Cross Technologies 2117-7172 Manuale utente

Instruction Manual

Model 2117-7172

Up/Downconverter

November 2019, Rev. 0

MODEL 2117

CROSS TECHNOLOGIES INC.

EXT

10MHZ POWERALARM

UP/DOWNCONVERTER

Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,

but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.

for purposes of operating the equipment.

When ordering parts from Cross Technologies, Inc., be sure to include the equipment

model number, equipment serial number, and a description of the part.

CROSS TECHNOLOGIES, INC.

6170 Shiloh Road

Alpharetta, Georgia 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

INSTRUCTION MANUAL

MODEL 2117-7172 Up/Downconverter

TABLE OF CONTENTS PAGE

Warranty 2

1.0 General 3

1.1 Equipment Description 3

1.2 Technical Characteristics 4

2.0 Installation 5

2.1 Mechanical 5

2.2 Front & Rear Inputs and Outputs 6

2.3 Available Options/Pinouts 7

2.4 Installation/Operation 8

2.5 Use Information 9

WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.

All Cross Technologies, Inc. products are warranted against defective materials and

workmanship for a period of one year after shipment to customer. Cross Technologies,

Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s

option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall

not be liable for any special, indirect, or consequential damages. This warranty does not

cover parts or equipment which have been subject to misuse, negligence, or accident by the

customer during use. All shipping costs for warranty repairs will be prepaid by the

customer. There are not other warranties, express or implied, except as stated herein.

CROSS TECHNOLOGIES, INC.

6170 Shiloh Road

Alpharetta, Georgia 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

2117-7172 Manual Page 2 11/14/19

MODEL 2117-7172 Up/Downconverter

1.0 General

The 2117-7172 Up/Downconverter converts 1.95 - 2.05 GHz to 7.15 - 7.25 GHz and 7.15-7.25 GHz to 1.55 -

1.65 GHz, with non-inverting spectrums. Front panel LEDs provide indication of DC Power, External 10 MHz,

and PLL Alarm. The gain is +20 dB for the upconverter and -20 dB for the downconverter. Connectors are

Type N female for the RF output and input, BNC female for the L-band input and output and external reference

input and reference output. A three-way switch controls which 10 MHz reference is being used. In the AUTO

position, the internal reference is used unless a +3 dBm ± 3 dB, 10MHz reference signal is connected to the

external reference input. The 2117 is powered by a 100-240 ± 10% VAC power supply, and in a 1 3/4” X 19” X

19” rack mount chassis.

MODEL 2117

CROSS TECHNOLOGIES INC.

EXT

10MHZ POWERALARM

UP/DOWNCONVERTER

FRONT PANEL

GND

EXT REF

IN REF

OUT

INT EXTAUTO

S1 J112

J11

MONITOR

AND

CONTROL

15 234 6

J111

RF2 IN RF2 OUT

J102J101

RF1 OUT RF1 IN

DOWNCON UPCONV

REAR PANEL

FIGURE 1.1 Model 2117-7172 Front and Rear Panels

2117-7172

Up/Dowconverter

Block Diagram

10 MHz

To PLLs

EXT 10 M

10 M

MON

1.95 to 2.05

GHz IN

RF2 In

7.15 to 7.25 GHz BP 2.05 GHz LP

7.15 to 7.25

GHz OUT

RF2 Out

5.20 GHz

7.15 to 7.25

GHz IN

RF1 In

1.55 to 1.65

GHz OUT

RF1 Out

7.15 to 7.25 GHz BP

5.60 GHz

1.65 GHz LP

Upconverter

Dowconverter

ATT. ATT.

