User Manual

PCM-3618

8-port RS-422/485 High-Speed

Module

PCM-3618 User Manual ii

The documentation and the software included with this product are copyrighted 2008

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

Part no. 2000361801 Edition 2

Printed in Taiwan April 2009

iii PCM-3618 User Manual

Declaration of Conformity

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

kind of cable is available from Advantech. Please contact your local supplier for

ordering information.

This product has passed the CE test for environmental specifications. Test conditions

for passing included the equipment being operated within an industrial enclosure. In

order to protect the product from being damaged by ESD (Electrostatic Discharge)

and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-

sure products.

FCC Class B

Note: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful inter-

ference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be determined by turning the equip-

ment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Technical Support and Assistance

1. Visit the Advantech web site at www.advantech.com/support where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

PCM-3618 User Manual iv

Warnings, Cautions and Notes

Document Feedback

To assist us in making improvements to this manual, we would welcome comments

and constructive criticism. Please send all such - in writing to: support@advan-

tech.com

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

15. The power cord or plug is damaged.

16. Liquid has penetrated into the equipment.

17. The equipment has been exposed to moisture.

Warning! Warnings indicate conditions, which if not observed, can cause personal

injury!

Caution! Cautions are included to help you avoid damaging hardware or losing

data. e.g.

There is a danger of a new battery exploding if it is incorrectly installed.

Do not attempt to recharge, force open, or heat the battery. Replace the

battery only with the same or equivalent type recommended by the man-

ufacturer. Discard used batteries according to the manufacturer's

instructions.

v PCM-3618 User Manual

18. The equipment does not work well, or you cannot get it to work according to the

user's manual.

19. The equipment has been dropped and damaged.

20. The equipment has obvious signs of breakage.

21. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C

(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

22. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

23. The sound pressure level at the operator's position according to IEC 704-1:1982

is no more than 70 dB (A).

Safety Precaution - Static Electricity

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained

herein.Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from

damage.

To avoid electrical shock, always disconnect the power from your PC chassis

before you work on it. Don't touch any components on the CPU card or other

cards while the PC is on.

Disconnect power before making any configuration changes. The sudden rush

of power as you connect a jumper or install a card may damage sensitive elec-

tronic components.

PCM-3618 User Manual vi

vii PCM-3618 User Manual

Contents

Chapter 1 Overview...............................................1

1.1 Introduction ............................................................................................... 2

1.2 Features .................................................................................................... 2

1.3 Specifications ............................................................................................ 2

1.4 Initial Inspection ........................................................................................ 3

1.5 Board Layout............................................................................................. 3

1.6 Card Configuration .................................................................................... 3

1.7 Default Settings......................................................................................... 4

Table 1.1: PCM-3618 Default Configuration................................ 4

Chapter 2 Jumper and Switch Settings ..............5

2.1 Jumper and Switch Settings...................................................................... 6

Table 2.1: Interrupt Status Register SW1.................................... 8

Chapter 3 Software & Drivers ............................11

3.1 Operating Environment Selection ........................................................... 12

3.1.1 Driver Installation for DOS Users................................................ 12

3.2 Card Setup .............................................................................................. 12

3.2.1 ICOM Utility Setup for Windows 95/98/NT.................................. 13

3.3 Configuration........................................................................................... 13

3.4 Jumper Setting ........................................................................................ 14

3.5 Signal Wiring ........................................................................................... 15

Chapter 4 Hardware Installation ........................17

4.1 Hardware Installation .............................................................................. 18

PCM-3618 User Manual viii

Chapter 1

1Overview

PCM-3618 User Manual 2

1.1 Introduction

The PCM-3618 is a PC/104-compatible module with eight individually configurable

RS-422/485 ports. It works with PC/104 CPU modules to extend additional RS-2422/

485 ports. The PCM-3618 also features lots of functions such as high transmission

speed of 921.6 kbps, shared IRQ and more. It also provides high-performance

16C550 UART communication chip with 16-byte FIFO to reduce CPU load. This

makes the PCM-3618 especially suitable for multitasking environments.

The PCM-3618 comes with Windows 95/98/NT/ME configuration utility (Windows

2000/XP utility will soon be ready and allowed to download through our Web site).

The Windows con-figuration utility provides self-diagnostics and performance analy-

sis function for easy troubleshooting and debugging.

The PCM-3618 provides versatile function settings to meet users needs. These func-

tion settings include Shared IRQ mode setting and Speed mode setting. In Shared

IRQ set-ting, all of the eight ports of interrupt can be specified to one. This solves

problems of IRQ insufficiency within the embed-ded system. In Speed setting, the

PCM-3618 allows trans-mission rate up to 921.6 kbps. It improves the performance

of the system.

1.2 Features

Eight shared RS-422/485 serial ports

Automatic RS-485 data flow control

Transmission speeds up to 921.6 Kbps

Shared IRQ settings for each port

Windows configuration utility for Windows 95/98/NT/MEP.S. Windows 2000/XP/

CE driver will soon be available on our Web site

Built-in termination resistors

LED indicators: TX, RX

1.3 Specifications

Bus interface: PC/104 (ISA)

Number of ports: 8

I/O address: 0x000 ~ 0x3F8

UART: 8 x 16C550

IRQ: 3, 4, 5, 6, 7, 9, 10, 11, 12, 15

Data bits: 5, 6, 7, 8

Stop bits: 1, 1.5, 2

Parity: none, even, odd

Speed (bps): 50 ~ 921.6 K

Connectors: Eight DB-9 male

Signal support: TxD+, TxD-, RxD-, CTS+, CTS-,RTS+ and RTS-

Surge protection: 1000 VDC

Temperature:

–Operating : 0 ~ 65°C (refer to IEC-68-1-1,2) ( 32~149°F)

–Storage : -25 ~ 80°C (-13~176°F)

Operation Humidity: 0% ~ 90% Relative Humidity, non-condensing
