Fujitsu PRIMERGY RX330 S1 Manuale utente

PRIMERGY RX330 S1 Server

Operating Manual

Edition May 2007

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

RX330 S1 Operating manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . 7

1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 16

1.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 17

2 Installation steps, overview . . . . . . . . . . . . . . . . . . 19

3 Important information . . . . . . . . . . . . . . . . . . . . . 21

3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 28

3.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 29

3.5 Notes on installing in the rack . . . . . . . . . . . . . . . . . 30

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 31

4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 33

4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 34

4.2 Installing/removing the server in/from the rack . . . . . . . 35

4.2.1 Installation in PRIMECENTER/DataCenter Rack . . . . . . . . 39

4.2.2 Installation in 3rd party racks . . . . . . . . . . . . . . . . . . 42

4.2.3 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 43

4.3 Connecting devices to the server . . . . . . . . . . . . . . . 45

4.4 Connecting the server to the mains . . . . . . . . . . . . . . 47

4.5 Notes on connecting/disconnecting cables . . . . . . . . . 48

Operating manual RX330 S1

Contents

5 Starting up and operation . . . . . . . . . . . . . . . . . . . 49

5.1 Controls and displays . . . . . . . . . . . . . . . . . . . . . . 49

5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 49

5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.2 Switching the server on and off . . . . . . . . . . . . . . . . 56

5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 58

5.3.1 Configuring onboard SAS controller . . . . . . . . . . . . . . . 58

5.3.2 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 59

5.3.3 Configuration without ServerStart . . . . . . . . . . . . . . . . 60

5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 60

6 Property and data protection . . . . . . . . . . . . . . . . . . 61

6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 61

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 63

7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 63

7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 64

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 64

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 65

7.5 No screen display or display drifts . . . . . . . . . . . . . . . 65

7.6 No mouse pointer displayed on screen . . . . . . . . . . . . 65

7.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 66

7.8 System will not boot . . . . . . . . . . . . . . . . . . . . . . . 66

7.9 Drives reported as “dead” when starting system . . . . . . . 67

7.10 Added drive reported as defective . . . . . . . . . . . . . . . 67

7.11 Error message on screen . . . . . . . . . . . . . . . . . . . . 67

RX330 S1 Operating manual

Contents

8 Hot-plug components . . . . . . . . . . . . . . . . . . . . . 69

8.1 Hot-plug power supply units . . . . . . . . . . . . . . . . . 69

8.1.1 Remove the dummy module . . . . . . . . . . . . . . . . . . . 70

8.1.2 Installing/removing the hot-plug power supply unit . . . . . . . 71

8.1.3 Replacing the hot-plug power supply unit . . . . . . . . . . . . 72

8.2 Hot plug hard disk drives . . . . . . . . . . . . . . . . . . . 73

8.2.1 Handling hard disk drives and HDD modules . . . . . . . . . . 75

8.2.2 Removing/Installing the dummy module . . . . . . . . . . . . . 76

8.2.3 Installing/removing the HDD module . . . . . . . . . . . . . . 77

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

RX330 S1 Operating manual 7

1 Introduction

The PRIMERGY RX330 S1 server is an AMD-based server for workgroups and

small networks. The server is suitable for use as a file server and also as an

application, information or Internet server.

Thanks to its highly developed hardware and software components, the

PRIMERGY RX330 S1 server offers a high level of data security and availability.

These components include hot-plug hard disk modules, redundant power

supply units, and the Server Management ServerView Suite, Prefailure Detection

and Analysing (PDA) and Automatic Server Reconfiguration and Restart

(ASR&R).

Security functions in the BIOS setup protect the data on the server against

manipulation. Additional security is provided by the lockable rack door.

The server occupies 2 height units (HU) in the rack.

1.1 Documentation overview

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD. The ServerBooks DVD is part of the ServerStart Suite supplied with

every server.

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL:

http://manuals.fujitsu-siemens.com. The PRIMERGY server documentation

can be accessed using the Industry standard servers navigation option.

Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This manual is intended for those people responsible for installing the hardware

and ensuring that the system runs smoothly. The manual contains all the infor-

mation required to install and operate your PRIMERGY RX330 S1.

It is assumed that users have some knowledge of hardware and data trans-

mission, and a basic familiarity with the operating system that is being used.

8 Operating manual RX330 S1

Documentation overview Introduction

Additional server documentation

The PRIMERGY RX330 S1 documentation also includes:

– “Quick Start Hardware - PRIMERGY RX330 S1” (leaflet)

– “Quick Start Software - PRIMERGY ServerView Suite” (leaflet)

– “Warranty” manual (print version supplied with the system, PDF file available

on the ServerBooks DVD supplied)

– “Safety notes and other important information” manual (print version

supplied with the system, PDF file available on the ServerBooks DVD

supplied)

– “Ergonomics” manual (PDF file available on the ServerBooks DVD supplied)

– “Returning used devices” manual (PDF file available on the ServerBooks DVD

supplied)

– “Helpdesk” (leaflet with worldwide helpdesk telephone numbers)

– Technical manual for the system board D2440 (PDF file available on the

ServerBooks DVD supplied)

– “BIOS Setup” (PDF file available on the ServerBooks DVD supplied)

– “PRIMERGY RX330 S1 Server Options Guide” (PDF file available on the

ServerBooks DVD)

IThe “Options Guide” describes the server expansion and modifi-

cation options.

– “ServerView Suite” includes the ServerStart Disc 1, the ServerStart Disc 2

and the ServerBooks DVD. The version of the

“PRIMERGY ServerView Suite - ServerStart” user manual is available on

the ServerBooks DVD.

IIf you need a replacement copy of the ServerBooks DVD, send the

details of your server to the following e-mail address: Reklamat-PC-

[email protected]

– “ServerView RAID User Manual” (PDF file available on the ServerBooks DVD

supplied)

– “Integrated RAID for SAS User’s Guide” (PDF file available on the

ServerBooks DVD supplied)

– “Integrated Mirroring User’s Guide” (PDF file available on the supplied

ServerBooks DVD)

– “LSI SATA Software RAID User’s Guide” (PDF file available on

theServerBooks DVD supplied)

RX330 S1 Operating manual 9

Introduction Features

Further sources of information:

– Technical Manual for the relevant rack

– Manual for the monitor

– Manual on ServerView Server Management

– Manual for the remote testing and diagnostic system RemoteView

– Documentation for boards and drives

– Documentation for your operating system

– Information files on your operating system

(See also “Literature” on page 87.)

1.2 Features

System board

The features of the system board are described in the technical manual for the

system board D2440 for the hardware and in the “BIOS Setup” for the firmware

(see “Literature” on page 87).

Hard disk drives

The server includes two drive cages with up to six (2x3) SAS/SATA2 hard disk

modules. Each hard disk module can accommodate an SAS/SATA2 hard disk

drive with a maximum height of 1 inch. The module is connected to the

SAS/SATA2 backplane wirelessly. This allows hard disk drive modules to be

simply plugged in or pulled out (for further details see “Hot plug hard disk drives”

on page 73).

The hard disk subsystem is designed for SAS/SATA 2, each with one channel

for each hard disk drive.

If the server has the corresponding RAID configuration, HDD modules can also

be exchanged during operation.

10 Operating manual RX330 S1

Features Introduction

Onboard SAS controller with Integrated Mirroring Enhanced functionality

An onboard SAS controller with "Integrated Mirroring Enhanced" (IME) function-

ality is fitted to operate the six hard drives. IME also offers RAID functionality for

configuring the internal hard disk drives (RAID level 0, 1).

IA separate utility is available to the controller for IME configuration.

Further information can be found in the "Integrated RAID for SAS User’s

Guide" (on the ServerBooks DVD under "Controllers").

The RAID functionality can optionally be expanded with a corresponding PCI

expansion module (zero-channel RAID controller). In addition to RAID levels 0

and 1, this RAID controller also offers the option of configuring RAID 5. The ZCR

controller uses the Onboard SAS controller using logic that is specially

integrated on the system board.

