IBASE Technology MB835 Manuale utente

MB835

Intel®EP80579

Motherboard

USER’S MANUAL

Version 1.0

MB835 User’s Manual

Acknowledgments

Award is a registered trademark of Award Software International,

Inc.

PS/2 is a trademark of International Business Machines

Corporation.

Intel and Intel EP80579 Integrated Processor are registered

trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

MB835 User’s Manual iii

Table of Contents

Introduction.......................................................1

Product Description.............................................................1

Checklist..............................................................................2

MB835 Specifications.........................................................3

Board Dimensions...............................................................5

Installations.......................................................7

Setting the Jumpers .............................................................8

Connectors on MB835 ......................................................12

BIOS Setup.......................................................19

Drivers Installation......................................39

Appendix...........................................................41

Bypass and WDT ..............................................................41

Watchdog Timer Configuration........................................43

MB835 User’s Manual

This page is intentionally left blank.

INTRODUCTION

MB835 User’s Manual

Introduction

Product Description

The MB835 motherboard incorporates the Intel® EP80579 Integrated

Processor for embedded computing. The EP80579 System on a Chip

(SoC) is a new generation processor that is cost optimized for a wide

range of applications. EP80579 delivers the balance of a powerful IA-32

processor core, standards-based chipset, and acceleration

/communications-focused I/O capabilities.

The EP80579 SoC integrates features into a single device with memory

controller hubs (IMCH) and I/O controller hubs (IICH). The IMCH has

built-in memory controllers for external memory and the IICH has

standard IA I/O peripheral capabilities.

The MB835’s EP80579 IA-32 core is a derivative of the Intel®

Pentium® M processor. This low power IA-32 core is based on 90-nm

process technology featuring 256-Kbyte L2 cache and 400/533 MHz

quad-pumped internal front-side bus (FSB). With two DDR2 DIMM

sockets on board, the board supports up to 2GB of DDR2 system

memory. It integrates three Gigabit Ethernet MAC interfaces. The MAC

fully implements the IEEE 802.3z, Carrier Sense Multiple Access with

Collision Detection (CSMA/CD) method and physical layer

specifications The GbE features include RGMII/RMII interface to PHY

devices Multi-speed operation 10/100/1000 Mbps.

The main features of the ECX810 board are:

Supports Intel EP80579 processors in 600/1066/1200MHz.

EP80579 built-in USB 2.0 host controller supports 2 ports.

EP80579 built-in SATA controller supports 2 ports.

Two DDR2 SDRAM DIMM, Max. 2GB memory.

Integrated Three Gigabit Ethernet MACs + PHY.

Intel 82574L PCI-E X1 Controller.

2x SATA, 2x USB 2.0, 4x COM, Watchdog timer.

Interface connector for daughter board (ID835/IBP835).

INTRODUCTION

MB835 User’s Manual

Checklist

Your ECX810 package should include the items listed below.

•The MB835 Mother board

•This User’s Manual

•1 CD containing chipset drivers and flash memory utility

•Optional cables for: Keyboard/mouse, Serial port, Serial ATA

INSTALLATION

MB835 User’s Manual 3

MB835 Specifications

Model MB835 Motherboard

Form Factor Custom Size

Processor Intel EP80579 SOC processor with ASU & SSU

Frequency: 600 / 1000 /1200 MHz

L2 cache: 256kb

Memory 2x DDR2 sockets, supporting DDR2 400,533,667 and 800 Max 2GB memory

with ECC (600Mhz CPU at DDR2 533 only)

Chipset Integrated Intel® Architecture (IA) processor and chipset (MCH/ICH)

technology; 1088-Ball FCBGA package

BIOS Award BIOS

PCIe Switch PEX8509 of PLX: Gen1 8Lanes / 8Ports PCIe switch (up: 4 lanes

/down:1lanes)

Connect from: PCIeX4 bus of EP80579

Connect to : Intel 82574L GbE

JM368 PCIe to PATA bridge

PEX8112 PCIe to PCI bridge

PCIeX1 golden finger

PCI bridge PEX8112 of PLX: PCIe to PCI bridge, max for 4PCI

Connect from: PCIeX1 bus of PEX8509 downstream

Connect to: HIFN 7964 IPSec onboard MiniPCI slot PCI32 golden finger

Ethernet controller Intel EP80579 integrated 3x GbE MACs(RGMII) link to Marvell 88E1145

Quad PHYs with 3x RJ45 on the edge connector

Onboard Intel 82574L GbE with RJ45 on the edge connector

Ethernet bypass Default ETH0 ~ ETH3 with bypass, optional function, can be controlled by

GPIO and WDT)

IPSec HIFN 7964 (pin to pin compatible with 7965 and 7966, optional function)

Connect from: PCI bus from PEX8112

(PCI bus must be 32bit / 66Mhz)

USB Intel EP80579 build-in 2X USB2.0 host controller with 1x USB stack

connector on edge connector

SATA Intel EP80579 build-in 2X SATA controller with 2XSATA onboard 7-pin

shrouded vertical connector

Compact flash

(PATA) Jmicron JM368 PCIe to PATA bridge

Connect from: PCIeX1 bus of PEX8509 downstream

Connect to: onboard CF type II socket, support UDMA mode

LPC I/O Winbond W83627DHG

COM1 with RJ45 on edge connector for console redirection

COM2 for LCM function, Hardware monitor,

COM3 & COM4 from EP80579 built in UART with box header

Keyboard / mouse PS/2 keyboard & mouse support with pitch 2.54mm pin header

Expansion slot &

connector 1x onboard MiniPCI slot

1x LAN module expansion connector

1x pitch 2.0mm 44-pin HDD connector for ID370 LED board

Edge connector 4x RJ45 connector with LED for GbE, 1x USB vertical connector

1x console redirection via RJ45 without LED

Onboard connector ATX 20P connector, 3x 3P fan header with Smart FAN function

2x SATA controller with 2x SATA onboard 7-pin shrouded vertical

connector

1x COM2 port for LCM, 2x COM ports for COM3 & 4

1x PS/2 keyboard/mouse, 1x USB2.0, 1x right angle SAMTEC

MEC1-140-02-L-D-RA1-SL Hi-Speed connector for LAN module IBP835

TDM Intel EP80579 Integrated Processor with QuickAssist Technology

Reserved interface (headers) for future connection to proprietary E1/T1 board

Power ATX

WDT Yes (256 segments: 0, 1, 2,..., 255 sec/min)

INSTALLATION

MB835 User’s Manual

Model IBP835 LAN Module

Form Factor Custom size

Golden finger PCIeX4 bus of M/B

PCIe switch PEX8509 of PLX: Gen1 5 lanes / 8 ports PCIe switch

(up: 4lanes /down:1lanes)

Connect from: PCIeX4 bus of M/B

Connect to 4x Intel 82574L GbE

Ethernet controller 4x onboard Intel 82574L GbE (optional 2x GbE)

Connect from: PCIeX1 bus of PEX8509 downstream

Connect to: RJ45 on edge connector

Edge connector 4x RJ45 with LED connector

Model ID835 Riser Card

Form Factor Custom size

Expansion slot (M/B side) 1x PCI and 1x PCIeX1 slot, connect from M/B

Expansion slot Top: PCI slot, for additional card

Bottom: PCIeX4 slot, for additional card

INSTALLATION

[

Board Dimensions

MB835 User’s Manual 5

INSTALLATION

MB835 User’s Manual

This page is intentionally left blank.
