Comtrol ROCKET LINX MP1204-XT Manuale utente
QUICK INSTALLATION GUIDE
2000641 Rev A | Release Date - November 2017
INTRODUCTION
The RocketLinx MP1204-XT is twelve port managed industrial switch that
provides:
• Eight 10/100/1000BASE-T PoE (802.3af/at) ports
• Four 100/1000 SFP ports
The MP1204-XT provides features needed for network control in an industrial
network environment. See the Comtrol website (www.comtrol.com) for
detailed product specicaons and the product warranty.
INSTALLATION OVERVIEW
You can use the following informaon to install the MP1204-XT. If you need
more detailed informaon, you can refer to the RocketLinx MP1204-XT User
Guide on the download site (hp://downloads.comtrol.com), which contains
detailed installaon and conguraon informaon.
Connect the Power Terminal Block
The MP1204-XT provides redundant
power inputs (PWR 1/2), which
supports reverse polarity protecon,
and accepts a posive or negave
powersource (12V – 57V). However,
PWR1 and PWR2 must apply to the
same mode.
Note: Power should be disconnected
from the power supply before
connecng it to the switch.
Otherwise, your screwdriver blade
can inadvertently short your
terminal connecons to the grounded enclosure.
1. Insert the posive and negave wires into PWR+ and PWR- contacts. You
can connect a single power supply or both power supplies depending on
your requirements.
2. Tighten the wire-clamp screws to prevent the wires from coming loose.
1
Electrical Specicaons Value
Power Input Voltage
PWR1/PWR2
IEEE 802.3af 46-57/3.1A (Max)
IEEE 802.3at 50-57VDC/5.2A (Max)
Maximum PoE
Power/Port
IEEE 802.3af 15.4W
IEEE 802.3at 30W
Power Budget PWR1/PWR2 240W
Power Consumpon
Without PD load (Max) 14W
PoE with PD load (Max)
IEEE 802.3af
IEEE 802.3at
265W with 240W PSE
2.92A @ 48VDC [134W]
4.89A @ 53VDC [247W]
ALARM RELAY AND GROUND
The alarm relay output contacts are in the middle of the DC terminal block
connector as shown in the gure below.
The alarm relay output is “Normal Open”, and it will be closed when detected
any predened failure such as power failures or Ethernet link failures.
The relay contacts have current carrying capacity of 0.5A @ 24 VDC.
ETHERNET INTERFACE
The switch provides two types of Ethernet interfaces: electrical (RJ45) and
opcal (SFP) interfaces.
2
Connecng RJ45 Cables
To connect the MP1204-XT to a PC, use straight-through or cross-over CAT 5
or higher Ethernet cables. To connect the MP1204-XT to an Ethernet device,
use UTP (Unshielded Twisted Pair) or STP (Shielded Twisted Pair) CAT 5 or
higher Ethernet cables.
The pin assignment of RJ45 connector is shown in the following gure and table.
Pin Assignment PoE Assignment
1,2 TxRx+ and TxRx- Posive Vport
3,6 TxRx+ and TxRx- Negave Vport
4,5 TxRx+ and TxRx- N/A
7,8 TxRx+ and TxRx- N/A
Connecng SFPs
The SFP accepts LC connector
ber transceivers and supports
both 100/1000 Mbps ber speed
connecons.
Comtrol recommends using Comtrol-approved SFP mini GBIC transceivers.
Note: Never aempt to view opcal connectors that might be eming laser
energy.
Do not power up the laser product without connecng the laser to the opcal
ber and pung the dust cover in posion, as laser outputs will emit infrared
laser light at this point.
Cross-connect the transmit channel at each end to the receive channel at the
opposite end as illustrated in the gure.
Aenon
This is a Class 1 Laser/LED product. Do not stare into the Laser/LED beam.
3
4
DIN RAIL MOUNTING
Use the following procedure to
mount the MP1204-XT on a DIN rail:
1. Screw the DIN clip with screws in
the accessory kit.
2. Hook the unit onto the DIN rail.
3. Push the boom of the unit
towards the DIN rail unl it locks
in place.
WALL MOUNTING
Use the following procedure to
mount the MP1204-XT on a wall or
panel:
1. Screw the wall-mount brackets
with screws in the accessory kit.
2. Mount it to a wall or panel.
CONSOLE CONNECTION
The Console port supports local management by using a terminal emulator
or a computer with terminal emulaon soware, such as puTTY. The console
port is located below the power connector.
• Baud rate: 115200bps
• Data bits: 8
• Stop bit:1
• Parity: None
• Flow control: None
Connect the RJ45 (male) connector to the MP1204-XT console port and
connect the RS-232 DB9 (female) connector cable to a COM serial port.
CONFIGURING THE IP ADDRESS
You can use the console port or a telnet connecon to congure the IP
address
5
Using Telnet to Congure the IP Address
You must have the MP1204-XT connected to your network.
1. Open the command prompt and enter telnet 192.168.250.250.
2. Enter admin as the
Username and press the
Enter key.
3. Enter admin as the
Password and press the
Enter key.
4. Enter enable and press the Enter key.
5. Enter congure terminal and press the Enter key.
6. Enter interface vlan 1 and press the Enter key.
7. Enter ip address ###.###.###.### ###.###.###.### (the IP address –
space – subnet mask) and press the Enter key.
8. Move the Ethernet cable to the appropriate network.
9. Close the telnet session.
10. Save the new IP address
to the ash, enter telnet
and the new IP address.
11. Enter the Username and
Password.
12. Enter copy running-
cong startup-cong and press the Enter key.
You can now open the MP1204-XT web interface to congure it to your
environment.
Using the Console Port to Congure the IP Address
Connect the console cable as previously described. The following example
illustrates using puTTY.
6
1. Start the terminal emulaon soware and congure the port as
previously described.
2. You may need to press Enter to get the Username prompt.
3. Enter admin as the Username and press the Enter key.
4. Enter admin as the Password and press the Enter key.
5. Enter enable and press the Enter key.
6. Enter congure terminal
and press the Enter key.
7. Enter interface vlan 1 and
press the Enter key.
8. Enter ip address
###.###.###.###
###.###.###.### (the IP
address – space – subnet
mask) and press the Enter
key.
9. Enter exit and press the
Enter key
10. Enter exit and press the Enter key.
11. Enter copy running-cong startup-cong and press the Enter key.
You can now open the MP1204-XT web interface to congure it for your
environment
COMTROL CUSTOMER SERVICE
You can use one of the following methods to contact Comtrol.
Contact Method Web Address or Phone Number
Support hp://www.comtrol.com/support
Downloads hp://downloads.comtrol.com
Website hp://www.comtrol.com
Phone +1 763.957.6000
7