Accessible drives

A 5.25 inch bay is available for a CD/DVD drive or a magnetic tape drive. The

accessible drive installed here cannot be replaced during operation.

USB port

The USB interface on the front of the server supports activities carried out by

the service technician. The maximum length of the external cable are three

meters.

Power supply

The basic configuration of the server includes a hot-plug power supply unit,

which automatically sets itself to a mains voltage in the range of 100 V - 127 V

or 200 V - 240 V. As an option, the power supply can be expanded with an extra

power supply unit to create a redundant power supply. If a power supply unit

fails, the redundant configuration assures continued operation. The defective

power supply unit can be replaced during operation (for further details see “Hot-

plug power supply units” on page 69).

High level of availability and data security

When memory data is accessed, 1-bit errors in the main memory are identified

and automatically corrected with the ECC (Error Correcting Code) method. The

patented memory scrubbing function regularly starts up the EDC mechanism

and thus ensures continuous data integrity.

Altri manuali per PRIMERGY RX330 S1

Indice

Altri manuali Fujitsu Server

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Istruzioni per il montaggio

Fujitsu

Fujitsu PRIMERGY MX130 S1 Manuale utente

Fujitsu

Fujitsu PRIMERGY RX600 S3 Manuale del proprietario

Fujitsu

Fujitsu FUTRO S5010 Manuale utente

Fujitsu

Fujitsu Primergy RX300 S2 Guida

Fujitsu

Fujitsu Primergy Econel 100 S2 Guida

Fujitsu

Fujitsu PRIMERGY 300 Manuale utente

Fujitsu

Fujitsu PRIMERGY TX200 S7 Manuale utente

Fujitsu

Fujitsu PRIMERGY RX2540 M1 Manuale utente

Fujitsu

Fujitsu PRIMERGY BX924 S4 Manuale utente

Fujitsu

Fujitsu PRIMERGY TX200 S2 Manuale utente

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Istruzioni operative e di manutenzione

Fujitsu

Fujitsu PRIMERGY 10/40GbE Manuale utente

Fujitsu

Fujitsu PRIMERGY RX330 S1 Manuale del proprietario

Fujitsu

Fujitsu primergy TX150 Manuale utente

Fujitsu

Fujitsu PRIMERGY BX924 S3 Manuale utente

Fujitsu

Fujitsu PRIMERGY GX2570 M6 Manuale utente

Fujitsu

Fujitsu BX630 - PRIMERGY - S2 Dual Manuale del proprietario

Fujitsu

Fujitsu PRIMERGY TX1320 M4 Manuale utente

Fujitsu

Fujitsu PRIMERGY RX600 S4 Manuale utente

Fujitsu

Fujitsu PRIMERGY Econel 50 Manuale del proprietario

Fujitsu

Fujitsu Primergy BX900 S2 Manuale utente

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuale di servizio

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Manuale utente

Manuali Server popolari di altre marche

HP AlphaServer ES47 Manuale utente

Dell

Dell PowerEdge R410 Manuale utente

PowerNAS

PowerNAS CMA Manuale utente

Supero

Supero FatTwin F617R3-FT Manuale utente

MSI

MSI P1-109N-L70 Manuale utente

Dell

Dell PowerEdge XE9640 Manuale

Dell

Dell PS4100 Istruzioni di montaggio

EtroVISION

EtroVISION EV3151 Manuale utente

NEC

NEC Express5800/T110j Manuale utente

HP ProLiant Gen9 Manuale utente

Compaq

Compaq ProLiant 3000 Manuale

Dell

Dell PowerEdge 3YPMN Manuale utente

iRobo

iRobo IPC2U Manuale utente

Nortel

Nortel 1000 Con?guration guide Manuale utente

Asus

Asus AP7500 Manuale operativo e di manutenzione

Avid Technology

Avid Technology AirSpeed 5000 Manuale utente

HP Integrity rx2600 Guida all'installazione

Milestone

Milestone Husky IVO 350T Manuale utente
