Frigidaire FEB30S5D Manuale utente

FEB30S5D.eps CFEB30S5DSA.eps BFEB30S5DSD.eps DFES365ESD.eps

318046237.eps

Clea n

Keep

warm

Broil

Bake Clock

Controls

Clea r

/Off

Bake

tim e

Start

Oven

ligh t

Timer

On/Off

Se lf-C lea n in g O v e n

DoorLocked

Oven

Preheat

Product No. FEB30S5DBF FEB30S5DSF

38254331E4066 38254331E4016

Series 30" single 30" single

Color black white

Market North America North America

Wiring Diagram 318046237 318046237

Owner's Guide 318205115 318205115

Installation Instructions 318201514 318201514

Service Data Sheet 318047413 318047413

Timer Guide 318200189 318200189

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995489928

07/05/02

(EN/SERVICE/BJH)

377

SINGLE ELECTRIC

WALL OVEN

Model No.

FEB30S5D

Publication No: 5995489928 FEB30S5D

05/07 2

CONTROL PANEL

FEB30S5D Publication No: 5995489928

# Functional Parts 3 05/07

* Non-Illustrated Parts

CONTROL PANEL

Model Index: AFEB30S5D (FEB30S5DBF)

BFEB30S5D (FEB30S5DSF)

POS. NO PART NO. DESCRIPTION

2A 318257300 A B Shield, oven top

2B 318260100 A B Cover, box

19 318274601 A - Control Panel Assembly, glass, black, w/touch pad

19 318274600 - B Control Panel Assembly, glass, white, w/touch pad

20 # 316418522 A B Clock/Timer, electronic, ES350W1

* 5303211311 A B Screw, 8 x 0.500

Publication No: 5995489928 FEB30S5D

05/07 4

BODY

FEB30S5D Publication No: 5995489928

# Functional Parts 5 05/07

* Non-Illustrated Parts

BODY

Model Index: AFEB30S5D (FEB30S5DBF)

BFEB30S5D (FEB30S5DSF)

POS. NO PART NO. DESCRIPTION

1 318259205 A B Back, main

2 318258902 A B Shield, insulation, upper

6 318345207 A B Rack, oven

9 5303317977 A B Pan, broiler

10 5303317976 A B Insert, broiler pan

12 316445501 A B Switch, oven light, door frame

14 318224000 A B Receptacle, oven light

14* 318268099 A B Insulation, oven light

15 5303013071 A B Bulb/Lamp, light

16 08011086 A B Lens, oven light, glass

17 5304400195 A B Retainer, light cover

29 318147411 A B Bumper, (2)

37 # 316217002 A B Probe, oven temp

41 5303310526 A B Cover, hinge cutout

54 318222400 A B Housing, oven light

56 318903704 A - Trim, side, black, RH

56 318903702 - B Trim, side, white, RH

56A 318903705 A - Trim, side, black, LH

56A 318903703 - B Trim, side, white, LH

58A 318285055 A B Insulation, oven wrapper

58B 318285056 A B Insulation, oven back

59 318072560 A B Duct, oven vent

59A 318261600 A B Bracket, vent tube

62 316056000 A B Terminal Block

62* 5303323144 A B Nut, 10-32

66 # 318255600 A B Element, broil, 2750W

67 # 318255401 A B Element, bake, 3400W

68 5304403015 A B Support, hanger, (2), broil element

70 318259100 A B Shield, insulation, sides, (2)

71 318260007 A B Panel, rear box

76 318056217 A B Front, oven

80 5303320846 A B Plate, oven mtg

81 318192400 A B Spring, oven

82 318258707 A B Shield, insulation, lower

83 318261403 A B Liner, oven assy

86 318342400 A B Receptacle, hinge

87 318260600 A B Bracket, cable mtg.

89 # 318261205 A B Motor, latch assy

90 318259701 A - Trim, oven front, black, bottom

90 318259700 - B Trim, oven front, white, bottom

99 318256200 A B Bracket, side, bottom, (2)

108# 318073018 A B Motor, blower

* 08016432 A B Screw, truss head, 8-18 x 0.375

108A 318251300 A B Bracket, fan support

112# 318112701 A B Relay

119# 318004900 A B Switch, thermal

127 318317100 A B Adapter Assembly, vent tube, w/converter

131 318272900 A B Box, vent

132 318003000 A B Plate, shield

Publication No: 5995489928 FEB30S5D

05/07 6

BODY

FEB30S5D Publication No: 5995489928

# Functional Parts 7 05/07

* Non-Illustrated Parts

BODY

Model Index: AFEB30S5D (FEB30S5DBF)

BFEB30S5D (FEB30S5DSF)

POS. NO PART NO. DESCRIPTION

142 318123910 A B Deflector

* 5303324184 A B Screw, 8-18 x 5/16, black, (4)

143 318172904 A B Support, wire

163 318014111 A B Spacer

185 318014700 A B Spacer, oven shield, (4)

219# 318003614 A B Thermostat, safety

219A 318003613 A B Thermostat, safety, 1.375" mtg, 105/120

264 318257701 A B Trim, oven, black, front

310 5304440067 A B Cabinet Mounting Kit

311 318246010 A B Bracket, cabinet mtg, (2)

311* 5304438005 A B Screw, 6 x 1, black

312 318246702 A B Tool, cabinet bracket, RH

312 318246703 A B Tool, cabinet bracket, LH

* # 318078542 A B Box & wires assy

* # 318231735 A B Harness, wiring, main

* 5303323136 A B Screw ground

* 5303211311 A B Screw, 8 x 0.500

* 5303323139 A B Screw, 10-24 x 0.906

* 5303323277 A B Screw, 8-18 X 13/32

* 5304436875 A B Screw, 8-18 X 1/2, black

Publication No: 5995489928 FEB30S5D

05/07 8

DOOR

DFES365ESD

FEB30S5D Publication No: 5995489928

# Functional Parts 9 05/07

* Non-Illustrated Parts

DOOR

Model Index: AFEB30S5D (FEB30S5DBF)

BFEB30S5D (FEB30S5DSF)

POS. NO PART NO. DESCRIPTION

3 318260201 A B Trim, oven door, black, upper

3A 318260401 A B Trim, oven door, side, (2)

4 318261300 A - Glass Assy., oven door, black, outer, w/trim

4 318261301 - B Glass Assy., oven door, white, outer, w/trim

6 318260520 A B Baffle, door

7 318372000 A B Insulation, door, (2)

7A 318372002 A B Insulation, door, (2)

8 316117500 A B Glass, oven door, heat barrier

9 318259601 A B Liner, oven door, upper

10 5304453223 A B Screw, handle mtg, 10-14 x 1.82, (2)

12 318053130 A B Seal, oven door, upper

16 318212210 A B Glass, oven door, heat barrier

17 316402403 A B Spacer, door glass, (2)

23 318024722 A B Hinge, door, upper, (2)

29 318014402 A B Spacer, door

39 316270200 A - Handle, door, black

39 316270201 - B Handle, door, white

42 318382301 A B Bracket, glass retainer, (4)

56 5304436875 A B Screw, 8-18 X 1/2, black

64 318165800 A B Spacer

* 08016432 A B Screw, truss head, 8-18 x 0.375

* 5303211311 A B Screw, 8 x 0.500

* 5303323277 A B Screw, 8-18 X 13/32

Publication No: 5995489928 FEB30S5D

05/07 10

WIRING DIAGRAM
