Item

Model

ProjectName

Turbo Liquidisers

603287

TBX120

The TBX 120 floor-standing grinder with

removable mixer tube is fitted with a

turbine effect mixing head, which

sigificantly improves the grinding fineness

and throughput. The turbo liquidisers are

used to mix, liquidise, reduce and

emulsify vegetable and fish soups, fruit

and vegetable purées, liquid pastries and

sauces. These preparations can be

carried out directly in the cooking

containers or in suitable liquid containers.

FEATURES

V The turbo liquidisers are designed to

withstand intensive use in large

catering, central kitchens and the food

preparation industries.

V Stainless steel is used to withstand

the humid atmosphere of the various

production environments.

V Height adjustable on installing.

V All models are mounted onto a

stainless steel trolley with castors.

V All models can be adapted to all

shapes of recipients: cylindrical,

rectangular, hemispherical.

V All models have a turbine that gives

an accelerated flow of the liquid over

the impeller giving greater throughput

and finer grinding.

Specifications

MODEL

TBX120F

603287

TBX120FP

603288

External dimensions - mm

width 640 640

depth 1625 1625

height 1330 1330

Electrical power - kW 0.9 0.9

Net weight - kg. 76 76

Supply voltage 230/400 V, 3, 50 230/400 V, 3, 50/60

Included accessories

CODE DESCRIPTION

TBX120F

603287

TBX120FP

603288

653485 S/S TUBE FOR PUREES FOR TURBO

LIQUIDISER

653519 S/S TUBE FOR SOUPS FOR TURBO

LIQUIDISER

Optional accessories

CODE DESCRIPTION

TBX120F

603287

TBX120FP

603288

653520 BRAISING PAN KIT EJECTOR

F.TURBO LIQUID. ✓ ✓

653507 FISH SOUP GRID FOR TURBO

LIQUIDISERS ✓ ✓

653502 PUREE KIT FOR TURBO LIQUIDISERS ✓ ✓

653485 S/S TUBE FOR PUREES FOR TURBO

LIQUIDISER ✓ ✓

653519 S/S TUBE FOR SOUPS FOR TURBO

LIQUIDISER ✓ ✓

V Safety device in non-working position

and protective ring for the grinding head.

V Grinding head can be removed without

tools for easier cleaning.

V Touch control panel allows the entire

machine to be cleaned with a jet of water

(IP66 water protection).

Installation drawings

XXX

I - Electrical connection 230/400 V, 3, 50 230/400 V, 3, 50/60

MODEL

TBX120F

603287

TBX120FP

603288

603287, 603288

640

1090/1330

420/660

1625

1865/2105

1544/1739

840

ACBD010

www.dito-electrolux.com

Turbo Liquidisers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.
