Hamilton Beach 14963 Manuale utente

English ......................................................................................... 2

USA: 1-800-851-8900

Visit www.hamiltonbeach.com for our complete line of products and Use and Care

Guides – as well as delicious recipes, tips, and to register your product online!

Français ..................................................................................... 14

Canada : 1-800-267-2826

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de

nos manuels utilisateur – ainsi que nos délicieuses recettes, nos conseils, et pour

enregistrer votre produit en ligne !

Español ...................................................................................... 28

En México: 01 800 71 16 100

¡Visite www.hamiltonbeach.com.mx para obtener nuestra línea completa de

productos y las Guías de Uso y Cuidado, además de deliciosas recetas, consejos,

y para registrar su producto en línea!!

Irons

Fer à repasser

Planchas

840164303

Le invitamos a leer cuidadosamente este

instructivo antes de usar su aparato.

READ BEFORE USE

À LIRE AVANT UTILISATION

LEA ANTES DE USAR

840164303 ENv01.indd 1840164303 ENv01.indd 1 8/22/14 1:06 PM8/22/14 1:06 PM

When using your flat iron, basic safety precautions should always

be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING

1. Only use an iron for its intended use.

2. To avoid the risk of electric shock, do not immerse the iron in

water or other liquids.

3. Always turn the iron to OFF before plugging or unplugging

the iron from the electrical outlet. Never pull on the cord to

disconnect the iron from the electrical outlet; instead, grasp

the plug and pull on the plug to disconnect the iron.

4. Do not let the cord touch hot surfaces. Let the iron cool

completely before putting the iron away. Coil the cord loosely

around the iron when storing.

5. Always disconnect the iron from the electrical outlet before

filling the iron with water, emptying the water from the iron,

and when the iron is not in use.

6. Do not operate the iron with a damaged cord or in the event

the iron has been dropped or damaged or there are visible signs

of damage or it is leaking. To avoid the risk of electric shock,

do not disassemble the iron. Take it to a qualified serviceman for

examination and repair. Incorrect assembly might result in a

risk of electric shock when the iron is used after reassembly.

7. The iron must be used and rested on a stable surface.

8. When placing the iron on its stand, ensure that the surface

on which the stand is placed is stable.

9. Close supervision is required for any appliance used by or near

children. Do not leave the iron unattended while the iron is

connected or on an ironing board.

10. Burns can occur from touching hot metal parts, hot water, or

steam. Use caution when you turn a steam iron upside down—

there might be hot water in the reservoir.

IMPORTANT SAFEGUARDS

840164303 ENv01.indd 2840164303 ENv01.indd 2 8/22/14 1:06 PM8/22/14 1:06 PM

OTHER CONSUMER SAFETY INFORMATION

This appliance is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug (one

wide blade) that reduces the risk of electric shock. The plug fits only

one way into a polarized outlet. Do not defeat the safety purpose of

the plug by modifying the plug in any way or by using an adapter.

If the plug does not fit fully into the outlet, reverse the plug. If it still

does not fit, have an electrician replace the outlet.

• Use the iron on an ironing board. Ironing on any other surface may

damage that surface.

• Do not iron or vertical-steam clothes that are being worn.

• Do not use vertical steam in the direction of people or pets.

Please Read Before First Use:

• During first use of the iron, it may appear to smoke. This will stop

and does not indicate a defect or hazard.

• Many irons spit or sputter during the first few uses with tap water.

This happens as the steam chamber becomes conditioned. This

will stop after a few uses.

•

To clean steam vents before first use, prepare iron for steam ironing

and then iron over an old cloth for a few minutes while letting the

iron steam. Press the Blast button several times to clean the vents.

Then follow the Self-Cleaning instructions on page 10.

11. To avoid a circuit overload, do not operate an iron on the same

circuit with another high-wattage appliance.

12. If an extension cord is absolutely necessary, a cord with an

ampere rating equal to or greater than the maximum rating of

the iron shall be used. A cord rated for less amperage can result

in a risk of fire or electric shock due to overheating. Care shall

be taken to arrange the cord so that it cannot be pulled or be

tripped over.

