (EP-BII)*
* If you purchased the printer with the extra wide print option,
the printer ships with the EP-BIIX extra wide toner cartridge.
Optional items from the following list ship separately.
• Additional 250 sheet paper cassettes
• Paper feeder
• Cassette supporter
• 500 sheet letter/A4 paper cassette
Note: If you order optional RAM, Ethernet, or resolution
upgrades when you order your printer, they will be
installed before the printer ships.
If you do not receive your full shipment or if anything is damaged,
immediately contact XANTÉ Customer Support at 800-926-8393 in
the US and Canada, at 95-800-926-8393 Mexico or at
(334) 342-4846 elsewhere.
__________________________________________ Installation 2-5
Printer Setup
Printer setup includes
• Unpacking the printer
• Installing optional equipment
• Installing the toner cartridge
• Loading the paper cassette
• Loading the fold down tray
• Connecting the power cord
• Starting the printer
Before you begin this setup, take a few minutes to look over figures
2.1 and 2.2 to familiarize yourself with the printer.
MANUAL
READY
ON LINE FORM
FEED RESET TEST ENTER MENU TRAY
SELECT
®
Paper
Stop Front
Panel Front Cover
Fuser
Cover
Release
Latch
Ledger
Extender
Tray
Extender
Fold Down Tray Paper Guides
Paper Cassette Slot
Output
Tray
Fig. 2.1 Front View of the Printer
2-6 Installationbb_________________________________________
Output Tray Interface Ports
Power
Switch
Power
Receptacle
Feeder Tray
Connector Cover
Cassette Cover
Fig. 2.2 Rear View of the Printer
Unpacking the Printer
Various packing materials protect your printer during shipping. These
materials include plastic, tape, polystyrene, cardboard, and shipping
spacers—all of which must be removed. You may want to save these
materials in case you ever have to move or ship the printer.
1. Remove everything except the printer in its protective bag
from the shipping box.
Warning! The printer weighs approximately 51 lbs (23 kg)
without the toner, cassettes, and media installed. Have
someone help you lift it.
2. Lift the printer out of the box.
3. Remove the plastic wrap from around the printer.
__________________________________________ Installation 2-7
4. Remove the three pieces of tape securing the fold down tray.
The tape is located at the top and on each side of the tray.
5. Open the fold down tray by grasping the top corners and
pulling out and down (fig. 2.3).
FORM
FEED
ON LINE
MANUAL
READY
READY/IDLE
ACTIVE RE
Fig. 2.3 Open the Fold Down Tray
6. Locate the shipping cardboard in the lower right corner of the
front cover. Then, pull it straight out to remove it (fig. 2.4).
FORM
FEED
ON LINE RESET TEST ENTER
MANUAL
READY
TRAY
SELECT
Innovations In Output
MENU
READY/IDLE
ACTIVE
®
Fig. 2.4 Remove the Shipping Cardboard
2-8 Installationbb_________________________________________
7. Open the front cover by lifting the release latch and tilting the
cover towards you (fig. 2.5).
FORM
FEED
ON LINE
MANUAL
READY
PRINTER OPEN
ACTIVE RE
Fig. 2.5 Open the Front Cover
__________________________________________ Installation 2-9
8. Remove the two orange shipping spacers by pulling them up
and back in the direction of the arrows (fig. 2.6).
Remove
this spacer
Enlever
cette cale.
•
•
Remove
this spacer
Enlever
cette cale.
•
•
Remove
this spacer
Enlever
cette cale.
•
•
Shipping
Spacers
MANUAL
READY
ON LINE FORM
FEED RESET TEST ENTER MENU TRAY
SELECT
®
Fig. 2.6 Remove the Two Shipping Spacers
If you did not purchase the optional paper feeder or the 500 sheet
letter/A4 paper cassette with the cassette supporter, skip to
“Installing the Toner Cartridge.”
Installing Options
If you have an optional paper feeder or the 500 sheet letter/A4 paper
cassette with the cassette supporter, unpack the option(s) now.
Follow the installation instructions included with the option(s). See
“Tray Chaining” in chapter 6 for details on using optional trays.
2-10 Installationbb_________________________________________
Installing the Toner Cartridge
Caution: The toner cartridge is sensitive to bright lights and direct
sunlight. Leave it in its protective bag until you are ready to
load it into the printer. The cartridge contains a magnet, so
keep it away from your hard disk(s) and monitor to prevent
possible data loss or equipment damage.
The standard Accel-a-Writer 8200 ships with an EP-BII toner
cartridge. If you purchased the extra wide print option with your
printer, it ships with the EP-BIIX extra wide cartridge. Both
cartridges load in the same manner.
Use the following procedure to install the toner cartridge.
1. If the fold down tray is closed, open it by grasping the top
corners and pulling out and down (fig. 2.3).
2. If the front cover is closed, open it by lifting the release latch
and tilting the cover towards you (fig. 2.5).
3. Remove the toner cartridge from its package and gently rock it
back and forth to distribute the toner evenly throughout the
cartridge (fig. 2.7).
Fig. 2.7 Distribute the Toner
