AURA®handheld NIR

User Manual

2AURA handheld NIR – 2289-971 and 2298-955 | User Manual

AURA handheld NIR

Users must be familiar with this manual to operate the device. Therefore,

please familiarize yourself with the contents. In particular, make sure to

follow the instructions explaining how to handle the device safely. The

device has a built-in WiFi adapter and therefore it is a Radio Equipment /

Combined Equipment according to the Radio Equipment Directive

2014/53/EU.

communication of its contents are prohibited, unless explicit permission

has been granted. Violations of this copyright notice will result in claims

for damages. All rights are reserved in case a patent is granted or a sample

is registered.

Carl Zeiss Spectroscopy GmbH

Carl-Zeiss-Promenade 10

07745 Jena, Germany

Service + 49 3641 64-3200

E-Mail [email protected]

Info + 49 3641 64-2838

Fax + 49 3641 64-2485

Internet www.zeiss.com/spectroscopy

Publication number: EN_40_070_0004I

UM AURA®handheld NIR – 2289-971 and 2289-955 / E | 2020-03

1st edition March 2020 Subject to technical changes

User Manual | AURA handheld NIR – 2289-971 and 2298-955

AURA handheld NIR

Content

1 Safety instructions��5

1.1 Used symbols and signal words 6

1.2 General safety instructions 7

1.3 Environmental management 8

1.4 Storage and transport 9

1.5 WiFi 10

2 Basic information��12

2.1 General information 12

2.2 Intended use 13

2.3 Warranty and liability 13

2.4 Connection and environmental parameters 14

3 System overview��15

3.1 AURA handheld NIR with standard handle 15

3.1.1 Functional elements 15

3.1.2 Controls and indicators 16

3.1.3 Interfaces 17

3.1.4 Dimensions 18

3.2 AURA handheld NIR with slanted handle 19

3.2.1 Functional elements 19

3.2.2 Controls and indicators 20

3.2.3 Interfaces 21

3.2.4 Dimensions 22

4 Technical description ��23

4.1 Function description 23

4.2 Speciﬁcations 24

4.3 ZEISS InProcess software 26

4.4 WiFi settings 27

5 Application note ��29

4AURA handheld NIR – 2289-971 and 2298-955 | User Manual

AURA handheld NIR

List of ﬁgures

Fig. 1 Functional elements ...........................................................15

Fig. 2 Controls and indicators .......................................................16

Fig. 3 Interfaces ............................................................................17

Fig. 4 Dimensions .........................................................................18

Fig. 5 Functional elements ............................................................19

Fig. 6 Controls and indicators .......................................................20

Fig. 7 Interfaces ............................................................................21

Fig. 8 Dimensions .........................................................................22

Fig. 9 InProcess software – welcome screen..................................27

Fig. 10 WiFi setting – connect to network.....................................27

Fig. 11 WiFi setting – create access point......................................28

Fig. 12 Exchanging the battery pack .............................................37

6 Operation ��33

6.1 Getting started 33

6.2 Start measurement 34

6.3 Export data 35

6.4 Shutting down 35

6.5 Exchanging battery pack 36

6.6 Charging the battery pack 38

7 Cleaning and accessories ��39

7.1 Cleaning the sensor 39

7.2 Accessories 39

8 Appendix��40

8.1 Technical Data Sheet

RRC-SMB-UBC Standard Battery Charger 41

8.2 Instruction Manual Battery Pack RRC 2054 45

8.3 Instruction Manual Battery Pack RRC 2040-02 49

8.4 Safety Data Sheet RRC Batteries 53

8.5 Data sheet WiFi adapter LM808 68

8.6 EU Declaration of Conformity (RED) LM808 70

User Manual | AURA handheld NIR – 2289-971 and 2298-955

Safety instructions

AURA handheld NIR

1 Safety instructions

The AURA handheld NIR has been designed and tested in compliance

with the Radio Equipment Directive (RED) 2014/53/EU due to the built-in

WiFi adapter and left the factory in a faultless state. The RED-Directive

includes the general requirements according to Safety and Electromagnetic

Compatibility EMC.

The safety requirements according Low Voltage Directive (LVD) 2014/35/EU

are tested in compliance with DIN EN 61010-1 for the device and with

DIN EN 60950-1 for built-in components and accessories from other

manufactures.

The electromagnetic compatibility requirements according to EMC-

Directive 2014/30/EU are tested in compliance with DIN EN 61326-1 and

ETSI EN 301 489-1.

To maintain the faultless state and ensure safe operation, all instructions

and warning notes in this manual must be followed.

The AURA handheld NIR with standard handle (2289-971) meets the

degree of protection IP 54 and protection class III.

The AURA handheld NIR with slanted handle (2289-955) meets the degree

of protection IP 54 (front side only) and protection class III.

The instruments carries the marking.

6AURA handheld NIR – 2289-971 and 2298-955 | User Manual

Safety instructions AURA handheld NIR

1.1 Used symbols and signal words

The symbols below are used in this user manual to indicate safety relevant

or helpful information:

Attention

Warning of possible property damage

Note

Read the User Manual

Note

Important general note

Note

Important note about environmental protection

User Manual | AURA handheld NIR – 2289-971 and 2298-955

Safety instructions

AURA handheld NIR

1.2 General safety instructions

The AURA handheld NIR including the original accessories must only be

used for the applications described in this user manual. The manufacturer

cannot be held liable for any other use.

