DeLonghi FXN18AG Manuale utente

5712710251/04.10

DE’LONGHI AMERICA, INC.

250 Pehle Avenue, Suite 405

Saddle Brook, NJ 07663

1-800-322-3848

DE’LONGHI CANADA, INC.

6150 McLaughlin Road

Mississauga, Ontario

L5R 4E1 Canada

1-888-335-6644

FIDUCIA ITALIANA S.A DE C.V.

Erasmo Castellanos Quinto

calle B manzana II #29 - Col. Educación

C.P. 04400

Deleg. Coyoacán – Mexico D.F.

Lada sin costo: 01800 711 8805

www.delonghi.com

STEAM IRON - FXN18AG

IMPORTANT INSTRUCTIONS -

SAVE THESE INSTRUCTIONS

trial issue of Cook’s Illustrated.

Visit http://www.delonghiregistration.com.

Visit www.delonghi.com for a list of service cen-

ters near you. (U.S. and Canada only).

FER À VAPEUR - FXN18AG

MODE D’EMPLOI IMPORTANT - CONSER-

VEZ LES PRESENTES INSTRUCTIONS

Enregistrez ce produit en ligne et recevez un

numéro gratuit de Cook’s Illustrated. Visitez

http://www.delonghiregistration.com.

Visitez www.delonghi.com pour y voir une liste

des centres de réparation proches de chez vous.

(É.-U. et Canada seulement).

PLANCHE DE VAPOR - FXN18AG

INSTRUCIONES IMPORTANTES - REPASE Y

GUARDE ESTAS INSTRUCCIONES- LEA

ESTE INSTRUCTIVO ANTES DE UTILIZAR EL

APARATO

Registre este producto en línea y reciba un ejem-

plar gratis de Cook’s Illustrated.

Visite http://www.delonghiregistration.com.

Visite www.delonghi.com para ver la lista de

centros de servicios cercanos a usted. (Sólo

Estados Unidos y Canada)

ELECTRONIC CHARACTERISTICS - CARACTÉRISTIQUES ÉLECTRIQUES

- CARACTERISTICAS ELECTRICAS: 120V˜60HZ 1800W

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING

1. Use appliance only for it’s intended use.

2. To protect against a risk of electric shock, do not immerse

the appliance in water or other liquids.

3. The appliance should always be turned to “MIN” before

plugging or unplugging from outlet. Never yank the cord to

disconnect from outlet, instead grasp plug and pull to

disconnect.

4. Always disconnect appliance from electrical outlet before

filling with water, emptying or when not in use.

5. Do not allow cord to touch hot surface. Let iron cool

completely before putting away. Loop cord loosely around

iron when storing.

6. Do not operate the iron with a damaged cord or in the event

the iron has been dropped or damaged. To avoid risk of

electric shock, do not disassemble the iron. Take it to a

qualified serviceman for examination and repair. Incorrect

assembly might result in a risk of electric shock when the

iron is used after reassembly.

7. Not intended for use by children. Close supervision is

necessary for any appliance being used by or near children.

Unsupervised use can result in fire or personal injury. Do

not leave the appliance unattended while plugged in ,on an

ironing board, or while it is still hot.

8. Burns can occur from touching hot metals parts, hot water

or steam . Use caution when you turn the iron upside down.

There may be hot water in the reservoir.

9. The use of an accessory attachment is not recommended by

De' Longhi and may result in fire, electric shock or personal

injury.

SPECIAL INSTRUCTION

1. To avoid a circuit overload, do not operate a high wattage

appliance on the same circuit.

2. If an extension cord is absolutely necessary, a cord with an

ampere rating equal to or greater than the maximum rating

of the iron shall be used. A cord rated for less amperage can

result in a risk of fire or electric shock due to overheating.

Care shall be taken to arrange the cord so that it cannot be

pulled or be tripped over.

3. After removing the packing, make sure the appliance is not

damaged .If in doubt do not use the appliance and contact

an authorized Customer Service Center.

4. To repair or if power cable is damaged and requires

replacement, contact your local dealer or an authorized

Customer Service Center, in order to avoid compromising

the efficiency of your appliance. For the same reason you

are always recommended to use original spare parts.

The use of all electrical appliances implies the observance of

some fundamental rules. IN PARTICULAR:

• Never touch the appliance with wet or damp hands or feet.

DO NOT IMMERSE THE APPLIANCE IN WATER.

• Never use appliance in bathrooms.

• Never pull the power cable or the appliance with wet or

damp feet.

