Abocom SW1600R Manuale utente

16-Port Fast Ethernet

N-Way Switch

The FastEthernet 10/100Mbps N-Way Switchprovides

you a flexible, reliable, and affordable solution of the

Ethernet network. It comes with sixteen independent

10BASE-T /100BASE-TX ports. Each port delivers up

to 200Mbps throughput, and is able to operate in either

half or full-duplex modes. The Fast Ethernet

10/100Mbps N-Way Switch also processes a N-Way

auto-negotiation function, which automatically adjusts

the device for optimum operation; ¡§ Store-and-

Forward¡¨architecture filtersto eliminateerror packets

and improveefficiency,and MDI/MDIXauto crossover

technology provides for detecting a plugged straight

through orcrossover Ethernetcable automatically. Plus,

the built-in 4M bits DRAM is smaller than the SRAM in

dimension and features very low power consumption.

Moreover, the built-in Universal Power Supply allows

you to install the Switch easily without the external

power adapter.

Key Features & Specification

* Compliant with IEEE 802.3 10Base-T and IEEE

802.3u 100Base-TXstandards

* Supports store-and-forward

* 10/100Mbps port auto-detect onFull or Half

Duplex Mode

* IEEE802.3x orBack Pressure(HDX) FlowControl

* Each Ethernet port supports MDI/MDIX auto

crossover capacity

* 16(Sixteen) 10/100MbpsAuto-Detection ports

* Providesnon-blocking andHead-of-line blocking

prevention

* Embedded 8K entries of look-up table and 128

entriesof CAM

* 4Mbits DRAMis builtin aspackage storage buffer.

Page basedbuffer management toefficiently utilize

the internal packet buffer.

* Broadcaststorm filtering control

* Dimension(WxDxH): 225x 126.8x 44(mm)

* Builtin UniversalPowerSupply: 90~ 264V

* 16x RJ45STP/UTP networkports on frontpanel

* EmissionCertification: FCC/CE ClassA

* OperatingEnvironment:

Temperature:0 ~40oC; Humidity:5 ~90 %RH

* Support WindowsNT4.x/98/98SE/ME/2000/XP