Only our service staff or authorized personnel is allowed to carry out repair

work on this device. The device manufacturer does not assume any liability

for damages caused by unauthorized actions with the device. Furthermore,

such actions result in the forfeiture of all warranty and guarantee claims.

The devices may only be operated by instructed personnel. Such personnel

must be instructed on the possible risks associated with working with the

device and the respective area of application. The AURA handheld NIR is a

precision instrument, the functions of which may be adversely affected or

irreparably damaged in case of improper use.

Warning and note signs must not be removed and must always be in a

legible condition.

Please note:

• The AURA handheld NIR must not be started if it is damaged or in a

wet condition.

• Do not open the system.

• Never look directly into the measuring beam. The bright light of the

halogen lamp can cause glare.

• Beware of hot surfaces.

• The system contains a battery with a transport temperature range

from – 20 to + 60 °C. Never expose the system to the open sun for an

extended time span. If so, the system can get damaged seriously.

• Never leave samples unobserved in front of the measurement window.

The radiation from the halogen lamp can cause ﬁre.

8AURA handheld NIR – 2289-971 and 2298-955 | User Manual

Safety instructions AURA handheld NIR

1.3 Environmental management

Our company has implemented a certified environmental management

system that complies with ISO 14001.

This product has been developed, tested and manufactured in accordance

with the applicable environmental provisions and directives of the European

Union.

The product and its accessories comply with EU directives 2015/863/EU (RoHS),

2012/19/EU (WEEE), 2006/66/EU + amendment 2013/56/EU (for batteries)

and EMC-2014/30/EU + LVD-2014/35/EU (for accessories) to the extent

applicable to this product.

The device carries the marking.

We have installed a take-back and recycling process that ensures proper

recycling in accordance with the above-mentioned EU directives.

For details concerning disposal and recycling, please contact your local sales

or service organization.

The product must not get into domestic waste nor be disposed of via

municipal waste disposal facilities. On resale of the product, the seller

is obligated to inform the buyer that the product must be disposed of

properly.

User Manual | AURA handheld NIR – 2289-971 and 2298-955

Safety instructions

AURA handheld NIR

1.4 Storage and transport

The sensor is not provided with any special transportation mountings

or safety devices. We recommend using the original packaging for

transportation or to use the optionally available carrying case. You should

also use the original packaging when returning the device.

When storing or using the system, please note the speciﬁed environmental

parameters.

Attention

For air transport, follow the latest internationally applicable

regulations for the transport of Li-ion batteries�

The AURA handheld NIR with standard handle (2289-971) works with the

Standard Li-ion Smart Battery Pack RRC2054 by RRC power solutions.

The AURA handheld NIR with slanted handle (2289-955) works with the

Standard Li-ion Smart Battery Pack RRC 2040-2 by RRC power solutions.

Before use, read the latest Safety Data Sheet (SDS) and the manual

provided by the battery manufacturer.

These documents can be downloaded here: https://www.rrc-ps.com/en/

battery-packs/standard-battery-packs/products/rrc2054/ and here: https://

www.rrc-ps.com/en/battery-packs/standard-battery-packs/products/

rrc2040-2/.

Both documents can also be found in the Appendix of this User Manual.

Attention

Check the battery-status-LED bar before you store the device�

In case the charging status is below 25 %, please charge the

battery pack, otherwise the battery-pack could be damaged or

the lifetime is reduced�

10 AURA handheld NIR – 2289-971 and 2298-955 | User Manual

Safety instructions AURA handheld NIR

1.5 WiFi

The sensor comes with a built-in WiFi adapter type LM808. The WiFi

functionality shall only be used when a national certiﬁcate exists for your

country.

The following national certiﬁcates exist as of today:

Country / Region Standard ID

EU – all member

countries

EU declaration of conformity

(RED) —

USA FCC VVX808-04XX

Canada Radio Cert. (IC) 10531A-80804XX

China CMIIT 2017AJ5291

Japan Telec —

Russia, Belorussia,

Kazakhstan EAC —

South Africa ICASA —

South Korea KCC —

Australia and

New Zealand RCM —

Taiwan NCC —

Singapore IMDA —

Israel MOC —

Tab. 1 WiFi – national certiﬁcates

Altri manuali per AURA

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Zeiss Strumento di misura

Zeiss

Zeiss GOM Scan 1 Manuale utente

Zeiss

Zeiss TEMPAR console Manuale utente

Zeiss

Zeiss Humphrey Field Analyzer 3 Manuale utente

Zeiss

Zeiss MMZ M Manuale utente

Zeiss

Zeiss AT 030 Manuale dell'operatore

Zeiss

Zeiss AURA handheld NIR Istruzioni operative

Zeiss

Zeiss CONTURA Manuale utente

Zeiss

Zeiss CONTURA G2 Manuale utente

Zeiss

Zeiss AURA Manuale utente

Zeiss

Zeiss Corona process Manuale utente

Zeiss

Zeiss HUMPHREY 720i Manuale utente

Zeiss

Zeiss VISUREF 150 Manuale utente

Zeiss

Zeiss Humphrey Field Analyzer 3 Manuale utente

Zeiss

Zeiss CenterMax Manuale utente

Zeiss

Zeiss MEL 80 Manuale utente

Zeiss

Zeiss humphrey HFA II-i series Guida rapida

Zeiss

Zeiss Gom T-SCAN hawk Istruzioni per l’uso

Zeiss

Zeiss MCS 600 Manuale utente

Zeiss

Zeiss Humphrey II-i series Manuale utente

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
