INSTRUCTION BOOKLET

For your safety and continued enjoyment of this product, always read the instruction book carefully before using.

CUISINART JUICE EXTRACTOR JEX-450A

26675 JEX-450A IB 23/6/08 11:59 AM Page 1

CONTENTS

Important Unpacking/Repacking Instructions . . . . . . . . 1–2

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Assembling Your Cuisinart Juicer . . . . . . . . . . . . . . . . . . . 7

Disassembling Your Cuisinart Juicer . . . . . . . . . . . . . . . . . 8

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Thermal Protector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Care and Cleaning/Troubleshooting Guide . . . . . . . . . . .11

Tips on Juicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Vegetables and their Vitamin and Mineral Content . . . . . 16

Fruits and their Vitamin and Mineral Content . . . . . . . . . 17

Recipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

IMPORTANT UNPACKING

INSTRUCTIONS

Caution: The filter basket/shredder disc has sharp edges.

Handle carefully.

1. Place the box on a large, sturdy, flat surface.

2. Remove the instruction book and any other literature.

3. Put one hand on each side of the Styrofoam®inserts

and carefully lift the Styrofoam®inserts out of the box.

4. Separate Styrofoam®inserts to remove components.

5. Remove unit base, top cover, pulp container, juice cup

and pusher from Styrofoam®mold.

6. Remove top cover of juice extractor. Carefully remove

all protective shipping material.

Keep all plastic bags away from children.

26675 JEX-450A IB 23/6/08 11:59 AM Page 2

REPACKING INSTRUCTIONS

1. Place filter basket/shredder disc inside of filter bowl.

2. Place filter bowl and juice cover onto motor housing.

Lock juice cover into place by turning left to right.

3. Insert motor housing, top cover and pulp container into

Styrofoam®insert.

4. Place food pusher and juice cup into Styrofoam®insert.

5. Place empty Styrofoam®insert over insert holding

components.

6. Put one hand on each side of the Styrofoam®inserts

and place contents into box.

7. Close box cover.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions

should always be followed, including the following:

1. READ ALL INSTRUCTIONS.

2. Always use the appliance on a dry, level surface.

3. Do not push produce into the feed chute with your

fingers. Always use the food pusher provided.

4. Do not touch the small cutting blades in the base of

the stainless steel filter basket.

5. Do not leave the juice extractor unattended when in

use. Close supervision is necessary when this

appliance is being used near children. Do not allow

children to use this appliance.

6. Always make sure the juice extractor is properly and

completely assembled before operating. The unit will

not turn on unless properly assembled.

7 . Always disconnect the juice extractor from the power

outlet when not in use or when assembling.

8. Always make sure juice extractor cover is securely in

place before motor is turned on. Be sure to turn switch

26675 JEX-450A IB 23/6/08 11:59 AM Page 3

to off position after each use for your juicer. Make sure

the motor stops completely before dissembling.

9. Do not put your fingers or any other object into the

juicer opening while it is in operation. If food becomes

lodged in opening, use food pusher or another piece of

fruit or vegetable to push it down. When this method is

not possible turn the motor off and disassemble juicer

to remove the remaining food.

10. Do not operate any electrical appliance with a

damaged cord or plug or after the appliance has

malfunctioned or been damaged in any manner.

If damaged, immediately stop use and call Cuisinart

Customer Service at 1800 808 971 (AUST) or

0800 435 000 (NZ) for examination, adjustment

or repair.

11. Do not immerse power cord or motor base in water or

any other liquid.

12. Do not let the cord hang over the edge of the table or

counter, or touch hot surfaces or become knotted.

13. Do not place this appliance on or near a hot gas or

electric burner, or where it could touch a heated oven.

14. Always turn appliance off at the power point and

remove cord

- if the appliance is left unattended

- if not in use

- before cleaning

- before attempting to move the appliance

15. For any maintenance other than cleaning call

1800 808 971 (AUST) or 0800 435 000 (NZ).

16. This appliance has a 3-prong grounded plug .

To reduce the risk of electric shock, this plug is

intended to fit into a grounded outlet only one way.

If the plug does not fit, contact a qualified electrician.

Do not attempt to modify the plug in any way.

