Creality HALOT-LITE Manuale utente

HALOT-LITE

3D Printer User Manual

V1.4

HALOT-LITE

CREATE REALITY，ACHIEVE DREAMS

Dear Consumers,

Firmware Upgrade

Please login the oﬃcial website https://www.creality.com/download, switch the language and select the relevant printer and

model and download the required ﬁrmware, you can use it after the installation is ﬁnished.

Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our

teams will always be ready to render you the best services. Please contact us via the phone number or e-mail address

provided at the end when you encounter any problem with the Printer. For a better experience in using our product,

you can also learn how to use the printer in the following ways:

View the accompanied instructions and videos in the U disk.

Visit our oﬃcial website www.creality.com to ﬁnd relevant software/hardware information,contact details and operation and

maintenance instructions.

NOTES

Do not use the printer any way other than described here in order to avoid personal injury or property damage.

Do not place the printer near any heat source or ﬂammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.

Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.

Please use recommended resin to in case damage of machine.

Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.

Please do not open the plastic cover during usage, otherwise the printing will be interrupted.

Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.

Please wait a moment after the print is ﬁnished. And please wear gloves to take out the print by tools.

Children under 10 years should not use the printer without supervision.

Tips：Do not plug or unplug the power cord when power on.

Clean the printer frequently. Always turn the power oﬀ when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material oﬀ the frame,

guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.

Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety

obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any circustance.

Contents

Introduction 01-01

Parameters 02-02

Parts List 03-03

04-09

Use the 3D Printer

10-12

Start Printing

14-14

Wiring Connection

13-13

15-17

Troubleshooting

Control remote printing

Hexalobular socket screw

Resin vat

Touch screen

9USB port

Power socket

Limit switch

Protective cover

Hexalobular socket screw

Leveling screw

Buliding platform

1. Introduction

2.Equipment parameters

Model Name HALOT-LITE

USB Disk, Creality Cloud

3840*2400

0.05mm

1-4S/layer

250W

330*301*572mm

425*393*685mm

13.5KG

5 inch touch screen

Common rigid photosensivie resin, Standard resin, Hight hardness,High toughness, Dental model resin.

Integral light source (wavelength 405nm)

Win7/Win8/Win 10 64bit, Mac system (32-bit is not supported)

192*120*200mm（length,width and height）

Slicing Software Operation System

Rated Power

Build Size

Touch Screen

Machine Size

Package size

Gross Weight

Machine Language

Print Method

Print speed

Compatible Resin

Rated Voltage

Light Source Type

XY Axis Resolution

XY Axis Accuracy

Basic Parameters

100-240Va.c, 50/60Hz

10.6KGNet Weight

中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어

Layer Thickness 0.01-0.2mm

3. Package Content

Print platform x 1 Resin vat x 1 3D printer x 1

Screwdrivers x 1set

Tool list

U disk x 1 Plastic blade x 1

Metal blade x 1 Release ﬁlm x 1

Brush x 1

Resin ﬁlter x 4 Power cord x 1

9Vat cover x 1

Tips: the above accessories are for reference only, in kind prevail!

10 Calibration card x 1

Calibration Card

校准卡片

4. Interface Information

Note: The current interface is for reference only, due to the continuous upgrading

of functions, the actual to the oﬃcial website of the latest ﬁrmware UI as the standard.

4. Interface Information

Note: The current interface is for reference only, due to the continuous upgrading

of functions, the actual to the oﬃcial website of the latest ﬁrmware UI as the standard.

Setting

5. Level Platform

1. To calibrate the printing platform, ﬁrst raise the platform, loosen the

ﬁxing screws on the left and right sides of the material trough, and

take out the material trough;

2. Loosen the four Leveling screw

of the prototyping platform, attach Calibration

card tightly to the print screen, press

Settings → Z Axis Motion → Levelling（Refer

to operating steps of levelling platform 2 for

operation.）, to check whether the platform

ﬁts evenly with the paper.

3. After conﬁrming that Calibration card

ﬁts evenly with the platform, screw up

the four screws of the platform.

Note: The printing platform has been leveled at the factory. If it needs leveling due to transportation or other reasons, please follow the steps

below to adjust the printing platform.
