Instruction Manual
Thank you for purchasing BOYA BY-MM1!
The BOYA BY-MM1 is a cardioid microphone, which,specially design to improve
the sound quality of videos on the basis of build-in microphones.
With both TRS cable and TRRS output cable included,it can be used on Smartphones,
cameras, camcorders, .audio recorders, PCs, and other audio/video recording devices.
BY-MM1 comes out in compact size and light weight aluminium constructure ,it will
not be a heavy burden while shooting.Plug and play design,no need to worry the
battery status. Included inside with an anti-shock mount, which can effectively reduce
unwanted vibration,cable and handling noise. Also included a furry windproof
shield,which specially used for minimizing the wind and environmental noise for
outdoor recording , make sure the sound crystal clear.
Features
Compact on-camera microphone
Compatible with smartphones, DSLR cameras, Consumer Camcorders,PCs etc
Rugged metal construction
No battery required
Professional furry windshield included
Specifications
Transducer: Electret Condenser
Polar pattern: Cardioid
Frequency Response: 35-18KHz +/-3dB
Sensitivity: -42dB +/-1dB/0dB=1V/Pa,1kHz
Signal to Noise Ratio: 76dB SPL
Plug: 3.5mm TRS and TRRS connector
Dimensions: Ф22* 81mm
Net Weight: 86g
Please read these instructions for use thoroughly before you use this new
equipment for the first time. It contains everything you need to know in order to
avoid damage to persons or property.
Strictly follow all notes on safety in these instructions for use.
Keep these instructions for use in a safe place. If you sell your equipment or pass
it on to someone else, you should also pass on these instructions for use.
1.Understanding these instructions for use correctly
1.1 Markings on the device
This symbol indicates,that your device meets the safety requirements of all
applicable EU-directives.
Waste disposal and protection of the environment
Electric and electronic appliances as well as batteries must not be disposed of together
with domestic waste.The user is legally obliged to return electric and electronic
appliances as well as batteries to specially set up public collecting points or the sales
outlet once they have reached the end of their service life.Details are regulated by
national law. The symbol on the product,the instructions for use or the packaging
refers to these provisions. The recycling, the material-sensitive recycling or any other
form of recycling of waste equipment/batteries is an important contribution to the
protection of our environment.
What’s included
①Furry windshield
②Microphone
③3.5mm audio jacket
④Shock mount
⑤3.5mm audio output cable
⑥3.5mm to TRS audio output cable
⑦3.5mm to TRRS audio output cable
What's difference?
①3.5 mm TRRS connector
-For Smartphone, tablet or Mac
②3.5 mm TRS connector
-For cameras,camcorders,audio recorders and other audio/video recording devices.
Using the microphone with a Smartphone,tablet or Mac.
1.Plug the 3.5 mm TRRS connector into the audio jack of your smartphone,tablet or
Mac.
2.Open the audio-only or video recording app and begin recording.
Using the microphone with cameras,camcorders,audio recorders and other
audio/video recording devices.
1.Lock the microphone on the camera hot shoe
2.Plug the 3.5 mm TRS connector into the audio input jack of your device (audio
recorder,amplifier,PC,laptop).
Specifications
Troubleshooting
If you have any problem using the BY-MM1components,use the following checklist.
If any problem persist, please consult our local dealer,or contact us directly at
sales @boya-mic.com.
Problem
Solution
The microphone can't
work
Make sure that using the correct audio connector.
1)For smartphone,tablet or Mac,using 3.5mm flexible cable.
2)For others devices,using 3.5mm straight cable.
Too much ambience
noise is being picked
up
Make sure that the microphone is as close as possible to the
subject.
A certain amount of ambient noise is unavoidable in loud
environments.
