FEATURES

www.americandynamics.net

Front side – Single sheet – Letter size – print 4/c

•1/3-inch interline color

imager, NTSC format

•330-line color imager

•Sharp picture

•2.0 lux light sensitivity

•Sensitive to IR

illumination

•Discreet housings

•Automatic electronic

shutter

•Automatic gain control

•Auto tracing white

balance

•12 VDC input via

included power supply

•ADC722WP includes IR

illumination and is

weather resistant

The ADC720 Series cameras feature a color

imager that delivers a sharp picture at a very

economical cost.

The ADC720 Series offers cameras in housings

different than your typical standard camera.

The ADC720D features a 3.5-inch discreet

dome housing that is an attractive alternative

to a standard camera.

The ADC721B features a low silhouette tube

design that will fit in with most decors.

The ADC722WP is a weather resistant tube

design that meets IP57 for weather resistance.

The built in IR illumination LEDs allow this

camera to produce a picture with 0 lux ambient

light. The 12 IR LEDs provide coverage up to

10 meters (30 ft) to deliver a sharp picture while

producing no visible light. In low light when

the IR illuminators are operating the camera

electronically switches to black and white.

The ADC723PIR is a camera mounted in a

standard motion detector shell. The camera

blends in to the background appearing as a

security system device. People are unaware that

there is video surveillance in the area.

ADC720 Series

COLOR SPECIALTY CAMERAS

ADC720Series_VS281 3/1/04 3:19 PM Page 1

AMERICAN DYNAMICS ADC720 SERIES COLOR SPECIALTY CAMERAS

Product specifications and availability subject to

change without notice.

Certain product names mentioned herein may be trade

names and/or registered trademarks of other companies.

VS281-04 03/04 L

Back side – Single sheet – Letter size – print b/w

SPECIFICATIONS

Model Numbers

ADC720D . . . . . . . . . . . . . . . . . . . .Color camera in 3.5-inch micro dome with

3.6 mm lens

ADC721B . . . . . . . . . . . . . . . . . . . .Color camera in Bullet housing with

3.6 mm lens and mount

ADC722WP . . . . . . . . . . . . . . . . . .Color camera in weatherproof Bullet

housing with 4.0 mm lens and IR

illuminators and mount

ADC723PIR . . . . . . . . . . . . . . . . . .Color camera in non-functional PIR

detector housing with 3.6 mm lens

Operational

NTSC Imager . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD

Video Output . . . . . . . . . . . . . . . . .1.0 Vp-p 75

Active Pixels Count . . . . . . . . . . . .512 (H), 492 (V)

Minimum Scene Illumination . .2.0 lux at F2.0

Horizontal Resolution . . . . . . . . .330 TVL

Light Compensation Modes . . .Auto electronic shutter

1/60 to 1/100,000

Synchronization Modes . . . . . . .Internal

White Balance . . . . . . . . . . . . . . . .Automatic

Geometric Distortion . . . . . . . . .None

S/N Ratio . . . . . . . . . . . . . . . . . . . .-48 dB

Input Connectors

Input Power . . . . . . . . . . . . . . . . . .2.1 mm

Composite Video . . . . . . . . . . . . . .BNC on cable

Electrical

Input Voltage . . . . . . . . . . . . . . . . .120VAC @ 60Hz

Power Supply Output . . . . . . . . .12VDC (±10%)

Power Consumption . . . . . . . . . .ADC720D 120 mA

ADC721B 120 mA

ADC722WP 120 mA

ADC723PIR 280 mA

Regulatory

Emissions . . . . . . . . . . . . . . . . . . . .FCC Part 15, Class B

ICES-003

Safety . . . . . . . . . . . . . . . . . . . . . . . .UL 1585 (power supply only)

Environmental

Operating Temperature . . . . . . . .-10º to 50º C (14º to 122º F)

Humidity . . . . . . . . . . . . . . . . . . . . .90% RH (non-condensing)

ADC522WP . . . . . . . . . . . . . . . . . .100% RH

Storage Temperature . . . . . . . . . .-30º to +60º C (-22º to 140º F)

Dimensions

Weight

Shipping Weight

Environmental

ADC720D

87 x 57 mm

3.4 x 2.2 in

(D x H)

.18 kg

.40 lbs

.43 kg

.90 lbs

Indoor Only

ADC721B

26 x 87 mm

1.02 x 3.4 in

(D x L)

.30 kg

.70 lbs

.55 kg

1.20 lbs

Indoor Only

ADC723PIR

70 x 110 x 49 mm

2.7 x 4.3 x 1.9 in

(W x H x D)

.18 kg

.40 lbs

.43 kg

.90 lbs

Indoor Only

ADC722WP

65 x 105 mm

2.5 x 4.1 in

(D x L)

.55 kg

1.20 lbs

.80 kg

1.80 lbs

IP57

Note: All ADC720 Series cameras ship with a 120 VAC to 12 VDC UL listed power supply with a 6 foot cord. 12 VDC

cameras will not line-lock and are not recommended to be used in a matrix switcher environment.

ADC720Series_VS281 3/1/04 3:19 PM Page 2
