Xiaomi Mi Band 5 Manuale utente
Mi Smart Band 5
User Manual
Read this manual carefully before use, and retain it for
future reference.
Product Overview
Wristband Charging Cable
Fitness Tracker
Touchscreen
Touch Button
Heart Rate Sensor
Charging Port
Installation
1.
2.
Insert one end of the fitness tracker into the slot from
the front of the wristband.
Press down on the other end with your thumb to push
the fitness tracker completely into the slot.
Wearing
1.Comfortably tighten the band around your wrist, about 1
finger width away from your wrist bone.
2.To achieve the optimal performance of the heart rate
sensor, make sure its back to contact with your skin.
When wearing your wristband, keep it neither too tight
nor too loose but leaving some space for the skin to
be able to breathe. Tighten the wristband before you
start to exercise and properly loosen it afterward.
Too loose Just right
If the band can easily
move up and down the
wrist, or the heart rate
sensor cannot collect the
data, try tightening the
wristband.
The band can
comfortably fit around the
wrist.
Connecting
1
.
Scan the QR code to download and install the latest
version of the Mi Fit app, or search for it in Google Play,
App Store, or other third-party app stores.
Mi Fit app QR code
（Android 5.0 & iOS 10.0 or above）
Mi Fit
The band did not receive a pairing request
Confirm the pairing on your band
Allowtopair
Allow to pair
2.Log into your Mi account in the Mi Fit app, and follow
the instructions to connect and pair the band with
your phone. Once the band vibrates and a pairing
request is displayed on its screen, tap the touch
button to complete the pairing with your phone.
Note: Make sure the Bluetooth on your phone is
enabled. Hold the phone and the band close to each
other during pairing.
Usage
After successfully pairing with your device, the band
will start tracking and analyzing your daily activities
and sleeping habits.
Touch the button to light up the screen. Swipe up or
down to view various functions such as exercise data,
and heart rate measurements. Swipe right to return to
the previous page.
Swipe up/down to
switch between
functions
Swipe right to return to
the previous page
Disassembly
Remove the band from your wrist, hold on to each
end and pull on the wristband until you see a small
gap between the fitness tracker and the wristband.
Use your finger to pop the fitness tracker out of its
slot from the front side of the wristband.
Charging
Recharge your band immediately when the battery
level is low.
