ZyXEL Communications NWA-3165 Manuale utente

Benefits

Wireless N Business

WLAN Access Point

NWA-3165

Enabling Wi-Fi Convergence for

Enterprise Applications

ˍġ Draft 802.11n (2.0) Support and

Wi-Fi n/b/g Certification

ˍġ Multiple SSID with Predefined

VoIP, Guest SSID

ˍġ Wi-Fi Multimedia (WMM) + Auto

Traffic Classifier (ATC)

ˍġ Wi-Fi WPA2-Certified

ˍġ Plenum Rating Enclosure and

Flexible Installation

Dead-Spot Elimination with MIMO Technology

The Wi-Fi n/b/g-certified and IEEE 802.11n draft 2.0-compliant ZyXEL NWA-3165 is a wireless LAN Access

Point designed for enterprise environments.The MIMO (Multiple In, Multiple Out) feature of NWA-3165

utilizes a multiple-antenna system to take advantage of the multi-path effect in RF implementations,

rather than fighting against it as conventional 802.11 Access Points did.The resulting improvements in

both range and capacity provide substantially more reliable signal quality and greater bandwidth that are

critical to SMB deployments.

Virtual AP for Specific Applications

The NWA-3165 supports up to 4 multiple SSIDs with 802.1Q VLAN tag.This function makes the NWA-3165

perform as multiple virtual APs. The NWA-3165 also provides pre-defined voice SSID and guest SSID for

optimized voice prioritization, and offers top-level security for guest access without difficulties of

complicated configuration efforts.

Enterprise Class Security

The NWA-3165 delivers enterprise-class security features to small and medium businesses.To shield

wireless communication at the source, WPA2 with TKIP/AES encryption provides the latest and toughest

standard-based security while WEP encryption supports legacy wireless clients. Additionally, WPA2

ensures the compatibility with all Wi-Fi certified wireless clients.

Sophisticated Design with Easy Installation

The NWA-3165 is designed with a non-invasive concept that prevents radical image change to enterprise

surroundings. Its UL2043-certified casing has been fire-tested for heat and visible smoke release for

discrete products and related accessories installed in air-handling spaces.The test evaluates various small,

non-metallic products intended for use in air-handling spaces and plenums to prove that they are not

harmful to the nearby personnel in case of fire.With the professional installation kit ZyXEL provides,NWA-

3165 can be deployed with great flexibility. As an excellent performer and safe device,NWA-3165 is the

best choice for small and medium enterprises.

Specifications

System Specifications

Standard Compliance

• Ethernet

- IEEE 802.3

- IEEE 802.3u

• WLAN

- IEEE 802.11 b/g

- IEEE 802.11n Draft2.0 compliant

• PoE: 802.3af

Radio

• Output Power

- 11b/g: 17 dBm

- 11n: 15 dBm

• Modulation Type

- 802.11b: DBQSK, DQPSK, CCK

- 802.11g: BQSK, QPSK, 16-QAM, 64-QAM

- 802.11n: BQSK, QPSK, 16-QAM, 64-QAM

• Frequency Band

- USA: 2.412 to 2.462 GHz

- ETSI: 2.412 to 2.472 GHz

- Taiwan: 2.412 to 2.462 GHz

Coverage Range

• 11g

- Indoor: up to 100 m

- Outdoor: up to 400 m

• 11n

- Indoor: 120 m

- Outdoor: 400 m

Antenna

• 3 x 1.8 dBi dipole embedded antennas

Performance

• Wired Data Rates:10/100 Mbps Auto-sensing

(full-duplexing switch)

• Wireless Data Rates

- IEEE 802.11b (auto-fallback)

CCK: 11/5.5 Mbps

DQPSK: 2 Mbps

DBPSK: 1 Mbps

- IEEE 802.11g (auto-fallback)

64-QAM: 54/48 Mbps

16-QAM: 36/24 Mbps

QPSK: 18/12 Mbps

BPSK: 9/6 Mbps

- Wireless N (auto-fallback)

64-QAM: up to 300 Mbps

16-QAM: up to 180 Mbps

QPSK: up to 90 Mbps

BPSK: up to 30 Mbps

Remark: 11n data rate adoption is related to the configuration

of modulations,coding rate, and spatial stream.

Security

• Wireless Access: 64/128/152-bit WEP data

encryption 802.1x authentication with

MD5/TLS/TTLS/PEAP WPA/WPA2 support

Hardware Specifications

• Ethernet: 10/100Base-T full duplex RJ-45 x 1

• Reset button: Yes

• Power over Ethernet:Yes

• Power supply: 12 V DC, 1.5A

Physical Specifications

• Dimensions: 138.5 (W) x 198.5 (D) x 47.5 (H) mm

• Weight: 420 g

Environmental Specifications

Operating Environment

• Temperature: 0°C ~ 50°C

• Humidity: 20% ~ 95% (non-condensing)

Storage Environment

• Temperature: -30°C ~ 60°C

• Humidity: 20% ~ 95%

Certification

Radio

• FCC Part 15C 15.247

• ETSI EN 300 328 V1.7.1

• DGT LP0002

• Industry Canada RSS-210

• AS/NZS 4268

EMC

• FCC Part 15B

• EN 301 489-17 V1.2.1: 08-2002

• EN 301 489-1 V1.5.1: 11-2004

• EN 55022: 2006

• ICES-003

• AS/NZS CISPR22

Safety

• CSA International

- CSA 60950-1

- IEC 60950-1

- EN 60950-1

- UL 60950-1

• ANS/UL 2043 Compliant

• EN 60601-1-2: 2002

For more product information, visit us on the web www.ZyXEL.com

65-100-316501B 12/07

product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
