Abocom WAP2101 Manuale utente

WAP2101

802.11b/g Portable Router

Description

The WAP2101 is a compact/Travel size IEEE802.11b/g Access Point with 1

Fast Ethernet port, which provides a powerful high-speed wireless

connection for compatible wireless-enabled devices into the network with

the freedom to roam. With web-based UI, this Access Point is easy to be

setup and maintained. All functions can be configured within the easy and

friendly user interface via web browser. Via the fast wireless network speed

of 54 Mbps, you can be very comfortable to have experience of high speed

web surfing, efiles downloading, online game playing, and video

conference session and streaming high quality multimedia materials. The

WAP2101 provides WAP/WAP2, 64/128 bit WEP encryption and

IEEE802.1x which ensures a high level of security to protect users' data

and privacy when you are traveling. Plus, the build-in power supply

inside the enclosure, there is no need to bring redundant power adapter for

your light travel need. Specification

Standards IEEE 802.11 b/g standards compliant

Antenna High gain Internal Antenna (5dBi)

Frequency Range

802.11b/g

USA (FCC): 2.412GHz ~ 2.462GHz

Europe (ETSI): 2.412GHz ~ 2.472 GHz

Japan (TELEC): 2.412GHz ~ 2.483GHz

Number of Selectable

Channels

802.11b/g:

USA (FCC) 11 channels;

EU (ETSI) 13 channels;

Japan (TELEC) 14 channels

Data Rate 802.11b: 1, 2, 5,5, 11Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps

Coverage Area Indoor: up to 100M

Outdoor: up to 300M

Transmit Power (EIRP) 11b CCK: +17~19dBm

11g OFDM: +17~19dBm

Receiver Sensitivity -68dBm at 54Mpbs, 10% PER ;

-82dBm at 11Mpbs, 8% PER ;

Power Requirement AC 110~240V

Certifications: FCC, CE

Features

Create temporary, personal, wireless access in your hotel

room or a coffee shop hotspot

Travel size design with build-in Power supply & Internal

high gain antenna.

High security with build-in Security: WEP 64/128, WPA,

WPA2, 802.1x and 802.11i

Support Router/AP, WDS (Bridge + Repeater), or Client

Mode

Advanced Quality of Service (QoS) - 802.11e, WMM

Applications