SAVE THESE INSTRUCTIONS

840164303 ENv01.indd 3840164303 ENv01.indd 3 8/22/14 1:06 PM8/22/14 1:06 PM

Parts and Features

Spray Steam

Steam ON/OFF

Control

Water Fill

Cover

Steam

ON/OFF Control

Spray and Blast

Buttons

Self-Clean

Button

Swivel

Power

Cord

Heel

Rest

Temperature

Control Dial

Auto Shutoff

Reset Light

(GREEN)

and Power

ON Light

(RED)

Soleplate

840164303 ENv01.indd 4840164303 ENv01.indd 4 8/22/14 1:06 PM8/22/14 1:06 PM

This iron is equipped with a position/motion sensor. This means

that if the iron is left motionless it will turn off automatically and

cool to room temperature.

To restart iron, simply move the iron and allow it to reheat on

the heel rest position.

The iron will reheat to the previously selected setting.

Sensor Control

Auto Shutoff Reset Light

After 30 seconds of no movement in the horizontal position,

the iron will automatically shut off and the green light will

blink. Move iron upright to vertical position to turn back on.

IRON POSITION

Resting on soleplate

Resting on either side

Resting on heel

POSITION SENSING

The iron will turn off automatically when left in the following

positions. The auto off time varies based on the iron’s

position.

MOTIONLESS TIME

30 seconds

30 seconds or 15 minutes

depending on exact

orientation

15 minutes

840164303 ENv01.indd 5840164303 ENv01.indd 5 8/22/14 1:06 PM8/22/14 1:06 PM

1. Plug the iron into outlet.

2. Set Steam ON/OFF Control to

O (Dry Iron).

3. Turn Temperature Control Dial to

desired temperature. Allow 2 minutes

for iron to reach desired temperature.

4. To turn iron OFF, turn Temperature

Control Dial to OFF and unplug iron.

1. Unplug iron. Set Steam ON/OFF Control to O (Dry Iron)

Hold iron with soleplate parallel to the ground. Open water

fill cover.

2. Using a cup, slowly pour tap water into water tank opening

until MAX fill line is reached. Close water fill cover. Do not

fill iron directly from the faucet.

3. Plug iron into outlet.

4. Turn Temperature Control Dial to desired fabric setting in

the steam range.

5. Allow 2 minutes for the iron to reach desired temperature.

6. Set Steam ON/OFF Control to .

7. To turn iron off, set Set Steam ON/

OFF Control to O (Dry Iron). Turn the

Temperature Control Dial to OFF.

Unplug iron.

8. Empty water from the iron following

directions in “Caring and Cleaning.”

To Dry Iron

To Steam Iron

840164303 ENv01.indd 6840164303 ENv01.indd 6 8/22/14 1:06 PM8/22/14 1:06 PM

Water: Please use ordinary tap water. If you have extremely

hard water, alternate between tap water and distilled water

for use in the iron.

1. Follow Steps 1 through 5 in

“To Steam Iron.”

2. Hang garment in a location that is

not susceptible to damage from heat

or moisture. Do not hang in front of

wallpaper, window, or mirror.

3. Hold iron about 6 inches (15 cm) away

from garment and press and release

the Blast Button to steam out wrinkles. Do not press

Blast Button more than once every 5 seconds.

4. To turn iron off, set Set Steam ON/OFF Control to O

(Dry Iron). Turn the Temperature Control Dial to OFF.

Unplug iron.

5. Empty water from the iron following directions in “Caring

and Cleaning.”

NOTICE: Do not allow hot soleplate to touch delicate

garments.

To Steam Iron (cont.)

To Vertical Steam

840164303 ENv01.indd 7840164303 ENv01.indd 7 8/22/14 1:06 PM8/22/14 1:06 PM

Features

Steam ON/OFF Control

This control turns steam ON or

OFF (O).

Power ON Light

The red light stays on even if Temperature Control Dial is

turned to OFF.

Spray and Steam Buttons

Push Spray Button to release a fine

spray of water for difficult wrinkles in

cotton or linen. Push Steam Button

for an extra blast of steam.

Spray Steam

840164303 ENv01.indd 8840164303 ENv01.indd 8 8/22/14 1:06 PM8/22/14 1:06 PM

Caring and Cleaning

Iron Storage

1. The water tank of your iron should be emptied after each

use. Turn Temperature Control Dial to OFF. Unplug the

iron and hold over a sink. Slowly tilt pointed end of iron

down over sink. Water will run out of water tank opening.

After iron has completely cooled, wrap cord loosely around

iron and store in an upright position. Do not store iron laying

flat on soleplate.

Soleplate

1. Never iron over zippers, pins, metal rivets, or snaps, since

these may scratch the soleplate.

2. To clean occasional buildup on the soleplate, wipe with

a sudsy cloth. Do not use abrasive cleansers or metal

scouring pads.