FIGURE 1.2 Model 2117-7172 Up/Downconverter Block Diagram

2117-7172 Manual Page 3 11/14/19

1.2 Technical Characteristics

TABLE 1.0 2117-7172 Up/Downconverter Specifications*

EQUIPMENT SPECIFICATIONS*

SPECIFICATIONS*

Input

Input Characteristics

DOWN

Impedance/Return Loss 50Ω/14 dB 50Ω/14 dB

Frequency 1.95-2.05 GHz 7.15-7.25 GHz

Noise Figure, Max. 20 dB @ max gain 25 dB @ max gain

Input Level range -40 to -20 dBm -20 to 0 dBm

Output

Output Characteristics

Impedance/Return Loss 50 Ω/14 dB 50 Ω/14 dB

Frequency (GHz) 7.15-7.25 GHz 1.55-1.65 GHz

Output Level Range -20 to 0 dBm -40 to -20 dBm

1 dB comp, max gain +10 dBm -10 dBm

Mute @ 0 dBm out >50 dB N/A

Channel

Channel Characteristics

Gain, max. at Fc, fixed +20 ±2 dB -20 ±2 dB

Image Rejection >60 dBC >60 dBC

Spurious, Inband, sig. rel. <-50 dBC, 0dBm <-50 dBC, -5dBm

Spurious, Inband, sig. ind. <-50 dBC, Gmax <-50 dBC, Gmax

urious, Out of band

<-50 dBm, Gmax <-50 dBm, Gmax

2 tone 4MHz; Max -10 ea <-50 dBC,Gmax <-50 dBC,Gmax

Frequency Resp. band ±1.5 dB ±1.5 dB

Frequency Resp. 40 MHz ± 0.5 dB ± 0.5 dB

Frequency Sense non-inverting non-inverting

LO Characteristics

LO Frequency Downconverter -5.60 GHz; Upconverter - 5.20 GHz

Frequency Accuracy ± 0.01 ppm max over temp internal reference; external reference input

10 MHz Level +3 dBm, ± 3dB, 75 ohms, External In or Internal out

-110-100-85-80-70

1MHz100kHz10kHz1kHz100 MHz

dBC/Hz

Phase Noise

Fre

(

)

Controls, Indicators

INT/AUTO/EXT Switch Selects internal or external 10 Mhz (rear panel DP3T switch)

Ext 10 MHz Yellow LED, indicates external 10 MHz reference selected

PLL Alarm Red LED, External contact closure

Power Green LED

Other RF1 In, RF2 Out N-Type (female), 50Ω

RF1 Out, RF2 In BNC, 50Ω, female (see TABLE 2.2 for other options)

10 MHz Connectors BNC (female), 75Ωconnector; works with 50Ωor 75Ω

Alarm Connector DB9, female - NO or NC contact closure on Alarm

Size 19 inch Standard Chassis 1.75”high X 14.0” deep

Power 100-240 ± 10% VAC, 47-63 Hz, 50 watts maximum

Options

Connector Options See TABLE 2.2

*+10˚C to +40˚C; Specifications subject to change without notice.

2117-7172 Manual Page 4 11/14/19

2.0 Installation

2.1 Mechanical - The 2117-7172 consists of one RF PCB housed in a 1 RU (1 3/4 inch high) by 14 inch deep

chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assemblies. The 2117-7172 can

be secured to a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2117-7172 is assembled.

PS IN

PIN 1, +12 VDC

PIN 2, +5 VDC

PIN 3, +5 VDC

PIN 4, GROUND

PIN 5, GROUND

PIN 6, -12 VDC

PIN 7, +24 VDC

PIN 8, +24 VDC

POWER

SUPPLY

FIGURE 2.0 2117-7172 Mechanical Assembly

2117-7172 Manual Page 5 11/14/19

2.2 Rear Panel Input/Output Signals - Figure 2.1 shows the input and output connectors on the rear panel.

INT AUTO EXT

GND

J102

AND

MONITOR

CONTROL

J2 - EXT 10 MHz INPUT

BNC (Female), 75Ωinsert

external 10 MHz reference

here

(

dBm

± 3 dB)

J11 - ALARM

DB9 (Female)

connector.

See table 2.1

5 23

J14 - Ethernet Connection

RJ45 Ethernet Connector

(option -W8, 18, W28).

J8-10 MHz OUTPUT

BNC (Female), 75Ω

J101- RF1 OUTPUT

BNC (Female), 50Ω

1.55 to 1.65 GHz

-40

-20

dbm

nal

J102 - RF1 IN

N-Type Female, 50Ω

7.15 to 7.25 GHz

-20 to 0 dbm max. signal

J112-RF2 OUT

N-Type Female, 50Ω

7.15 to 7.25 GHz,

-20 to 0 dBm max signal.