26675 JEX-450A IB 23/6/08 11:59 AM Page 4

17. To protect against risk of electrical shock do not

put motor, unit housing and power cord in water or

other liquid.

18. Unplug from outlet when not in use, before putting

on or taking off parts, and before cleaning.

19. Avoid contacting moving parts.

20. The use of attachments not recommended or sold by

the manufacturer may cause fire, electric shock or injury.

21. Do not use outdoors.

22. Always make sure juicer cover is clamped securely in

place before motor is turned on. Do not unfasten

clamps while juicer is in operation.

23. Be sure to turn switch to OFF position after each use

of your juicer. Make sure the motor stops completely

before disassembling.

24. Do not use the appliance if the rotating sleeve is damaged.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

SAVE THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

GROUNDING INSTRUCTIONS

This appliance must be grounded while in use to protect the

operator from electrical shock. The appliance is equipped

with a 3-conductor cord and 3-prong grounding-type plug to

fit the proper grounding-type receptacle.

26675 JEX-450A IB 23/6/08 11:59 AM Page 5

GROUNDING METHOD

EXTENSION CORDS

Use only 3-wire extension cords which have 3-prong

grounding-type plugs and 3-pole cord connectors that accept

the plug from the appliance. Use only extension cords which

are intended for indoor use. Use only extension cords having

an electrical rating not less than the rating of the appliance.

Do not use damaged extension cords. Examine extension

cord before using and replace if damaged. Do not abuse

extension cord and do not yank on any cord to disconnect.

Keep cord away from heat and sharp edges.

INTRODUCTION

Raw juices derived from fresh fruits and vegetables are

invaluable as an aid in maintaining a balanced diet.

Raw juice contains, in its most natural and complete form,

precious vitamins, minerals, bioflavonoids and enzymes.

Nutritional authorities claim that raw juice is food in one of

its most easily digestible forms.

Be sure to use your Cuisinart Juicer daily, or as often as

you can manage, in the manner recommended in this

instruction manual.

Because of the cleansing and rebuilding properties

contained in juices, it is recommended that you use juices

in small amounts in the first week and then gradually

increase amounts as you can comfortably enjoy them.

We recommend that juices be taken alone, between meals,

and at room temperature – not with meals.

This Cuisinart Juicer is the result of intensive research and

engineering efforts, and we are sure you will be delighted

with its performance.

26675 JEX-450A IB 23/6/08 11:59 AM Page 6

PARTS

1. Food Pusher

2. Extra-Wide Feed Chute

3. Top Cover

4. Stainless Steel

Filter Basket and

Shredder Disc

5. Filter Bowl

6. Motor Housing

7. Pulp Container

10-Cup Capacity

(dishwasher-safe)

8. Pulp Container Lip

9. Lo/Off/High Toggle

Switch

10. Juice Collector Cup

and Cover

11. Froth/foam separator

(ensures juice froth is

separated from juice

when poured into glass)

12. Rest Button (not shown)

located under unit base

26675 JEX-450A IB 23/6/08 11:59 AM Page 7

Assembling Your Cuisinart Juicer

NOTE: The juice extractor will not operate

until the pulp container is locked into

position. To assemble this unit the

following steps must be followed in the

order given.

Step 1

Place filter bowl on top of the motor

housing.

Step 2

Place the stainless steel filter basket

inside the centre of the filter bowl. Make

sure it snaps into hub. Press firmly on the

stainless rim of the filter basket. To avoid

injury do not press on shredder disk.

Note: Before switching the juicer on,

ensure the stainless steel filter basket is

pushed down firmly until it clicks into place.

Step 3

Place the Juicer top cover over the

top of the motor housing by positioning

it over the centre of the filter and lower

into position.

Step 4

Lock juice cover into place by turning

left to right (counterclockwise) until cover

locks into position. Follow instructional

arrows on top cover.

Step 5

Slide the food pusher down the feed chute

by aligning the flat area of the food pusher

with the flat area of the feed chute. Food

pusher is marked with an arrow for easy lineup.

Continue to slide the food pusher down the feed chute.

Step 1 and 2

Step 3

Step 4

Step 5

26675 JEX-450A IB 23/6/08 11:59 AM Page 8

Step 6

Place the pulp container into position by grasping the lip

of the pulp container with one hand and tilting the pulp

container slightly. Place under top cover until it locks

into position.

