Event Lighting LM75 Manuale utente

LM75

75W LED WASH ZOOM HEAD

USER MANUAL

For safety, please read this user manual carefully before initial use.

Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to

change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting

for any clarification or information regarding this item.

www.event-lighting.com.au V1.0

www.event-lighting.com.au

Safety Instructions

WARNING

• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.

•Do not look at the light source when the device is on.

•CAUTION: This unit's housing may be hot during and after operation.

•Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.

•Do not leave any flammable material within 50 cm of this unit while operating or connected to power.

•Use a safety chain when mounting this device overhead.

•Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.

•Do not operate this device if the housing, lenses, or cables appear damaged.

•Do not connect this device to a dimmer or rheostat.

•ONLY connect this device to a grounded and protected circuit.

•ONLY use the hanging bracket to carry this device.

•In case of a serious operating problem, stop using immediately.

•The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.

Power Input & Power Linking

This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.

Link up to the maximum 8A. DO NOT exceed this.

Fuse Replacement

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.

Before replacing the fuse, unplug mains lead.

Procedure:

Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anticlockwise).

Step 2: Remove the old fuse from the fuse holder.

Step 3: Install the new fuse in the fuse holder.

Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au

Product Installation

This device can be mounted in many orientations provided each

individual device is secured by the use of correct mounting bracket.

Use a safety chain when mounting this device overhead.

www.event-lighting.com.au

Dimensions

Lux Chart

www.event-lighting.com.au

Colour Wheel

Open

Red

Blue

Green

Yellow

Magenta

Dark Blue

Orange

Orange-red

www.event-lighting.com.au

Gobo Wheel

Position 1

Position 2

Position 3

Position 4

Position 5

Position 6

Position 7

www.event-lighting.com.au

Menu operation

Menu –Move up a level.

Up –Move selection up one item.

Down –Move selection down one item.

Enter –Select / Move down a level.

DESCRIPTION

DMX

Address

DMX

Address

A001~AXXX

DMX Address Setting

Auto Run

Program 1-8 | Master/Alone

Auto Run State

Music Run

Program 1-8 | Master/Alone

Music Control State

Reset

ALL

On/Off

Reset all motors

Pan/Tilt

On/Off

Reset pan/tilt motor

Colour

On/Off

Reset colour motor

Gobo

On/Off

Reset gobo motor

Other

On/Off

Reset other

Reverse

Pan

On/Off

Reverse pan

Reverse

Tilt

On/Off

Reverse tilt

Special

R Default

On/Off

Reset to default settings

Cal

Code (Password: 088)

Calibration code

Pan, Tilt, Colour, Gobo, Focus,

Prism

Calibrate the selected

channel

Temp.

XXX °C/°F

Current temperature

Manual

Ctrl.

Pan = XXX…

Manual control

Mic Sens.

0-99%

Microphone sensitivity

Limit Mode

Limit Mode Off/Centre/Right/Left

Select Edge or Corner range

DMX Mode

CH13

Mode

13 channel mode

CH11

Mode

11 channel mode

Scan

Degree

Pan

Degree

Pan 630°

Select Pan degree

(default 540°)

Pan 540°

Pan 360°

Tilt Degree

Tilt 270°

Select Tilt degree

www.event-lighting.com.au

Tilt 180°

(default 270°)

Tilt 90°

Version

V1.0 - vX.X

Software version

DMX Chart

Channel Mode

Min

DMX

Max

DMX

Name

Function

Standard

Basic

255

Pan

Pan movement

255

Pan-fine

Fine control of pan movement

255

Tilt

Tilt movement

255

Tilt-fine

Fine control of tilt movement

Colour

Open/white

Colour 1

Colour 2

Colour 3

Colour 4

Colour 5

104

Colour 6

105

119

Colour 7

120

127

Colour 8

128

189

Forward rainbow effect, fast to slow

190

193

Stop rainbow effect

194

255

Backward rainbow effect, slow to fast

Gobo

Open

Gobo 1

Gobo 2

Gobo 3

Gobo 4

Gobo 5

Gobo 6

Gobo 1 shake slow to fast

109

Gobo 2 shake slow to fast

110

129

Gobo 3 shake slow to fast

130

149

Gobo 4 shake slow to fast

150

169

Gobo 5 shake slow to fast

170

189

Gobo 6 shake slow to fast

190

255

Forward wheel spin, slow to fast

Shutter

Shutter closed

Shutter open

Strobe effect, slow to fast

127

Shutter open

128

159

Pulse effect, slow to fast

www.event-lighting.com.au

160

191

Shutter open

192

223

Random strobe effect, slow to fast

224

255

Shutter open

255

Dimmer

Dimmer 0..100%

255

Focus

In (near) to out (far)

Rotating

Prism,

Prism

Off

255

Gobo &

Prism

rotation

TBD

127

Forwards gobo and prism rotation, fast to

slow

128

131

Stop gobo and prism rotation

132

255

Backwards gobo and prism rotation, slow to

fast

225

Speed

pan/tilt

Pan/tilt speed, fast to slow

226

235

Blackout during pan/tilt movement

236

245

Blackout when colour and gobo wheel

switching

246

255

TBD

Special

function

TBD

Reset all

Reset pan/tilt

Reset colour

Reset gobo

TBD

Reset other

100

109

Internal program 1

110

119

Internal program 2

120

129

Internal program 3

130

139

Internal program 4

140

149

Internal program 5

150

159

Internal program 6

160

169

Internal program 7

170

179

Internal program 8

180

189

Internal sound program 1

190

199

Internal sound program 2

200

209

Internal sound program 3

210

219

Internal sound program 4

220

229

Internal sound program 5

230

239

Internal sound program 6

240

249

Internal sound program 7

250

255

Internal sound program 8

The device is controlled by universal DMX 512 protocol, DMX address is the start channel used to receive instructions

from the external controller. For independent control, each fixture must be assigned its unique address control channels.

www.event-lighting.com.au

For example, this device has two channel modes: 13/11, if we set the mode at standard 13 channels mode, and there

are several models need to be independently controlled, we just simply address first fixture at 1, and second fixture at

14, third one at 27, etc.

- If the devices have the same address, they will behave synchronically.

- Display is flashing when no DMX signal is received.