• Never let children or unfit persons use the appliance without

supervision.

• Never leave the appliance plugged in as it could be a safety

hazard.

• Before cleaning or servicing, disconnect the appliance by

unplugging it from the outlet.

• Never fill the appliance under running water.

• Do not direct the steam jet toward people , animals , or iron

clothes when they are being worn as this could be

dangerous.

• After ironing ,allow the iron to cool before putting away.

• The iron must be used and rested on a stable surface.

• When placing the iron on its stand, ensure that the surface

on which the stand is placed is stable.

• The iron is not to be used if it has been dropped, if there are

visible signs of damage or if it is leaking.

SAVE THESE INSTRUCTIONS

THIS APPLIANCE IS FOR

HOUSEHOLD USE ONLY

MAIN COMPONENTS

APlate

BSpray

COpening for filling tank with cover

DIndicator light

ESteam regulator

FSpray button

GSuper steam button

HThermostat knob

ISELF CLEAN button

LPower (lit steadily)/Auto-off (flashing) light (certain

models only)

Read this manual thoroughly before using the appliance.

This will ensure optimum results and maximum safety.

Important: Before plugging the appliance in, check that the

outlet voltage corresponds to the voltage (V) indicated on

the rating plate of the iron. The outlet must be efficiently

grounded.

The first time you use the iron, remove the plate protection.

Note: When used for the first time, the appliance may give

out smoke and an odor for several minutes. This is caused

by heating and subsequent drying of the sealers used in

assembling the steam generator. You are recommended to

ventilate the room.

STEAM IRONING

Before steam ironing, make sure the fabric is suitable for this

kind of ironing. The machine works with normal tap water.

If the water is very hard, we suggest using demineralized

water diluted 50/50 with tap water. Never use

demineralized water. Never use chemical substances or

detergents (e.g. perfumed water, essences, descaling

solutions, etc).

a) Before filling the tank, make sure the steam regulator E

is in the position ("dry" position) (fig. 1). Make sure

the power cable is unplugged from the outlet.

b) Open the cover of the opening Cand pour the water

into the iron (fig. 2). It is important that the iron is

always unplugged from the outlet every time you fill or

top up the water in the tank.

c) Plug the iron into the outlet.

d) A special segment on the thermostat knob H

identifies the steam range. The steam will be wet if the

thermostat pointer His at the beginning of the segment

and dryer if it is towards the end. Make sure the fabric

to be ironed is suitable for steam ironing. When using

the iron for the first time, you are recommended to pass

it several times over a piece of cloth first.

e) After these checks, select the required temperature by

rotating the thermostat knob H.

f) The indicator light Dwill come on to show the iron is on.

After about a minute in the case of maximum

temperature, the indicator light will go off showing that

the iron is ready for use.

g) Continuous steam delivery is obtained by positioning

the steam regulator Ein the 1, 2 or 3 position (3= more

steam; 1= less steam). Steam delivery ceases whenever

the iron is placed in a vertical position on the rear rest

(position recommended during pauses in ironing) or

with the iron horizontal when the steam regulator Eis in

the dry position .

Note: On the back of the iron there is a useful guide giving

information on the temperature to set according to

the garment being ironed:

Remember that the steam function can only be used

when the thermostat is in the position.

DRY IRONING

• Plug in the iron and select the temperature, if there is

water in the tank, position the steam regulator Eon the

dry position (fig. 1).

• Wait until the indicator light Dgoes off showing that the

required temperature has been reached.

• If the fabric to be ironed is slightly damp or you iron

fast, you can use a higher temperature. If, on the other

hand, the garments are dry or you iron slowly, use a

higher temperature.

TURBO (SUPER STEAM) (FIG. 3)

• Place the thermostat knob Hon maximum.

• When the indicator light Dgoes off, press the super

steam button G.

For correct operation of the super steam function, you

must wait a few seconds between one burst of steam

and the next.

VERTICAL IRONING

Enables delicate garments to be steamed without resting

them on the ironing board: pay attention to the

temperature used to steam hanging fabrics.

Position the steam regulator Eon the dry position .

Rotate the thermostat knob Hclockwise as far as it will go

(maximum steam position). When the indicator light Dgoes

off, place the iron in a vertical position and move it near the

garment. Press the super steam button Guntil the

indicator light Dcomes on again. Wait until the light goes

off before continuing vertical ironing.

When the light (D) goes off, place the iron in an upright

position and move it near the garment, then press the turbo

button (G). For efficient vertical ironing, wait for a few