See table 2.2 for other

connection options.

J14 S1

S1 - 10MHz SWITCH

3 position switch INT selects 10MHz

ref. Auto selects internal10MHZ ref.

unless a 0 dBm ± 3 dB 10 MHz

signal is inserted on J2 EXT selects

external

10MHz

reference

from

J2.

J2 J101 J111 UPCON

J112

J111-RF2 IN

1.95 to 2.05 GHz

-40 to -20 dbm

max

nal

RF2 IN

RF2 OUT

J11

RF1 IN

DOWNCON

J102

RF1 OUT

EXT REF

IN RF

OUT

AC INPUT

100-240 VAC, 47-60 Hz

Uses 2 amp Slow Blo,

5mm

fuse.

Shown below (Option P48) - Rear Panel Input/Output Signals

with Option P48, 48 VDC nominal 36-72 VDC, 2.5A maximum.

INT AUTO EXT

GND

J102

AND

MONITOR

CONTROL

5 23

36 TO 72 VDC

• •

•

DC INPUT

J14 S1

J2 J101 J111 UPCON

J112

RF2 IN

RF2 OUT

J11

RF1 IN

DOWNCON

J102

RF1 OUT

EXT REF

IN RF

OUT

DS2 - ALARM LED

Lights RED when PLL

comes out of lock.

DS1 - POWER LED A

Lights GREEN when DC voltage is

present from AC power supply.

DS3 - EXT 10MHZ LED

Lights YELLOW when external

10MHz reference is active.

POWER

EXT

10MHZ ALARM

FIGURE 2.2 2117-7172 Front Panel Controls and Indicators

2117-7172 Manual Page 6 11/14/19

TABLE 2.1 JJ11

TABLE 2.1 J11 Pinouts (DB9)

Pin Function

1 Not Used

2 Not Used

3 Not Used

4 Not Used

5GND

6 Alarm Relay: Common

7 Alarm Relay: Normally Open

8 Not Used

9 Alarm Relay: Normally Closed

TABLE 2.3 DDC1

TABLE 2.3 DC1 Pinouts

Pin# Function

1 Minus DC input

2NC

3 Plus DC input

4NC

Shell Ground

FIGURE 2.1 2117-7172 Rear Panel I/Oʼs FIGURE 2.3 2117-7172 DC1 Pinouts

TABLE 2.2 Available Options

P48 = 48 V DC Power Supply

R = Redundant AC Power Supply

Available Connector Options

NF 50ΩN-Type (RF), 75ΩF-Type (L-Band)

N50ΩN-Type (RF), 75ΩBNC (L-Band)

NN 50ΩN-Type (RF), 50ΩN-Type (L-Band)

SS 50ΩSMA (RF), 50ΩSMA (L-Band)

FIGURE 2.2 2117-7172 Available Options

AC Fuse - 2 amp slow blow (Type T),

5 mm X 20 mm

FUSE DRAWER

SPARE FUSE

INPUT

100-240± 10%VA

47-63 Hz

2A MAX

FUSE

TYPE T 2A GDC

250 VOLT

FOR 100 - 240 V~

FIGURE 2.3 Fuse Location and Spare Fuse

2117-7172 Manual Page 7 11/14/19

2.4 Installation / Operation

2.4.2 Installing and Operating the 2117-7172 Downconverter

1.) Connect a -20 dBm to -0 dBm signal to RF1 7.15 to 7.25 GHz INPUT, J102 (Figure 2.1).

2.) Connect the, RF1 OUT, J101 to the external equipment.

3.) Connect 100-240 ± 10% VAC, 47 - 63 Hz to AC connector on the back panel.

4.) Be sure DS1 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.2).

5.) Select either INT (for internal 10MHz ref), AUTO (for internal 10MHz ref UNLESS a external

10MHz, 0 dBm signal is connected to J2), or EXT (for external 10MHz, 0 dBm ref that is inserted

at J2) on rear panel switch S1 (Figure 2.1).

6.) If EXT is selected or AUTO is selected and there is a 10MHz, 0 dBm signal at J2,

check that DS3 (yellow, Ext 10 MHz) is on (Figure 2.2).

