AEMC MR561 Manuale utente
AC/DC OSCILLOSCOPE
CURRENT PROBES MR461
MR561
ENGLISH User Manual
!
AC/DC CURRENT PROBE
Model MR 561
ON
OL
OFF
600A
60A
600V CAT III - 600A
!
OUTPUT:
600A: 1 mV/A
60A: 10 mV/A
AC/DC CURRENT PROBE
Model MR 461
ON
OL
OFF
1500A
150A
600V CAT III - 1500A
OUTPUT:
1500A: 1 mV/A
150A: 10 mV/A
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ________________________________
Catalog #: 1200.72 / 1200.73
Model #: MR461/ MR561
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
Table of Contents
1. INTRODUCTION............................................................................... 3
1.1 International Electrical Symbols................................................3
1.2 DenitionofMeasurementCategories .....................................4
1.3 ReceivingYourShipment..........................................................4
1.4 OrderingInformation.................................................................4
1.4.1 AccessoriesandReplacementParts............................4
2. PRODUCT FEATURES ...................................................................... 5
2.1 Description................................................................................5
2.2 MR461Features .......................................................................6
2.3 MR561Features .......................................................................7
2.4 InstrumentDisplayCompatibility ..............................................8
3. SPECIFICATIONS............................................................................. 9
3.1 ReferenceConditions ...............................................................9
3.2 MR461Specications ...............................................................9
3.2.1 Electrical .......................................................................9
3.2.2 Mechanical..................................................................10
3.3 MR561Specications .............................................................10
3.3.1 Electrical .....................................................................10
3.3.2 Mechanical..................................................................11
3.4 CommonSpecications(MR461&MR561) ........................... 11
3.4.1 Electrical .....................................................................11
3.4.2 Mechanical..................................................................12
3.4.3 Safety..........................................................................13
4. OPERATION .................................................................................. 14
4.1 MakingMeasurements ...........................................................14
4.1.1 DCMeasurement........................................................14
4.1.2 ACMeasurement........................................................15
4.1.3 IndicatorLights:GreenLED .......................................15
4.1.4 MakingMeasurementswiththeConnector ................15
4.1.5 Auto-Off.......................................................................16
4.2 TipsForGettingtheBestAccuracy ........................................16
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
4.3 TypicalResponseCurves .......................................................17
4.4 OperationExamples ...............................................................18
5. MAINTENANCE ............................................................................. 20
5.1 Maintenance ...........................................................................20
5.1.1 BatteryReplacement ..................................................20
5.1.2 Cleaning......................................................................20
Limited Warranty ...................................................................................22
WarrantyRepairs...................................................................................22
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
AC/DCCurrentProbeModelsMR461andMR561
3
CHAPTER 1
INTRODUCTION
WARNING
Thesesafetywarningsareprovidedtoensurethesafetyofpersonnel
andproperoperationoftheinstrument.
•Read this instruction manual completely and follow all the safety
informationbeforeattemptingtouseorservicethis instrument.
•Use caution on any circuit: Potentially high voltages and currents
maybepresentandmayposeashockhazard.
•Read the safety specications section before using the Model
MR461orMR561.Neverexceedthemaximumworkingvoltagerat-
ingsgiven.
•Safetyistheresponsibilityoftheoperator!
•Neveropenthebackoftheinstrumentwhileconnectedtoanycircuit
orinput.
•ALWAYSconnecttheModelMR461orMR561tothedisplaydevice
beforeclampingtheprobeontothesampleundertest.
•Alwaysinspect theinstrument and leadprior touse. Replace any
defectivepartsimmediately.
•NEVERusetheModelMR461orMR561 onelectricalconductors
ratedabove600V.
1.1 International Electrical Symbols
This symbol signifies that the instrument is protected by double or reinforced
insulation.
This symbol on the instrument indicates a WARNING and that the operator must refer
to the user manual for instructions before operating the instrument. In this manual,
the symbol preceding instructions indicates that if the instructions are not followed,
bodily injury, installation/sample and product damage may result.
Risk of electric shock. The voltage at the parts marked with this symbol may be
dangerous.
This symbol refers to a type A current sensor. This symbol signifies that application
around and removal from HAZARDOUS LIVE conductors is permitted.
In conformity with WEEE 2002/96/EC
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
4
AC/DCCurrentProbeModelsMR461andMR561
1.2 Definition of Measurement Categories
CAT I: Formeasurementsoncircuits notdirectlyconnectedtotheAC
supply wall outlet such as protected secondaries, signal level,
andlimitedenergycircuits.
CAT II: For measurements performed on circuits directly connected to
the electrical distribution system. Examples are measurements
onhouseholdappliancesorportabletools.
CAT III: For measurements performed in the building installation at
the distribution level such as on hardwired equipment in xed
installationandcircuitbreakers.
CAT IV: For measurements performed at the primary electrical supply
(<1000V) such as on primary overcurrent protection devices,
ripplecontrolunits,ormeters.
