Yada BT58190 Manuale utente

DUAL-1080PROADCAM

User Manual

Important, retain for future reference:

Read carefully

BT58190

QUICK INSTALLATION GUIDE

1. Mount the Roadcam

Before you begin... Gather these items.

3 4

Mount the Roadcam

on the windshield.

3. Connect to Power

2. Insert the MicroSD Card

Please read all of the installation instructions carefully before installing

the product. Improper installation will void manufacturer’s warranty. The

installation instructions do not apply to all types of vehicles, and are

written as guidelines to assist in installing the system.

Consult an experienced technician if you are not comfortable installing

the product. You can also contact YADA at 1.866.294.9244 to speak

to one of our installation specialists if you have any specific questions

regarding the Dual-1080P Roadcam.

BEFORE using the Dual-1080P Roadcam, please read the safety

information provided in this user manual. ALWAYS use the

product as outlined in this user manual.

Please make sure to read and understand all local laws and regulations

regarding cameras and their use in a vehicle. Laws vary by state.

INTRODUCTION

PACKAGE CONTENTS

1. 1 x Dual-1080P Roadcam

2. 1 x Windshield Mount

3. 1 x 12V/24V Power Adapter

4. 1 x 16GB MicroSD Card

1 2

3 4

PRODUCT SPECIFICATIONS

Display: 1.5 inch display

Front and Rear Lenses:

120 degrees diagonal

Video Resolution: 1080P / 25 FPS

Circular Video: Seamless loop recording

Memory Card: MicroSD (maximum support 32GB)

Microphone: Supported

Built-in Audio: Supported

Operating Temperature: 14°F~140°F (-10°C~60°C)

Operating Voltage: Cigarette Charger - DC 12/24V / DC 5V (Mini-USB)

Battery: Built-in 300 mAh li-ion battery

PRODUCT OVERVIEW

Rear Camera Lens LCD Screen

Mount Socket

Speaker

LED Indicator

Speaker

Front Camera Lens

Mini-USB Power Port

Infrared LEDs

CAMERA CONTROLS

CAMERA DIMENSIONS

Power / OK Button

Menu / Mode Button

1.46” / 37mm 3.98” / 101mm

1.86” /

47mm

Down Navigation Button

Power Reset Hole

Microphone

MicroSD Card Slot

Up Navigation Button

Peel off the

protective sticker

from the LCD screen.

1. 2.

INSTALLATION

Insert the

windshield

mount to the

socket on the top

of the Roadcam.

Plug the Mini-USB

power cable into the

DC input port.

Note: Power on and test camera before mounting.

INSTALLATION

Mount the Roadcam on the windshield. You can turn on

the Roadcam and check the live screen to determine the

most suitable mounting position.

Warning: Do not install the product in a location where it

can obstruct the driver’s field of vision.

Recommended mounting position

Adjust the rear camera

lens angle to get the

best interior view.
