Emerio STC-110548.1 Manuale utente

STC-110548

STC-110548.1

Foldable Steamer (EN)

Faltbarer Dampfgarer (DE)

Cuiseur Vapeur Pliant (FR)

F Ihopfällbar ångkokare (SE)

Opvouwbare stoomkoker (NL)

Parowar składany (PL)

Forno a vapore pieghevole (IT)

- 1 -

Content –Inhalt –Teneur –Innehåll –Inhoud –Treść – Contenuto

Instruction manual –English ......................................................................................- 2 -

Bedienungsanleitung –German .................................................................................- 9 -

Mode d‘emploi – French ..........................................................................................- 16 -

Bruksanvisning –Swedish.........................................................................................- 23 -

Gebruiksaanwijzing –Dutch.....................................................................................- 30 -

Instrukcja obsługi – Polish........................................................................................- 37 -

Manuale d'istruzioni –Italian...................................................................................- 44 -

- 2 -

Instruction manual –English

SAFETY INSTRUCTIONS

Before use make sure to read all of the below instructions in

order to avoid injury or damage, and to get the best results

from the appliance. Make sure to keep this manual in a safe

place. If you give or transfer this appliance to someone else

make sure to also include this manual.

In case of damage caused by user failing to follow the

instructions in this manual the warranty will be void. The

manufacturer/importer accepts no liability for damages

caused by failure to follow the manual, a negligent use or use

not in accordance with the requirements of this manual.

1. This appliance can be used by children aged from 8 years

and above if they have been given supervision or

instruction concerning use of the appliance in a safe way

and if they understand the hazards involved.

2. Cleaning and user maintenance shall not be made by

children unless they are older than 8 and supervised.

3. Keep the appliance and its cord out of reach of children

aged less than 8 years.

4. Appliances can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved.

5. Children shall not play with the appliance.

6. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

7. This appliance is intended to be used in household and

similar applications such as: staff kitchen areas in shops,

offices and other working environments; farm houses; by

clients in hotels, motels and other residential type

environments; bed and breakfast type environments.

- 3 -

8. Regarding the instructions for cleaning the surfaces which

come in contact with food, please refer to the paragraph

“cleaning and maintenance” of the manual.

9. Before inserting the plug into the mains socket, please

check that the voltage and frequency comply with the

specifications on the rating label.

10. If an extension cord is used it must be suited to the power

consumption of the appliance, otherwise overheating of

the extension cord and/or plug may occur.

11. Disconnect the mains plug from the socket when the

appliance is not in use and before cleaning.

12. Ensure that the mains cable is not hung over sharp edges

and keep it away from hot objects and open flames.

13. Do not immerse the appliance or the mains plug in water

or other liquids. There is danger to life due to electric shock!

14. To remove the plug from the plug socket, pull the plug. Do

not pull the power cord.

15. Do not touch the appliance if it falls into water. Remove the

plug from its socket, turn off the appliance and send it to

an authorized service center for repair.

16. Do not plug or unplug the appliance from the electrical

outlet with a wet hand.

17. Never attempt to open the housing of the appliance, or to

repair the appliance yourself. This could cause electric

shock.

18. Children are unable to recognize the hazards associated

with incorrect handling of electrical appliances. Therefore,

children should never use electric household appliances

unsupervised.

19. Never leave the appliance unattended during use.

20. This appliance is not designed for commercial use. This

appliance is intended for household use only.

21. Do not use the appliance for other than intended use.

22. Do not wind the cord around the appliance and do not

bend it.

23. Only connect the appliance to a grounded power outlet.

- 4 -

24. Before plugging in the appliance, make sure that there is

enough water in the water tank. To avoid overflow, do not

exceed the maximum water level indication when filling the

water tank with water.

25. Beware of the hot steam that comes out of the steam vent

during steaming or when you remove the steamer lid. Keep

your hands and face away from the steam vent on the

steamer lid to avoid scalding yourself with the steam.

26. The steamer lid and removable drip tray becomes hot

during cooking. Do not get too close to the steamer or

touch it with your hands to avoid scalding.

27. When you open the steamer lid during cooking, beware of

the hot steam coming out of the steamer lid to avoid

scalding. When you check the food status, use a utensil

with a longer handle.

28. Do not remove the appliance when it is working.

29. Do not remove the removable drip tray before it cools

down to room temperature and before the appliance is

unplugged.

30. After the cooking is finished, take extra caution when

removing the steamer lid and keep it away from your body.

Beware of the condensation to avoid scalding.

31. Do not clean the accessories before they have cooled down

to room temperature.

32. Do not expose the appliance to high temperature, nor put

it on or near an operating or still hot stove or cooker.

33. Do not connect the appliance to an external timer to avoid

hazards.

34. Do not use the appliance if the plug, the power cord, the

base, or the appliance itself is damaged.

35. Do not use the steamer too long (no longer than 1 hour) to

avoid liquid flows out from removable drip tray. If you need

to use for longer time, be sure to pour out the condensate

water from the removable drip tray once an hour. Make

sure no liquid flows out from the removable drip tray

during use.