7.) Check that a 10MHz, 0 dBm ±3 dB signal is present at the 10 MHz REF OUTPUT (J8)

(Figure 2.1).

8.) AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot

in the drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot.

If a fuse continues to open, the power supply is most likely defective.

2.4.3 Installing and Operating the 2117-7172 Upconverter

1. Connect 1.95 to 2.05 GHz -40 dBm to -20 dBm signal to RF2 IN, J111 (Figure 2.1).

2. Connect the RF2 OUTPUT, J112, to the external equipment.

3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC connector on the back panel.

4. Be sure DS1 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.2).

5. Select either INT (for internal 10MHz ref), AUTO (for internal 10MHz ref UNLESS a external 10MHz,

3 dBm signal is connected to J2), or EXT (for external 10MHz, 3 dBm ref that is inserted at J2) on rear

panel switch S1 (Figure 2.1).

6. If EXT is selected or AUTO is selected and there is a 10MHz, 3 dBm signal at J2, check that DS3

(yellow, Ext 10MHZ) is on (Figure 2.2).

7. Check that a 10MHz, 3 dBm ±3 dB signal is present at the 10MHZ REF OUTPUT (J8) (Figure 2.1).

8. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot in the

drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot. If a fuse

continues to open, the power supply is most likely defective.

Use Information

2117-7172 Manual Page 8 11/14/19

A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions

located in the user manual furnished by the manufacturer of your equipment rack.

B. Mechanical Loading - Mounting of equipment in a rack should be such that a hazardous condition

does not exist due to uneven weight distribution.

C.Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly,

the operating ambient temperature of the rack may be greater than room ambient temperature.

Therefore, consideration should be given to Tmra. (Maximum Recommended Ambient Temperature)

D. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow

required for safe operation of the equipment is not compromised. Additional space between units

may be required.

E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply

circuit and the effect that overloading of circuits could have on over current protection and supply wiring.

Appropriate consideration of equipment name plate rating should be used when addressing this concern.

F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.

Particular attention should be given to supply connections other than direct connection to the

Branch (use of power strips).

G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.

If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED

prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS

emission problems.

2117-7172 Manual Page 9 11/14/19

CROSS TECHNOLOGIES, INC.

6170 Shiloh Road

Alpharetta, Georgia 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

2117-7172 Manual Page 10 11/14/19

Indice

Altri manuali Cross Technologies Convertitore multimediale

Cross Technologies

Cross Technologies 2017-0923 370 Series Manuale utente

Cross Technologies

Cross Technologies 2005-10 Manuale utente

Cross Technologies

Cross Technologies 2015-58T Manuale utente

Cross Technologies

Cross Technologies 2115-275-1845 Manuale utente

Cross Technologies

Cross Technologies 2016-03A Manuale utente

Cross Technologies

Cross Technologies 4116-285-2450 Manuale utente

Cross Technologies

Cross Technologies 2115-122 Manuale utente

Cross Technologies

Cross Technologies 4116-31-2831 Manuale utente

Cross Technologies

Cross Technologies 2016-26 Manuale utente

Cross Technologies

Cross Technologies 3116-145-1600 Manuale utente

Cross Technologies

Cross Technologies 2116-182193 Manuale utente

Cross Technologies

Cross Technologies 2016-75-213 Manuale utente

Cross Technologies

Cross Technologies 2116-21-1014 Manuale utente

Cross Technologies

Cross Technologies 2017-03 Manuale utente

Cross Technologies

Cross Technologies 1584-29 Manuale utente

Cross Technologies

Cross Technologies 2415 0925 Series Manuale utente

Cross Technologies

Cross Technologies 2009-2425-1750 Manuale utente

Cross Technologies

Cross Technologies 3117-3338 720 Series Manuale utente

Cross Technologies

Cross Technologies 4117-14 Manuale utente

Cross Technologies

Cross Technologies 4116-31-184 Manuale utente

Cross Technologies

Cross Technologies 2016-05A Manuale utente

Cross Technologies

Cross Technologies 2005 Manuale utente

Cross Technologies

Cross Technologies 2017-03A Manuale utente

Cross Technologies

Cross Technologies 4115-300 Manuale utente

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
