American Dynamics ADC660 Manuale utente

FEATURES

The ADC660 and ADC660X black & white

1/3-inch CCD cameras are full-performance,

high-resolution imagers.

Incorporating the latest in CCD technology,

the camera provides improved control of video

processing; this allows it to deliver higher

resolution (580 TV lines) and enhanced

sensitivity (0.03 lux).

The camera can operate in extremely low light

conditions, making it the perfect choice for

any type of video application that requires

higher levels of sensitivity and image quality.

These cameras are sensitive to infrared light

and are suitable for use in covert applications

when used in conjunction with IR

illuminators.

The performance features of this camera make

it the ideal choice to be used with other

peripheral CCTV equipment such as indoor

and outdoor housings and pan/tilts.

ADC660 and ADC660X

1/3-INCH BLACK & WHITE CCD CAMERA

•1/3-inch interline black &

white CCD

•580 TV lines resolution

•0.03 lux low light

sensitivity

•Sensitive to IR

illumination

•Supports DC-type or

EE-type auto iris lenses

•CS lens mount

•Aperture correction

•Automatic electronic

shutter

•Automatic gain control

•Automatic backlight

compensation

•Phase adjustable line-lock

•24 VAC input

•Internal isolation

transformer

•Low power consumption

Front side – Single sheet – Letter size – print 4/c

www.americandynamics.net

ADC660_VS245_L.qxd 2/19/04 1:30 PM Page 1

SPECIFICATIONS

Model Numbers

ADC660 . . . . . . . . . . . . . . . . . . . . .EIA RS-170 Camera

ADC660X . . . . . . . . . . . . . . . . . . . .CCIR Camera

Operational

Imager . . . . . . . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD array

Video Output . . . . . . . . . . . . . . . . .1.0 Vp-p / 75 Ω, composite

Active Pixel Count

EIA . . . . . . . . . . . . . . . . . . . . . . . .768 (H) x 494 (V) pixels

CCIR . . . . . . . . . . . . . . . . . . . . . .752 (H) x 582 (V) pixels

Minimum Scene

Illumination . . . . . . . . . . . . . . .0.03 lux (f1.2 lens)

Horizontal Resolution . . . . . .580 TV lines

Light Compensation

Modes . . . . . . . . . . . . . . . . . . . . . . .Automatic electronic shutter, On/Off

(EIA 1/60 -1/100,000 sec)

(CCIR 1/50 - 1/100,000 sec)

Auto Iris Drive . . . . . . . . . . . . . . . .DC or EE-type

Backlight Compensation . . . . . .On/Off selectable

Aperture Correction . . . . . . . . . . .Yes

Synchronization Modes . . . . . . .Line-lock with phase adjustment

S/N Ratio . . . . . . . . . . . . . . . . . . . .-50 dB

Controls

AES . . . . . . . . . . . . . . . . . . . . . . . . . .On/Off

BLC . . . . . . . . . . . . . . . . . . . . . . . . . .On/Off

Back Focus . . . . . . . . . . . . . . . . . . .Self locking mechanism

Auto Iris . . . . . . . . . . . . . . . . . . . . .DC/EE-type, switchable

DC Iris . . . . . . . . . . . . . . . . . . . . . . .Level control

Connectors

Composite Video . . . . . . . . . . . . . .BNC

Auto Iris

EE-type . . . . . . . . . . . . . . . . . . . .Screw terminals

DC-type . . . . . . . . . . . . . . . . . . . .4 pin square

Electrical

Voltage . . . . . . . . . . . . . . . . . . . . . . .24 VAC ±20%

60 Hz (EIA)

50 Hz (CCIR)

Power Consumption . . . . . . . . . .3.6 watts

Mechanical

Lens Mount . . . . . . . . . . . . . . . . . .CS standard with C adapter included

Camera Mount . . . . . . . . . . . . . . .1/4-inch - 20 (top or bottom)

Dimensions (H x W x L) . . . . . . .55 x 55 x 120 mm

(2.16 x 2.16 x 4.72 in)

Unit Weight . . . . . . . . . . . . . . . . . .400 g (0.9 lbs)

Shipping Weight . . . . . . . . . . . . . .680 g (1.51 lbs)

Color . . . . . . . . . . . . . . . . . . . . . . . .Light gray

Environmental

Operating Temperature . . . . . . . .-10˚ to 50˚ C (14˚ to 122˚ F)

Humidity . . . . . . . . . . . . . . . . . . . . .85% RH (non-condensing)

Storage Temperature . . . . . . . . . .-30˚ to 60˚ C (-22˚ to 140˚ F)

Regulatory

Emissions . . . . . . . . . . . . . . . . . . . .FCC: Part 15, Class A

CE: EN55022

Immunity . . . . . . . . . . . . . . . . . . . .CE: EN50130-4

Safety . . . . . . . . . . . . . . . . . . . . . . . .UL2044

Recommended Housings*

AD1301, AD1303, AD1305, AD1314, AD1315

AD1317, AD1335, AD1337, AD1348

*Dependent on lens dimensions.

Recommended Camera Mounts

ADMC1361, ADMC1362, ADMC1363, ADMC1365,

ADMC1366, ADCM100T

AMERICAN DYNAMICS ADC660 AND ADC660X 1/3-INCH BLACK & WHITE CCD CAMERA

VS245-02 01/03 L

Product specifications and availability subject to

change without notice.

Certain product names mentioned herein may be trade

names and/or registered trademarks of other companies.

Front View Rear ViewSide View

VIDEO 24V AC

POWER

V.PHASE LEVEL

G + SIG

BLC

EE A1

OFF ON

LENS-1

LENS-2

30 mm

(1.18 in)

37 mm

(1.45 in)

120 mm

(4.72 in)

55 mm

(2.16 in)

55 mm

(2.16 in)

Back side – Single sheet – Letter size – print b/w

ADC660_VS245_L.qxd 2/19/04 1:30 PM Page 2