- 5 -

36. Do not pull out the water tank (when for cleaning)

frequently to avoid the leakage because of damage of the

tank sealing ring.

37. There may be water left on the removable drip tray, clean

before use.

38. If water left on steamer surface, power off immediately,

clean and dry before use.

39. WARNING!!

Please do not touch surface while in use. The

temperature of accessible surfaces may be high

when the appliance is operating.

- 6 -

STC-110548/STC-110548.1 EN

PARTS DESCRIPTION

1. Steamer lid

2. Lid handle

3. Steam vent

4. Steamer basket

5. Steamer basket board

6. Egg holder

7. Water tank

8. Water tank cover

9. Water level indication

10. Indicator light

11. Body

12. Safety switch

13. Steam outlet

14. Timer knob

15. Steaming tray

16. Removable drip tray

BEFORE USE

Remove the packaging materials from the appliance. Clean the appliance before using for the first time. (See “Cleaning

and maintenance”). The appliance may emit some smoke and a characteristic smell when you switch it on for the

first time. This is normal, and will stop soon.

USE

1. Open the folding steamer and put it on a flat, even and stable surface.

2. Place removable drip tray and steaming tray on the base of the appliance. Removable drip tray is under the

steaming tray. Place ingredients on the steaming tray.

3. Add water into the water tank. Do not exceed the max level indication.

4. Put steamer basket over the steaming tray. If you want to steam more ingredients, you can also place them on

the steamer basket board for cooking. At last, cover with the steamer lid.

5. Plug in the appliance. Rotate the timer knob to choose your desired cooking time.

6. After cooking is finished, the buzzer signal will be heard. Unplug the appliance. Wait 4 - 5 minutes (to prevent

from being scalded by steam) and remove the steamer lid and steamer basket. Take out the food and pour the

condensed water after the removable drip tray cools down.

NOTE: This appliance is equipped with a safety switch. It will be activated when pressed in by the steamer basket.

Otherwise, the appliance will not start to work when switched on.

- 7 -

Recommended cooking table

Food –Time

Milk –5 minutes

Steamed stuffed bun –12

minutes

Carrot –15 minutes

Pumpkin –20 minutes

Egg –10 minutes

Cauliflower –12 minutes

Steamed cake –8

minutes

Bean –25 minutes

Cabbage –10 minutes

Fish –15 minutes

Aubergine –20 minutes

Chicken –25 minutes

1. Eggs can be placed on the steamer basket board (with egg holders) for cooking.

2. The maximum weight of ingredients can be placed on the steaming tray / steamer basket board is 500g.

3. It is recommended to use metal bowls or dishes to contain food for steaming, if needed.

CLEANING AND MAINTENANCE

1. Clean the appliance after each use. Before cleaning, unplug the appliance and pour out the condensed water

from the removable drip tray.

2. Do not use soap, gasoline, thinner, alcohol, bleach, polishing powder, metal brush, nylon brush, steel wool or

abrasive cleaners to clean the appliance, as these can damage the surface of appliance.

3. Do not immerse the appliance in water nor rinse it under the tap.

4. Wash accessories with clean water and wipe the body with a soft cloth. Only the stainless steel accessories

can be cleaned in a dishwasher.

5. Make sure all parts are cleaned and dried before storing.

Cleaning for Steam Generator:

After using for 2 to 3 months, limescale may accumulate in the steam generator. It is a normal phenomenon. The

amount of limescale depends on the hardness of water. It is recommended to descale regularly to prolong the

life span of your steamer. (We recommend to use purified water.)

1. Add mixture of white vinegar and water into the tank (Do not use other chemicals).

2. Plug in the appliance.

3. Turn the timer knob to 20 - 25 minutes and allow steam to circulate.

4. When the timer rings, unplug the appliance and pour out the white vinegar.

5. Add purified water into the tank and then steam 10 minutes. Now, the steamer can be used again.

TROUBLESHOOTING

Problem

Possible cause

Solution

No steam

1. The appliance is not plugged in.

2. Steamer basket does not

connect safety switch.

3. No water in the tank.

4. Steamer delay protection

function.

1. Put the mains plug in an earthed wall

socket.

2. Properly cover the steamer basket

again.

3. Add water into the tank.

4. Wait approx. 25 seconds, steam will

come out then.

Timer knob does not

work

The appliance is not plugged in.

Put the mains plug in an earthed wall socket.

Indicator light does not

illuminate

1. The appliance is not plugged in.

2. Steamer basket does not

connect safety switch.

3. Timer is not on.

1. Put the mains plug in an earthed wall

socket.

2. Properly cover the steamer basket

again.

3. Turn on the timer knob.

The appliance cannot be

attracted and folded

Magnet will be weaken under high

temperature.

Away from high temperature environment.

