Bend-Pak HDS-18E Manuale utente

INSTALLATION AND OPERATION MANUAL

SUPER-DUTY

FOUR-POST LIFTS

Models:

HDS-18E

HDS-27 / HDS-27X

HDS-40 / HDS-40X

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION

AND OPERATION. BY PROCEEDING WITH LIFT INSTALLATION AND OPERATION YOU

AGREE THAT YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS

OF THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO

OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.

Manual Revision H7 - January 2021

Manual Part Number 5900160

1645 Lemonwood Dr.

Santa Paula, CA. 93060, USA

Toll Free (800) 933-9970

Tel: (805) 253-2363

www.bendpak.com

RECEIVING

The shipment should be thoroughly inspected as soon as it

is received. The signed Bill of Lading is acknowledgement

by the shipping carrier as receipt of this product as listed

in your invoice as being in a good condition of shipment. If

any of these goods listed on this Bill of Lading are missing

or damaged, do not accept goods until the shipping carrier

makes a notation on the freight bill of the missing or dam-

aged goods. Do this for your own protection.

BE SAFE

Your new lift was designed and built with safety in mind.

However, your overall safety can be increased with proper

training and thoughtful operation on the part of the operator.

DO NOT operate or repair this equipment without reading

this manual and the important safety instructions shown

inside. Keep this operation manual near the lift at all times.

Make sure that ALL USERS read and understand this

manual.

400V 50Hz SUPPLY DETAILS ARE IN-

CLUDED WITH ELECTRICAL CONTROL

BOX. DISREGARD SUPPLY WIRING

DETAILS IN THIS MANUAL

EUROPEAN USERS

ORIGINAL INSTRUCTIONS IN

ENGLISH LANGUAGE

Keep this operation manual near the

machine at all times. Make sure that

ALL USERS read this manual.

LIFT WILL NOT STAY UP

POSSIBLE CAUSE

1. Air in oil, (1,2,3)

2. Check valve leaks, (6)

3. Cylinders leak internally, (7)

4. Lowering valve leaks, (4,5,1,7,6)

5. Leaking fittings, (8)

REMEDY INSTRUCTION

1. Check oil level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . The oil level should be up to the bleed screw in the

reservoir with the lift all the way down.

2. Oil seal damaged and cocked . . . . . . . . . . . . . . . . . . . . . . . . Replace oil seal around pump shaft.

3. Bleed cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Refer to Installation Manual.

4. Flush release valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hold release handle down and start unit allowing it to

run for 15 seconds.

5. Replace with new valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Replace with new valve.

6. Return unit for repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Return unit for repair.

7. See Installation Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Consult Lift Manufacturer.

8. Check complete hydraulic system for leaks. . . . . . . . . . . . . . .Tighten all hydraulics fittings and inspects all hoses.

Grease Port / Lubrication Locations

Lubricate

Once A Week

VALUES ARE STATED IN FOOT POUNDS (ft-lb)

SAE 0-1-2 SAE Grade 5 SAE Grade 8 SOCKET HEAD CAP SCREW

CLASS 4.8 CLASS 8.8 CLASS 10.9 CLASS 12.9

Bolt Size

(SAE)

Bolt Size

(Metric)

1/4-20 M6 x 1.0 6 10 14 13

5/16-18 M8 x 1.25 12 19 29 31.4

3/8-16 M10 x 1.50 20 33 47 62

7/16-14 32 54 78

1/2-13 M12 x 1.75 47 78 119 108

9/16-12 M14 x 2.00 69 114 169 173

5/8-11 M16 x 2.00 96 154 230 269

3/4-10 M18 x 2.50 155 257 380 372

7/8-9 M22 x 2.50 206 382 600 716

3/4 Anchor Bolts 75 MIN 110 MAX

Torque Recommendations