3. Always store iron upright in the heel rest position.

840164303 ENv01.indd 9840164303 ENv01.indd 9 8/22/14 1:06 PM8/22/14 1:06 PM

Caring and Cleaning (cont.)

Self-Clean

To keep the steam vents clear of any buildup, follow these

instructions each time you iron using steam.

1. Set Temperature Control Dial to OFF. Fill iron with water to

1/2 of its maximum capacity.

2. Set Steam ON/OFF Control to O(Dry Iron). Set

Temperature Control Dial to Linen setting and let iron heat

for 2 minutes.

3. Set Temperature Control Dial to OFF. Unplug iron and hold

over a sink with soleplate facing down.

4. Press and hold the Self-Clean Button. Boiling water and

steam will flow out of steam vents. Allow all water to drain

from iron.

5. Gently move iron front to back to allow water to clean

entire soleplate area.

6. If water still remains inside of soleplate, reheat iron as

indicated in Step 2. Boiling water and steam could still

flow out of steam vents.

Troubleshooting

Iron won’t

heat

PROBLEM PROBABLE CAUSE

• Is the iron plugged in and the outlet working?

Check the outlet by plugging in a lamp.

• Is the Temperature Control Dial turned to a

fabric setting?

• If automatic shutoff model, is the Reset Light

flashing? Move the iron to reset.

840164303 ENv01.indd 10840164303 ENv01.indd 10 8/22/14 1:06 PM8/22/14 1:06 PM

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Hamilton Beach Ferro

Hamilton Beach

Hamilton Beach 14600 Manuale di programmazione

Hamilton Beach

Hamilton Beach HIR800 Manuale utente

Hamilton Beach

Hamilton Beach 840101300 Manuale utente

Hamilton Beach

Hamilton Beach 840131600 Manuale utente

Hamilton Beach

Hamilton Beach 840129100 Manuale utente

Hamilton Beach

Hamilton Beach 14671 Manuale del proprietario

Hamilton Beach

Hamilton Beach HIR750 DURATHON IRON Manuale utente

Hamilton Beach

Hamilton Beach Proctor Silex Manuale del proprietario

Hamilton Beach

Hamilton Beach 840111900 Manuale utente

Hamilton Beach

Hamilton Beach 14565 - Lightweight Iron Manuale del proprietario

Hamilton Beach

Hamilton Beach HIR200R Manuale utente

Hamilton Beach

Hamilton Beach 14978 Manuale del proprietario

Hamilton Beach

Hamilton Beach 14885C Manuale utente

Hamilton Beach

Hamilton Beach 14401 Manuale utente

Hamilton Beach

Hamilton Beach 14010 Manuale del proprietario

Hamilton Beach

Hamilton Beach 840121900 Istruzioni per l'installazione

Hamilton Beach

Hamilton Beach 14506 Manuale del proprietario

Hamilton Beach

Hamilton Beach Durathon 19800 Manuale utente

Hamilton Beach

Hamilton Beach 14210 Manuale utente

Hamilton Beach

Hamilton Beach 840121300 Manuale utente

Hamilton Beach

Hamilton Beach 19702-IS Manuale utente

Hamilton Beach

Hamilton Beach 14340 - Digital Iron A O Spray Manuale del proprietario

Hamilton Beach

Hamilton Beach 840164201 Manuale utente

Hamilton Beach

Hamilton Beach 14505 Manuale del proprietario

Manuali Ferro popolari di altre marche

Clatronic

Clatronic DB 3703 Manuale utente

TEFAL

TEFAL FV4093Z0 Manuale utente

Gorenje

Gorenje SIH 2200 BS Manuale utente

Philips

Philips GC6012 Manuale utente

Bosch

Bosch 2 Series Manuale utente

Riffel

Riffel Catena KB-819 Manuale utente

Texi

Texi Hestia Manuale utente

Maxwell

Maxwell MW-3010 Manuale utente

TREVIDEA

TREVIDEA Girmi ST60 Manuale utente

Philips

Philips HI5914/30 Manuale utente

Primula

Primula Vapormat Manuale utente

Magio

Magio MG-541 Manuale utente

Scarlett

Scarlett SC-1334S Manuale utente

Bosch

Bosch Sensixx B22L Manuale utente

Philips

Philips GC651 Manuale utente

Vitek

Vitek VT-1247 VT Manuale utente

Cleanmaxx

Cleanmaxx 3397 Manuale utente

Philips

Philips GC800 Manuale utente
