Item

Model

ProjectName

Vegetable slicers

603283 + AUTOMATIC HOPPER + STAND

TR260

The TR260 vegetable slicer makes

all types of vegetable slicing

possible. By combining the

equipment, it is possible to vary

the slicing dimensions in order to

achieve original vegetable

preparations. An advantage of the

automatic hopper is the high

productivity and the reduction in

the work time which makes it

possible to prepare the vegetables

at the last minute.

FEATURES

V A wide variety of work is possible

such as: thin slicing, grating and

shredding: carrots, potatoes and celery.

V Up to 2,200 W, with a two speed

(three phase) motor or 1,500 W (single

phase).

V "No volt release device".

V Self braking motor.

V Stainless steel motor housing.

V Flat control panel with on/off control

and possible selection of speed (only

for the two speed version).

V Vegetable slicer elements: automatic

hopper, standard lever-operated

hopper, cabbage hopper, long

vegetable hopper.

Specifications

MODEL

TR260F1V

603275

TR260FL1VS

603277

TR260F2V20

603283

TR260F2V38

603278

TR260FL2VS

603281

External dimensions - mm

width 750 486 750 750 486

depth 380 750 380 380 750

height 460 1346 460 460 1346

Cutting capacity - kg/h

carrots 350 350 350 350 350

chips 600 600 600 600 600

dicing 600 600 600 600 600

Cutting capacity - kg/h

potatoes 550 550 550 550 550

Power - kW

installed-electric 1.5 1.5 2 2 2

Net weight - kg. 49 78 49 49 78

Supply voltage 220...240 V,

1N, 50/60

220...240 V,

1N, 50

200...240 V, 3,

380...415 V, 3,

V The touch control panel allows the entire

machine to be cleaned with a jet of water

(IP66 water proof index).

V 300 mm diameter cutting disk.

Included accessories

CODE DESCRIPTION

TR260F1V

603275

TR260FL1VS

603277

TR260F2V20

603283

TR260F2V38

603278

TR260FL2VS

603281

653174 GRATING DISC 2 MM 1

653175 GRATING DISC 3 MM 1

653036 LEVER HOPPER 1 1

653017 S/S MOBILE STAND 1 1

653172 SLICING DISC 2 MM 1

653173 SLICING DISC 3 MM 1

653212 STAINLESS STEEL DISC RACK 1 1

Optional accessories

CODE DESCRIPTION

TR260F1V

603275

TR260FL1VS

603277

TR260F2V20

603283

TR260F2V38

603278

TR260FL2VS

603281

653037 AUTOMATIC HOPPER ✓ ✓ ✓ ✓ ✓

653048 CABBAGE HOPPER ✓ ✓ ✓ ✓ ✓

653009 CABBAGE SLICING DISC 1 MM ✓ ✓ ✓ ✓ ✓

653227 CABBAGE SLICING DISC 2 MM ✓ ✓ ✓ ✓ ✓

653228 CABBAGE SLICING DISC 3 MM ✓ ✓ ✓ ✓ ✓

653014 CABBAGE SLICING DISC FOR JULIENNE 7 MM ✓ ✓ ✓ ✓ ✓

653051 DICING GRID 10 MM ✓ ✓ ✓ ✓ ✓

653301 DICING GRID 12 MM ✓ ✓ ✓ ✓ ✓

653052 DICING GRID 16 MM ✓ ✓ ✓ ✓ ✓

653053 DICING GRID 20 MM ✓ ✓ ✓ ✓ ✓

653054 DICING GRID 25 MM ✓ ✓ ✓ ✓ ✓

653055 DICING GRID 32 MM ✓ ✓ ✓ ✓ ✓

653217 DISC WITH CORRUGATED BLADES 2 MM ✓ ✓ ✓ ✓ ✓

653218 DISC WITH CORRUGATED BLADES 3 MM ✓ ✓ ✓ ✓ ✓

653219 DISC WITH CORRUGATED BLADES 6 MM ✓ ✓ ✓ ✓ ✓

653174 GRATING DISC 2 MM ✓ ✓ ✓ ✓ ✓

653175 GRATING DISC 3 MM ✓ ✓ ✓ ✓ ✓

653194 GRATING DISC 4 MM ✓ ✓ ✓ ✓ ✓

653215 GRATING DISC 7 MM ✓ ✓ ✓ ✓ ✓

653220 GRATING DISC FOR KNOEDELN ✓ ✓ ✓ ✓ ✓

653216 GRATING DISC FOR PARMESAN ✓ ✓ ✓ ✓ ✓

653036 LEVER HOPPER ✓ ✓ ✓ ✓ ✓

653223 LONG VEGET.ACC.FOR LEVER

HOPPER-3TUBES ✓ ✓ ✓ ✓ ✓

653306 LONG VEGETABLE HOPPER W/3TUBES

D.50-70MM ✓ ✓ ✓

653017 S/S MOBILE STAND ✓ ✓ ✓ ✓ ✓

653224 S/S TROLLEY FOR GN2/1 TRAYS ✓ ✓ ✓ ✓ ✓

653200 SHREDDING DISC 10X10 MM ✓ ✓ ✓ ✓ ✓

653195 SHREDDING DISC 2X2 MM ✓ ✓ ✓ ✓ ✓

653196 SHREDDING DISC 3X3 MM ✓ ✓ ✓ ✓ ✓

653197 SHREDDING DISC 4X4 MM ✓ ✓ ✓ ✓ ✓

653198 SHREDDING DISC 6X6 MM ✓ ✓ ✓ ✓ ✓

653199 SHREDDING DISC 8X8 MM ✓ ✓ ✓ ✓ ✓

653188 SLICING DISC 1 MM ✓ ✓ ✓ ✓ ✓

653192 SLICING DISC 10 MM ✓ ✓ ✓ ✓ ✓

653193 SLICING DISC 16 MM ✓ ✓ ✓ ✓ ✓

653172 SLICING DISC 2 MM ✓ ✓ ✓ ✓ ✓

653173 SLICING DISC 3 MM ✓ ✓ ✓ ✓ ✓

653189 SLICING DISC 5 MM ✓ ✓ ✓ ✓ ✓

653190 SLICING DISC 6 MM ✓ ✓ ✓ ✓ ✓

653191 SLICING DISC 8 MM ✓ ✓ ✓ ✓ ✓

653212 STAINLESS STEEL DISC RACK ✓ ✓ ✓ ✓ ✓

AAAF010

www.dito-electrolux.com

Vegetable slicers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.

Installation drawings

XXX

I - Electrical connection 220...240 V,

1N, 50/60

220...240 V,

1N, 50

200...240 V, 3,

380...415 V, 3,

MODEL

TR260F1V

603275

TR260FL1VS

603277

TR260F2V20

603283

TR260F2V38

603278

TR260FL2VS

603281

603275, 603278, 603283

225

750

400

436

603277, 603281

460

760

880

1245

380

830
