Frigidaire PLEB27T8A Manuale utente

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET

PLEB27T8ACA PLEB27T8A 37057793G10S1 black North America

Publication No.

5995360988

011113

-EN/SERVICE /ECL

377

ELECTRIC

WALL OVEN

Model No.

PLEB27T8A

FACTORY PARTS CATALOG

RANGE

WIRING DIAGRAM - # 318046110

OWNER’S GUIDE - # 318200919

TIMER INSTRUCTION SHEET - # 318200130

INSTALLATION INSTRUCTIONS - # 318201509

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O. BOX 212378, Augusta, GA 30917

11/01 2

Publication No. PLEB27T8ACA

5995360988

CONTROL PANEL

# = Functional Parts 3 11/01

* = Non-Illustrated Parts

PLEB27T8ACA Publication No.

5995360988

CONTROL PANEL

POS. NO PART NO DESCRIPTION

19 318030214 Panel,control ,black ,back

19A 318192801 Panel,control ,stainless ,front

20 # 318010501 Clock/Timer,EOC

21 318028331 Trim,canopy

23 318015110 Bracket,clock mtg

42 318027310 Trim,vent

78 318037200 Cover,oven vent ,stainless

79 318029603 Trim,top

80 # 318022001 Relay Board

81 # 318022002 Relay Board,w/transformer

82 318023600 Support,relay board ,(2)

82A 5303317199 Support,snap-in ,(3)

96 316037700 Seal,vent cover

97 316037801 Tape,vent cover

99 5303307406 Screw,6-32 x 3/8 ,(2)

* 218490900 Cleaner,stainless steel

* 5303300414 Spacer,cork & rubber

* 3201861 Screw,6 x 0.375

* 5303320848 Screw,6-20 x 0.250

* 5303323136 Screw ground

11/01 4

Publication No. PLEB27T8ACA

5995360988

UPPER OVEN

# = Functional Parts 5 11/01

* = Non-Illustrated Parts

PLEB27T8ACA Publication No.

5995360988

UPPER OVEN

POS. NO PART NO DESCRIPTION

1A 318071000 Back,main ,upper

2 318070203 Shield,oven top

3 318070601 Panel,bodyside ,upper,RH

3A 318070600 Panel,bodyside ,upper,LH

6 318025300 Rack,oven

6A 5303311206 Shelf,broiler pan

6B 318025200 Shelf,oven

9 5303317977 Pan,broiler

10 5303317976 Insert,broiler pan

12 318089910 Switch,oven light ,door frame

14 # 5308011085 Receptacle,oven light

15 # 3201908 Light,oven

16 3201911 Cover,oven light ,glass

17 5304400195 Retainer,light cover

37 # 316111203 Sensor,oven temp probe

41 5303310526 Cover,hinge cutout

54 5303310514 Housing,oven light

57 318072100 Plate,connection

58A 5303311218 Insulation,oven wrapper

58B 5303311219 Insulation,oven back

59 318072511 Tube,oven vent

62 # 5303310518 Terminal Block

66 # 5303322963 Element,broil

67 # 5303299718 Element,bake

68 5304403015 Support,element hanger

76 318056104 Front,oven

80 5303301261 Spring,oven

81 5303320846 Plate,oven mtg

83 318089519 Liner,oven assy

86 5303310524 Receptacle,hinge

88 5303311222 Rod,latch

89 # 318095934 Motor,latch assy ,w/brkt & switch

89*# 318120710 Switch,cooktop shutoff

97 318066500 Wrapper,back & sides

99 318055200 Support

107 5303318711 Cover,fan

108# 318073012 Motor,blower

109 5303311203 Blade,fan

111 5303311205 Nut,fan retainer

119# 318005200 Switch,thermal ,lower

123 318071441 Shield,insulation ,top & sides

125# 5303311202 Motor,convection

127 5303310542 Adapter,vent tube ,with converter

128 5303311163 Bushing

129 5303311164 Spring

156 318024100 Bracket,vent tube

157 318071601 Divider,upper oven

187 318013501 Tube,latch rod

222 318080000 Plate,oven temp probe

263 5303322885 Spacer,fan blade

264 318143811 Shield,wire

* # 318078501 Box & wires assy

* 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

* 5303211311 Screw,8 x 0.500

* 5303323136 Screw ground

* 5303323139 Screw,10-24 x 0.906

11/01 6

Publication No. PLEB27T8ACA

5995360988

LOWER OVEN

# = Functional Parts 7 11/01

* = Non-Illustrated Parts

PLEB27T8ACA Publication No.