- 8 -

TECHNICAL DATA

Operation voltage: 220-240V ~ 50/60Hz

Power: 1500W

GUARANTEE AND CUSTOMER SERVICE

Before delivery our devices are subjected to rigorous quality control. If, despite all care, damage has occurred

during production or transportation, please return the device to your dealer. In addition to statutory legal rights,

the purchaser has an option to claim under the terms of the following guarantee:

For the purchased device we provide 2 years guarantee, commencing from the day of sale. If you have a defective

product, you can directly go back to the point of purchase.

Defects which arise due to improper handling of the device and malfunctions due to interventions and repairs

by third parties or the fitting of non-original parts are not covered by this guarantee. Always keep your receipt,

without the receipt you can’t claim any form of warranty. Damage caused by not following the instruction manual,

will lead to a void of warranty, if this results in consequential damages then we will not be liable. Neither can we

hold responsible for material damage or personal injury caused by improper use or if the instruction manual are

not properly executed. Damage to accessories does not mean free replacement of the whole appliance. In such

case please contact our service department. Broken glass or breakage of plastic parts is always subject to a charge.

Defects to consumables or parts subjected to wearing, as well as cleaning, maintenance or the replacement of

said parts are not covered by the warranty and are to be paid.

ENVIRONMENT FRIENDLY DISPOSAL

Recycling –European Directive 2012/19/EU

This marking indicates that this product should not be disposed with other household wastes. To

prevent possible harm to the environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material resources. To return your used

device, please use the return and collection systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling.

Emerio Deutschland GmbH (no service address)

Höfferweg 14

51519 Odenthal

Germany

Customer service:

T: +49 (0) 2202 10 93 756

E: info.de@emerio.eu

- 9 -

Bedienungsanleitung –German

SICHERHEITSHINWEISE

Lesen Sie vor dem Gebrauch unbedingt die nachfolgenden

Anleitungen, um Verletzungen oder Beschädigungen zu

vermeiden und das beste Ergebnis mit dem Gerät zu erzielen.

Bewahren Sie diese Bedienungsanleitung an einem sicheren

Ort auf. Wenn Sie dieses Gerät an eine andere Person

weitergeben, stellen Sie sicher, dass Sie auch diese

Bedienungsanleitung aushändigen.

Im Falle von Beschädigungen, die durch die Missachtung der

Anleitungen in dieser Bedienungsanleitung verursacht

wurden, wird die Garantie ungültig. Der Hersteller/Importeur

haftet nicht für Schäden, die durch Missachtung der

Bedienungsanleitung, fahrlässigen Gebrauch oder Benutzung,

die nicht in Übereinstimmung mit den Anforderungen dieser

Bedienungsanleitung erfolgt, verursacht wurden.

1. Dieses Gerät kann von Kindern ab 8 Jahren benutzt werden,

wenn sie beaufsichtigt werden oder in die sichere

Benutzung des Gerätes unterwiesen werden und die damit

verbundenen Gefahren verstehen.

2. Die Reinigung und vom Benutzer auszuführende

Wartungsarbeiten sollten nicht von Kindern durchgeführt

werden; es sei denn, sie sind älter als 8 Jahre und werden

beaufsichtigt.

3. Halten Sie das Gerät und sein Netzkabel außer Reichweite

von Kindern unter 8 Jahren.

4. Geräte können von Personen mit eingeschränkten

körperlichen, sensorischen oder geistigen Fähigkeiten oder

mangelnder Erfahrung und Kenntnis benutzt werden, wenn

sie beaufsichtigt werden oder in die sichere Benutzung des

Gerätes unterwiesen werden und die damit verbundenen

Gefahren verstehen.

5. Kinder dürfen nicht mit dem Gerät spielen.

6. Wenn das Netzkabel beschädigt ist, muss es vom Hersteller,

seinem Kundendienst oder einer ähnlich qualifizierten

Person ausgewechselt werden, um Gefahren zu vermeiden.

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali emerio Elettrodomestico da cucina

emerio

emerio AF-126672 Manuale utente

emerio

emerio AF-125927 Manuale utente

emerio

emerio VS-123947 Manuale utente

emerio

emerio PO-115848.1 Manuale utente

emerio

emerio POM-111664 Manuale utente

emerio

emerio AF-115668.4 Manuale utente

emerio

emerio POM-111241 Manuale utente

emerio

emerio SC-110627 Manuale utente

emerio

emerio AF-126624 Manuale utente

emerio

emerio CF-110992 Manuale utente

emerio

emerio AF-123543 Manuale utente

emerio

emerio PM-211798.3 Manuale utente

emerio

emerio SG-123562.6 Manuale utente

emerio

emerio AF-122706 Manuale utente

emerio

emerio PM-129032.2 Manuale utente

emerio

emerio POM-111664.7 Manuale utente

emerio

emerio AF-122706.1 Manuale utente

emerio

emerio FD-211838 Manuale utente

emerio

emerio Pizzarette PO-115985 Manuale utente

emerio

emerio HB-111411.1 Manuale utente

emerio

emerio MK-107297 Manuale utente

emerio

emerio CAN-110357 Manuale utente

emerio

emerio POM-120650 Manuale utente

emerio

emerio Smart Fryer AF-117898 Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente

emerio STC-110548.1 Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche
