EZ-KIT Lite for Analog Devices
ADSP-BF537 Blackfin Processor
Key Features
•ADSP-BF537 Blackfin Processor
•Max core clock rate 600 MHz
•64 MB (32 M x 16) SDRAM
•4 MB (2 M x 16) flash memory
•SMSC LAN83C185 10/100 PHY with
RJ45 connector
•CAN TJA1041 transceiver with
two modular connectors
•AD1871 96 kHz stereo DAC with
3.5 mm jack connector
•AD1854 96 kHz stereo ADC with
3.5 mm jack connector
•RS-232 UART line driver/receiver
•National Instruments Educational
Laboratory Virtual Instrumentation Suite
(NI ELVIS) interface
•Advanced USB-based debugger interface
•JTAG ICE 14-pin header
•Evaluation suite of VisualDSP++
development tools
•Flash utility for writing application boot
code and data to flash
•Six general-purpose LEDs, four general-
purpose push-buttons
•Expansion Board Interface Cluster for
evaluating and interfacing with the
processor’s peripheral interfaces
•Discrete IDC Expansion ports for all
processor peripherals
•CE-certified
System Requirements
•Pentium®500 MHz or higher
•Minimum of 256 megabytes of RAM
•Windows®2000 or Windows XP
•One available USB connector
•750 megabytes disk space
Overview
The ADSP-BF537 EZ-KIT Lite®provides developers with a cost-effective method
for evaluation of the ADSP-BF537 Blackfin®Processor and its rich set of system peripherals,
including the IEEE 802.3 10/100 Ethernet MAC and CAN 2.0B controller. A TCP/IP stack
with integrated device driver and example code is provided in VisualDSP++®release 4.0.
This evaluation kit was designed with an emphasis on modularity and expandability.
With this EZ-KIT Lite, users can learn more about Analog Devices ADSP-BF537 hardware
and software development and quickly prototype applications.
The EZ-KIT Lite includes an ADSP-BF537 processor desktop evaluation board along
with an evaluation suite of the VisualDSP++ development and debugging environment
that is comprised of a C/C++ compiler, assembler, and linker. The kit also contains
sample processor application programs, CE-approved power supply, a USB cable, both
straight through and crossover Ethernet cables, a 3.5 mm male/male stereo cable,
and a pair of stereo headphones.
Additionally, the ADSP-BF537 EZ-KIT Lite contains the National Instruments Educational
Laboratory Virtual Instrumentation Suite (ELVIS) interface. This interface will allow using the
oscilloscope, function generator, arbitrary waveform generator, DC voltage and current
measurement modules, and digital I/O. NI ELVIS is a LabVIEW™–based design and prototype
environment for university science and engineering laboratory curriculums. For more
details, go to www.ni.com.
www.analog.com/processors/tools
Embedded Processing Support
www.analog.com/processors
Email (in the U.S.A.):
Email (in Europe):
Fax (in the U.S.A.): 781.461.3010
Fax (in Europe): 49.89.76903.157
Worldwide Headquarters
Analog Devices, Inc.
One Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
U.S.A.
Tel: 781.329.4700
Fax: 781.326.8703
Toll-free: 800.262.5643 (U.S.A. only)
Analog Devices, Inc. Europe
c/o Analog Devices SA
17-19, rue Georges Besse
Parc de Haute
Technologie d’Antony
F-92182
Antony Cedex, France
Tel: 33.1.46.74.45.00
Fax: 33.1.46.74.45.01
Japan Headquarters
Analog Devices, Inc.
New Pier Takeshiba
South Tower Building
1-16-1 Kaigan,
Minato-ku, Tokyo
105-6891, Japan
Tel: 813.5402.8210
Fax: 813.5402.1063
Southeast Asian Headquarters
Analog Devices, Inc.
39/F One Pacific Place
88 Queensway
Admiralty,
Hong Kong, PRC
Tel: 852.2506.9336
Fax: 852.2506.4755
© 2005 Analog Devices, Inc. All rights reserved.
Trademarks and registered trademarks are the property
of their respective companies. Printed in the U.S.A. PH05378-2-1/05
www.analog.com/processors/tools
The VisualDSP++ development and debugging
environment, along with the advanced on-board USB-
based Debug Agent interface that operates up to
12 Mbits/second, enables users to perform standard
debugging functions (such as read and write
memory, read and write registers, load and execute
executables, set and clear breakpoints, and single-
step assembly, C, and C++ source code). The
evaluation versions of the included software tools are
limited to use with the EZ-KIT Lite. For faster and
unrestricted debugging, a family of JTAG emulators
and full versions of VisualDSP++ are available
separately from Analog Devices.
Analog Devices has EZ-Extender™ products (sold
separately) that plug into the Expansion Interface
of the ADSP-BF537 EZ-KIT Lite for additional
functionality. The Blackfin EZ-Extender daughter board
allows developers to connect to a number of Analog
Devices High Speed Converter (HSC) evaluation
boards, the OV6630 OmniVision camera evaluation
board, and an external LCD display. The Blackfin
USB-LAN EZ-Extender™ daughter board contains a
USB 2.0 interface and 10/100 Ethernet MAC. The
Blackfin A-V EZ-Extender™ daughter board contains
advanced audio and video circuitry, as well as
connectors allowing connection to three camera
sensor evaluation boards (Kodak, Mircron, and
OmniVision) and a Flat Panel Display (FPD) module.
CROSSCORE Development Tools
The ADSP-BF537 EZ-KIT Lite is part of the Analog
Devices CROSSCORE®Tools product line, which is
composed of a comprehensive set of development
tools providing engineers with easier and more robust
methods for developing and optimizing systems.
The CROSSCORE components include:
• VisualDSP++ development and
debugging environment
• EZ-KIT Lite evaluation kits
• EZ-Extender daughter boards
• Emulators
The easy-to-use VisualDSP++ integrated develop-
ment environment speeds development, debugging,
and deployment while shrinking product development
cycles and improving time to market. The EZ-KIT Lite
evaluation kits provide an easy way to investigate
the performance of the Analog Devices family of
embedded processors and DSPs. EZ-Extender daugh-
ter boards give developers access and ability to
connect various peripherals from Analog Devices and
third parties to the expansion interface of the EZ-KIT
Lite evaluation kits. Emulators are available for both
PCI and USB host platforms for rapid on-chip debug-
ging. Analog Devices is committed to continuous
expansion of leading-edge development solutions for
design engineers everywhere.
Embedded Processors and DSPs
Analog Devices is a leading supplier of embedded
and digital signal processing solutions, from high
performance Blackfin and TigerSHARC®Processors,
and from the low cost SHARC®Processors to
integrated mixed-signal DSPs that are ideal for an
ever-increasing spectrum of applications.
Analog Devices advances in design provide faster
processing, more memory, lower power consumption,
and simplified system integration. Analog Devices
products and technology provide a competitive
edge, complete with expert technical support,
comprehensive development tools, and the DSP
Collaborative™, an independent network of
third-party developers. For more information about
Analog Devices processors and DSPs, visit
www.analog.com/processors.
CROSSCORE Tools Support
Tel: 1-800-ANALOGD
Email: [email protected]
Web: www.analog.com/processors/tools
Ordering Information
Please call Analog Devices CROSSCORE Tools at
603-883-2430 or your local ADI sales representative
or distributor for pricing and ordering information
for part number: ADDS-BF537-EZLITE.
