CYP PU-1106 Manuale utente

PU-1106

HDMI v1.3 to CAT6

Transmitter & Receiver

with IR return control

Operation Manual

PU-1106

Safety Precautions

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

 Always follow basic safety precautions to reduce the risk of

fire, electrical shock and injury to persons.

 To prevent fire or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

 Never spill liquid of any kind on or into this product.

 Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.

 Do not attach the power supply cabling to building surfaces.

 Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.

 To protect the equipment from overheating, do not block the

slots and openings in the module housing that provide

ventilation.

Revision History

Version No Date Summary of Change

V1 20091020 Preliminary Release

Table of Contents

1. Introduction ……………………..……………………...…........….…….

2. Applications …………………..………………….……...................…..

3. Package Contents ………………………...........……….................…

4. System Requirements ……………..……….........………............…….

5. Features …………………………………………......……........…...……

6. Speciﬁ cations ………………………………...……..........………....….

7. Operation Controls and Functions ……………...……..............……

7.1 Front Panel ..............................................................................

7.2 Rear Panel .…………………………………..…….......…...….…

8. Pin Assignment .............................……………..........…......…....…...

8.1 IR Cable Pin Assignment .......................................................

8.2 RJ-45 Pin Deﬁ nitions ................................................................

10. Connection and Installation ….………………….........…..…..…......

11. Acronyms …......................................................................................

1. Introduction

The HDMI 1.3 transmitter and receiver over CAT6 is an extension tool for your

long distance HDMI display needs. Instead of using expensive HDMI cables,

your existing CAT6 cables/sockets can replace HDMI cables while performing

the same functions like transfer Deep Color (12 bits/color) video and new

lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master

Audio) Digital audio, at a bandwidth of up to 225MHz. Moreover, user can

use the existing remote control to control the source and cascade with multi

sets of this device to reach a extrem of the distance. This HDMI 1.3 Transmitter

and receiver is your ideal choice when looking for a HDMI extender.

2. Applications

 Showroom display & control

 Window display & control

 Home or individual display & control

 Hyper market display & control

 Lecture room display & control

3. Package Contents

 HDMI 1.3 Transmitter x 1

 HDMI 1.3 Receiver x 1

 IR Eye Receiver cable x 1

 IR Eye Blaster cable x 1

 5V DC power supply adaptor x 2

 Operation Manual x 1

4. System Requirements

HDMI input source equipment, output HDMI displayer, two CAT6 cables and

source equipment’s remote control.

5. Features

 Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards

 Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/

color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio) Digital audio

 Supports CAT-6 cables for data/DDC transmission

 Supports equalize and recover incoming TMDS data before

re-transmitting them with optimal quality regardless of the incoming

signal quality

 Supports high definition resolution, the HDMI cable distance test with

1080p/8bits & 12bits resolution the Input/Output can reach up to

15/15 meters. With CAT6 cable, distance test with 1080p/8bits & 12bits

resolution the Input/Output source can run up to 45/20 meters

Note:

A. Cable tested with CAT-6E / 23AWG / Solid and therefore, cable with

different specification may result in different distance.

B. Cable distance tested with equipment PS3 40G, 37" Philips 8 bit LCD

TV and 37" SamSung 12 bit LCD TV.

C. Figures provided in this manual are reference figures only, actual

figures may depend on source and display use with cable

specification.

 Supports CEC bypass

 Supports xvYCC

 Supports IR Receiver and IR Blaster

 Supports full range of IR frequency from 20~60KHz

 Supports multi cascade for extending the signal distance to extreme

6. Speciﬁ cations

Transmitter 1 x HDMI

1 x IR Blaster

1 x CAT-6 Output Video

1 x CAT-6 Output DDC

Receiver 1 x HDMI

1 x Receiver

1 x CAT-6 Input for Video,

1 x CAT-6 Input for DDC

HDMI Input Cable 1080p 8-bit (15M), 12-bit (15M)

HDMI Output Cable 1080p 8-bit (15M), 12-bit (15M)

CAT6 Cable 1080p 8-bit (45M), 12-bit (20M)

Power Supply 5V/1A (US/EU standards, CE/FCC/UL certified)

(US/EU standards, CE/FCC/UL certified)

ESD Protection Human body model: ±8kV (air-gap discharge)

±4kV (contact discharge)

Dimensions (mm) 78.5(W) x 117(D) x 30(H) / Transmitter

78.5(W) x 72(D) x 30(H) / Receiver

Weight(g) 200 / Transmitter

90 / Receiver

Chassis Material Aluminum

Silkscreen Color Silver

Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F

Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F

Power Consumption 3.6W/TX, 3.6W/RX

Relative Humidity 20 ~ 90% RH (non-condensing)

Black

7. Operation Controls and Functions

7.1 Front Panel

CH-1106TX CH-1106RX

① IR Transmitter: This slot is where you connect the IR blaster cable and

place the IR eye in front of the source equipment(s) for sending the IR

signal to the source equipment(s), The IR blaster accepts the frequency

range from 20KHz to 60KHz.

