Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

Product Dimensions

Width 36"

Depth 18"

Height 3-1/2"

More Easy-To-Use Features

Electronic Pilotless Ignition

Saves energy and can be ignited

manually when electricity is out.

Spill Saver™ Drip Bowls

Cooktop features drip bowls that make

cleaning up spills quick and easy.

Porcelain Cooktop Grates

Grates are durable and easy to clean.

LP Gas Conversion Option

A.D.A. Compliant2

Available in:

1Select models only.

2When properly installed, meets the appliance

standards in the Americans with Disabilities Act

and the Architectural Barriers Act Accessibility

Guidelines as published by the United States

Access Board on June 23, 2004, as amended

August 5, 2005.

Burners

Right Front

Right Rear

Left Front

Left Rear

BTU

12,000

5,000

9,500

White

(W)

Stainless

(S)

Black

(B)

36" Gas

Drop-In Cooktops

FFGC3613L S / W/ B

Color-Coordinated Control

Knobs

White and Black cooktops come with

matching knobs — while Stainless Steel

models feature our neutral black knobs.

Durable Stainless Steel

Cooktop1

A premium look that stands up to

everyday use.

Ready-Select™ Controls

Select options or control cooking

temperature with our easy-to-use

controls.

Sealed Gas Burners

Enjoy easier cleanup and a burner that

stays looking great.

Accessories information available

on the web at frigidaire.com

Granite Countertop

Installation Kit available.

USA

•

10200 David Taylor Drive •

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Drop-In Cooktops

FFGC3613L S / W/ B 36" Gas

Features

Controls

Surface Type

Sealed Gas Burners

Grates

Right Front Element (BTU)

Right Rear Element (BTU)

Left Front Element (BTU)

Left Rear Element (BTU)

Control Location

Knob Color

Knob Type

Bowl Type

Certiﬁcations

A.D.A. Compliant1

Speciﬁcations

Power Supply Connection Location

Gas Supply Connection Location

LP Gas Conversion Kit

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts2

Amps @ 120 Volts

Minimum Circuit Required (Amps)

Approved for Electric Single Wall Oven

Combination Installation

Shipping Weight (Approx.)

Ready-Select™

Stainless Steel ( S ),

Color-Coordinated

Porcelain ( W/ B )

Yes

Cast Iron with Black

Matte Finish

12,000

5,000

9,500

Center Front

Black ( S ),

Color-Coordinated

( W/ B )

Plastic

Black ( S ),

Color-Coordinated

( W/ B )

Yes

Right Rear

Included

120V / 60V / 15A

1.0

40 Lbs.

1When properly installed, meets the appliance standards in the Americans

with Disabilities Act and the Architectural Barriers Act Accessibility

Guidelines as published by the United States Access Board on June 23,

2004, as amended August 5, 2005.

2For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

Product Dimensions

A - Width

B - Depth

C - Height

Cutout Dimensions

Width (Min.)

Width (Max.)

Depth (Min.)

Depth (Max.)

Height

36"

18"

3-1/2"

34-1/4"

34-3/8"

16-5/8"

16-3/4"

NOTE: Always consult local and national electric and gas codes. Refer to Product

Installation Guide for detailed installation instructions on the web at frigidaire.com.

Drop-In Gas Cooktops

Frigidaire Baseline