Step 7

Place the juice collector cup provided under the spout of the

filter bowl.

Disassembling Your Cuisinart Juicer

Step 1

Turn the Cuisinart Juicer toggle switch to the off position.

Remove the plug from the power outlet.

Step 2

Remove juice cup.

Step 3

Remove the pulp container by tilting slightly to remove from

base.

Step 4

Remove the lid by twisting right to left (clockwise) as far as it

will go to disengage then lift up cover.

Step 5

Remove stainless steel filter basket and filter bowl at the

same time by holding onto the filter bowl spout and pulp

container lip while putting pressure with your thumbs on

the top rim of housing and pulling gently in an upward

motion. For best cleaning results, we recommend

cleaning the filter basket with a nylon cleaning brush.

THE STAINLESS STEEL FILTER BASKET

CONTAINS SMALL SHARP BLADES TO CUT AND

PROCESS FRUITS AND VEGETABLES.

DO NOT TOUCH BLADES WHEN HANDLING THE

FILTER BASKET.

26675 JEX-450A IB 23/6/08 11:59 AM Page 9

Step 6

To remove the stainless steel filter basket, lift up from

juicer bowl.

Caution: Sharp blades

OPERATION

Note: The juice extractor will not operate until the pulp

container is locked into position. See page 8.

Step 1

Wash your selection of fruit and vegetables for juicing.

Note: Most fruit and vegetables such as apples, carrots and

cucumbers will not need to be cut to size as they will fit into

the feed chute whole.

Step 2

Ensure that the Juicer is correctly assembled and

that the juice collector cup is placed under the spout

while juicing.

Step 3

Plug the power cord into a power outlet. For softer fruits

and vegetables such as melons, spinach, pears, etc., use

the low setting. For harder fruits and vegetables such as

carrots, beets, cabbage, etc., use the high setting.

Toggle to the low or to the high position depending on the

fruit or vegetable being processed. Toggle to the off position

when process is completed.

Step 4

With the motor running place food down the feed chute.

Using the food pusher, gently guide food down the chute.

To extract maximum juice always push the food pusher

down slowly. Make sure flat area of food pusher is aligned

to flat area of feed chute. The food pusher is marked with

an arrow for easy lineup.

26675 JEX-450A IB 23/6/08 11:59 AM Page 10

Indice

Altri manuali Cuisinart Elettrodomestico da cucina

Cuisinart

Cuisinart IB-5239A Manuale operativo

Cuisinart

Cuisinart CSB-78 - Cordless Rechargeable Hand Blender Manuale di installazione e funzionamento

Cuisinart

Cuisinart PrepExpress SPI-50 Manuale di servizio

Cuisinart

Cuisinart TOA-70 Series Manuale utente

Cuisinart

Cuisinart PE-50C Manuale di servizio

Cuisinart

Cuisinart Hot Air Popcorn Maker CPM-100 Series Manuale di servizio

Cuisinart

Cuisinart WM-SW2N1 Series Manuale di servizio

Cuisinart

Cuisinart Smart Stick CSB-400CD Manuale utente

Cuisinart

Cuisinart CPC-900XA Manuale utente

Cuisinart

Cuisinart CCM-150C Manuale di servizio

Cuisinart

Cuisinart PartyPop CPM-800 Manuale di servizio

Cuisinart

Cuisinart CSB-85C Manuale di servizio

Cuisinart

Cuisinart CSB-78C Manuale utente

Cuisinart

Cuisinart CWO-240WS Manuale utente

Cuisinart

Cuisinart CPM-32 Series Manuale utente

Cuisinart

Cuisinart Griddler Five GR-5 Series Manuale di servizio

Cuisinart

Cuisinart PROFESSIONAL Series Manuale utente

Cuisinart

Cuisinart CWA-100C Manuale utente

Cuisinart

Cuisinart GR030E Manuale utente

Cuisinart

Cuisinart GRSM1U Manuale utente

Cuisinart

Cuisinart CTG-00-SSC Manuale di servizio

Cuisinart

Cuisinart Smart Stick CSB-77 Manuale operativo

Cuisinart

Cuisinart WM-SW2N1 Series Manuale utente

Cuisinart

Cuisinart SMS-216 Series Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