5995360988

LOWER OVEN

POS. NO PART NO DESCRIPTION

6 318025300 Rack,oven

6B 318025200 Shelf,oven

12 318089910 Switch,oven light ,door frame

14 # 5308011085 Receptacle,oven light

15 # 3201908 Light,oven

16 3201911 Cover,oven light ,glass

17 5304400195 Retainer,light cover

37 # 316111203 Sensor,oven temp probe

41 5303310526 Cover,hinge cutout

54 5303310514 Housing,oven light

56 318145515 Trim,bodyside ,(2)

58A 318133750 Insulation,oven wrapper

58B 318133749 Insulation,oven back

59 3016331 Tube,oven vent

66 # 5303322963 Element,broil

67 # 5303299718 Element,bake

68 5304403015 Support,element hanger

71 318071120 Shield,rear wall

76 318056104 Front,oven

80 5303301261 Spring,oven

81 5303320846 Plate,oven mtg

82 5303304699 Shield,insulation

83 318089519 Liner,oven assy

86 5303310524 Receptacle,hinge

88 5303311222 Rod,latch

89 # 318095934 Motor,latch assy ,w/brkt & switch

89*# 318120710 Switch,cooktop shutoff

96 5303317197 Duct,oven vent ,assy

96A 3016325 Duct,oven vent ,center

96B 3016327 Duct,vent pipe

97 318066604 Wrapper,back & sides

98 318029310 Trim-side,inner,RH

98A 318029311 Trim-side,inner,LH

99 318055200 Support

101 318039501 Bracket,trim ,black

103 5303316773 Trim,base ,black ,lower

107 5303318711 Cover,fan

109 5303311203 Blade,fan

111 5303311205 Nut,fan retainer

119# 318004900 Switch,thermal

121 318145002 Wrapper,base

123 318071441 Shield,insulation ,top & sides

125# 5303311202 Motor,convection

127 318072801 Adaptor assy

128 5303311163 Bushing

129 5303311164 Spring

142 318054900 Support

156 5303317198 Bracket,oven vent

187 318013501 Tube,latch rod

188 08007817 Spacer,(6)

222 318080000 Plate,oven temp probe

227 5303323955 Clip,retainer

263 5303322885 Spacer,fan blade

265 318029502 Trim,bodyside ,stainless ,outer,RH

265A 318029503 Trim,bodyside ,stainless ,outer,LH

* 3015722 Clip-wire

* 5303304015 Washer,padded

* 5304407813 Washer

* 08002868 Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

* 5303211311 Screw,8 x 0.500

* 5303302745 Screw,10-16x1-1/8 ,square drive

* 5303311528 Screw,oval hd sq dr ,6-20AB x 0.625 ,black

* 5303323136 Screw ground

* 5303323139 Screw,10-24 x 0.906

* 5303323277 Screw (8-18X13/32)

11/01 8

Publication No. PLEB27T8ACA

5995360988

DOOR

# = Functional Parts 9 11/01

* = Non-Illustrated Parts

PLEB27T8ACA Publication No.

5995360988

DOOR

POS. NO PART NO DESCRIPTION

4 318210701 Glass,oven door ,black ,outer

6 318073500 Shield,air wash

7 318133751 Insulation,oven door

9 318048501 Liner,oven door

10 5303311217 Screw,handle ,door

12 318053100 Seal,oven door

13 318009201 Panel,oven door ,stainless ,exterior

15 318091101 Bracket,glass ,(3)

16 318042300 Glass,oven door ,heat barrier ,(2)

17 318042000 Spacer,glass

18 318053000 Seal,rope

20 318086020 Spacer,handle ,(2)

22 5303310511 Bar,glass retainer

23 5303320452 Hinge,oven door

29 318014400 Spacer,door

31 318065102 Latch,door

32 318056703 Deflector,4.25" x 17"

39 318197900 Handle,oven door ,stainless

54 5303308456 Screw,8-18 x 0.531 ,black ,door frame

59 3202113 Plug,button

61 5303316982 Foam seal,(3)

* 5303308450 Screw,8 x 0.375

* 5303323277 Screw (8-18X13/32)

11/01 10

Publication No. PLEB27T8ACA

5995360988

WIRING DIAGRAM