1.3 Receiving Your Shipment
Uponreceivingyourshipment,makesurethatthecontentsareconsistent
withthepackinglist.Notifyyourdistributorofanymissingitems.Iftheequip-
mentappearstobedamaged,leaclaimimmediatelywiththecarrierand
notifyyourdistributoratonce,givingadetaileddescriptionofanydamage.
Savethedamagedpackingcontainertosubstantiateyourclaim.
1.4 Ordering Information
AC/DCOscilloscopeCurrentProbeModelMR461............. Cat. #1200.72
AC/DCOscilloscopeCurrentProbeModelMR561............. Cat. #1200.73
Both models include a 9V battery and user manual.
1.4.1 Accessories and Replacement Parts
Banana/BNCconnectorXF-SS(4mmplugadaptor)........... Cat. #2111.32
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
AC/DCCurrentProbeModelsMR461andMR561
5
CHAPTER 2
PRODUCT FEATURES
2.1 Description
The MR probes are a line of professionalAC/DC current probes. They
aredesignedtothelatestsafetyandperformancestandards.Twodiffer-
enthook-shapedjawsareoffered,bothpermittingtheuserto“pry”intoor
“hook”ontocables(willaccept2x500MCM)orsmallbusbars.
TheMRseriesusesHalleffecttechnology.Theelectronicsandbatteries
areself-containedinthehandles.TheoutputoftheAC/DCprobesis1mV/
Aand10mV/A.Anautozeropushbuttonensuresrapidandstablezeroing.
Thereisnooutputltering–TrueRMSwithDCcomponentsispossible.
Phaseshiftisexcellent,makingtheMRserieswellsuitedforpowerand
powerqualityapplications.
ModelMR461isaportable400AAC(600Apeak),600ADCcurrentprobe.
TheunithasproportionalmVoutputfordirectreadingsonhandheldand
benchtoposcilloscopes.
Model MR561 is a portable 1000AAC (1500A peak), 1500ADC current
probethataccuratelymeasuresACorDCcurrentwaveformsusingHall
effecttechnology.
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
6
AC/DCCurrentProbeModelsMR461andMR561
2.2 MR461 Features
ON
OL
OFF
600A
60A
600V CAT III - 600A
!
OUTPUT:
600A: 1 mV/A
60A: 10 mV/A
AC/DC CURRENT PROBE
Model MR 461
Ø = 1.18" (30mm)
Cable max
Ø = 0.95" (24mm)
Dual Cable max
1
2
3
4
5
6
7
8
9
Figure 1
1. Jaws
2. Conductor
3. Protectivenon-slipguard
4. Zeroadjustmentbutton
5. BNC Connector
6. Coaxialcable6.5ft(2m)
7. Three-positionrange
selectionswitch:
•60A(10mV/A)
•600A(1mV/A)
•On/Off
8. Greenlight(onwhenbattery
voltage≥6.5V)
9. Redlight(overrangeand
incorrectzeroadjustment)
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
AC/DCCurrentProbeModelsMR461andMR561
7
2.3 MR561 Features
!
AC/DC CURRENT PROBE
Model MR 561
ON
OL
OFF
1500A
150A
600V CAT III - 1500A
OUTPUT:
1500A: 1 mV/A
150A: 10 mV/A
1
2
3
4
5
6
7
8
9
Ø = 1.6" (42 mm)
Cable max
1.96 x 0.19" (50 x 5 mm)
Dual Bus Bar max
Ø = 0.98" (25 mm)
Dual Cable max
Figure 2
1. Jaws
2. Conductor
3. Protectivenon-slipguard
4. Zeroadjustmentbutton
5. BNC Connector
6. Coaxialcable6.5ft(2m)
7. Three-positionrange
selectionswitch:
•150A(10mV/A)
•1500A(1mV/A)
•On/Off
8. Greenlight(onwhenbattery
voltage≥6.5V)
9. Redlight(overrangeand
incorrectzeroadjustment)
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
8
AC/DCCurrentProbeModelsMR461andMR561
2.4 Instrument Display Compatibility
The Model MR461 and MR561 current probes are compatible with any
hand-heldandbenchtoposcilloscope,whichhavethefollowingfeatures:
• BNCinput
• Rangeandresolutioncapableofdisplaying1mVofoutputper
ampofmeasuredcurrent
• Instrumentaccuracyof0.3%orbettertotakefulladvantageofthe
probeaccuracy
• Inputimpedanceof1MΩ/100pForgreater
Whentheprobeismakingameasurement,thecurrent-carryingconduc-
torisnotbrokenandremainselectricallyisolatedfromtheprobeoutput.
Asaresult,theprobeoutputcommonmaybeeitheroated(isolated)or
grounded.
Warning: User Safety
Alwaysuseanoscilloscope,voltmeterorotherdisplayingdevice,appro-
priatelyratedforsafetytothevoltageofthesamplebeingtested.
www.ShopAEMC.ca
Shop for AEMC products online at: 1.800.561.8187