② HDMI INPUT: This slot is where you connect to the HDMI or DVI output port

of your source equipments such as DVD player or set-top-box with HDMI

cable or cascade from the receiver unit or splitter of the same family

device for extending signal distance.

Example:

③ Power: This slot is where you plug the 5V DC power supply into the unit

and connect the adaptor to an AC wall outlet.

④ HDMI OUTPUT: This slot is where you connect the HDMI or DVI input port of

your displayer such as HD TV or HD monitor or cascade to another

transmitter unit or splitter of the same family device to extend signal

distance.

① ② ③

POWER 5V

HDMI INPUT

Transmitter

④ ⑤

POWER 5V IR

Receiver

HDMI OUTPUT

DVD

Player

HDMI

Cable

HDMI

Cable

CAT6

VIDEO

DDC

CAT6

CH-1106TX CH-1106RX CLUX-22HC

CLUX-1H4CAT

CLUX-1H8CAT

HDMI

Cable

CAT6

VIDEO

DDC

CAT6 HDMI LCD TV

HDMI LCD TV

CH-1106TX CH-1106RX

HDMI

Cable

CAT6

VIDEO

DDC

CAT6

HDMI

DVD

Player

HDMI

Cable

HDMI

Cable

CAT6

VIDEO

DDC

CAT6

PU-22HC

PU-Q1H4C

PU-Q1H8C

HDMI

Cable

CAT6

VIDEO

DDC

CAT6 HDMI LCD TV

HDMI LCD TV

HDMI

Cable

CAT6

VIDEO

DDC

CAT6

HDMI

PU-1106TX PU-1106RX

Example:

⑤ IR Receiver: This slot is where you connect the IR receiver cable and

place the IR eye in front of the display then use the existing remote

controls to control input source equipment(s). The IR receiver accepts the

frequency range from 20KHz to 60KHz.

7.2 Rear Panel

CH-1106TX CH-1106RX

①DDC input/output: Connect the DDC output of transmitter to the DDC

input of the receiver unit using CAT-6 cable.

②Video input/output: Connect the video output of transmitter to the video

input of the receiver unit using CAT-6 cable.

① ②

DDC VIDEO

CAT6 OUTPUT

①②

VIDEO DDC

CAT6 INPUT

DVD

Player

HDMI

Cable

HDMI

Cable

HDMI

Cable

CAT6

VIDEO

CAT6

VIDEO

DDC

CAT6

DDC

CAT6 HDMI LCD TV

CH-1106TX

CH-1106RX

HDMI

DVD

Player

HDMI

Cable

HDMI

Cable

CAT6

VIDEO

DDC

CAT6

HDMI

PU-1106TX PU-1106RX

PU-1106TX PU-1106RX HDMI

Cable

CAT6

VIDEO

DDC

CAT6 HDMI LCD TV

HDMI

8. Pin Assignment

8.1 IR Cable Pin Assignment

IR Blaster IR Receiver

① ②

① Power 5V

② NC

③ IR blaster signal

① IR signal

② Power 5V

③ Grounding

① ② ③③

8.2 RJ-45 Pin Deﬁ nition

Pin Video DDC

1 TMDS2+ SCL

2 TMDS2- N/A

3 TMDS1+ SDA

4 TMDS1- Power 5V

5 TMDS0+ GND

6 TMDS0- IR

7 TMDSC+ HPD

8 TMDSC- CEC

10. Connection and Installation

30°

3M 3M

HD TV

HDMI

Cable

HDMI

IR Receiver

DVD HDMI IN

IN OUT CAT6 OUTPUT

CAT6

OUTPUT

IR Blaster

DVD

AorBorCAorBorC

PU-22HC

PU-Q1H4C

PU-Q1H8C

PU-106 Transmitter

PU-1106 Transmitter

DDC

VIDEO

DDC

VIDEO

AorBorC

HDMI

CAT6

OUTPUT

DVD

HD TV

DDC

VIDEO

PU-106 Transmitter

PU-1106 Transmitter

PU-Q1H4C

PU-Q1H8C

PU-O4H4C

PU-22HC

DDCVIDEO

HDMI

Cable

HDMI IN

CAT6 IN
