Ivation IVBWCC311SS Manuale utente

31 Bottle Built-In Compressor Wine Cooler

SKU: IVBWCC311SS

User Guide

INTRODUCTION

Thank you for purchasing the Ivation® 31 Bottle Built-In

Compressor Wine Cooler. This User Guide is intended to

provide you with guidelines to ensure that operation of this

product is safe and does not pose risk to the user. Any use

that does not conform to the guidelines described in this

User Guide may void the limited warranty.

Please read all directions before using the product and

retain this guide for reference. This product is intended for

household use only. It is not intended for commercial use.

This product is covered by a limited one-year warranty.

Coverage is subject to limits and exclusions. See warranty

for details.

FEATURES

SAFETY PRECAUTIONS

PACKAGE CONTENTS

PRODUCT OVERVIEW

INSTALLATION

WINE STORAGE TIPS

USAGE/CARE

CARE/SPECS

TROUBLESHOOTING

WARRANTY

GET IN TOUCH!

TABLE OF CONTENTS

FEATURES

A Better Way to Store Your Best Bottles

No wine cellar? No problem! This product will protect

your favorite bottles from the light and air that can

damage wine’s aromas, all while storing them at the

precise recommended temperature for your varietals. The

advanced compressor cooling system delivers the optimal

environment for those special vintages, preserving their

unique flavor and delicacy. You get serious performance

with a look that’s pure luxury — rounded edges and

seamless designer stainless steel trim on the doors and

shelving.

YOUR WINE COOLER FEATURES:

• Built-in model installs into your cabinetry for a custom-

designed look

• Internal fan helps maintain consistent temperature

throughout the unit

• Compressor provides consistent, energy-ecient cooling

with low energy costs

• Quiet operation and vibration suppression technology

• One-touch controls and LCD display

• Interior lighting with independent on/o control

• Celsius or Fahrenheit temperature control, adjustable by

one-degree increments

• Chrome shelves are stylishly accented with stainless steel

and are easy to pull out

• Tempered smoked glass door protects wines from UV rays

• Securely sealing door gasket and dual-pane glass help

maintain internal temperature

• Auto-defrost

• Holds 31 standard size 750mL bottles

• CFC-free solid polyurethane foam insulation

FEATURES

FOCUSED ON INNOVATION, COMMITTED TO QUALITY

The power of innovation plus quality drives all of our product

designs. We pay attention to the small details that add up to

an impactful experience. We believe it’s possible to be the

best while being unique, and we bring that value into each and

every one of our oerings.

Explore our full line of solutions for your home at

www.ivationproducts.com, and keep the conversation going

by calling us at 1-866-849-3049, or sending us an email at

info@myivation.com

1-866-849-3049

info@myivation.com

Set up your warranty and stay current with information about

your unit by registering online. It only takes a moment, and

you’ll receive emails about product recalls, updates, and more.

Go to: register.ivationproducts.com.

SAFETY PRECAUTIONS

1. WARNING: CHOKING HAZARD – Small parts. This

product contains small parts and is not suitable for children

under 3 years old.

2. Remove all packaging before using this device. Please keep

all packaging materials out of reach of children and pets.

3. Properly dispose of all packing materials immediately after

unpacking product, as the bags used for packaging could

present a suocation or choking hazard.

4. Read all instructions carefully before attempting to operate

this device. Improper usage could result in injury or a

reduction in ecacy.

5. Never allow children to operate, play with, or crawl inside

the appliance.

6. Keep all ﬂammable liquids or materials away from this unit.

Failure to do so may result in a ﬁre or explosion.

7. Keep out of direct sunlight and away from heat sources.

8. Do not attempt to repair or replace any parts or service this

unit unless speciﬁcally recommended in this User Guide.

9. Use only with a properly grounded, standard 115V 60Hz

electrical outlet to avoid the risk of electrical shock.

10. Do not use with an extension cord.

11. Do not lift the unit by the door handle.

12. Make sure the door is fully closed before and during

installation.

13. Do not obstruct airﬂow to the front of the unit or any of the

unit’s fans, as doing so can cause the unit to malfunction

and will void the warranty.

PACKAGE CONTENTS

PARTS

AUpper hinge

Allows you to switch the

door opening from right

to left.

CScrews (2 pieces)

Fastens the handle to

the door.

ERound rubber stoppers

(5 pieces)

Covers the opening at the

left front corners of the unit.

GExtra screws for bottom

hinge (3 pieces)

Fastens the hinges to

the wine cooler body.

IWine cooler door

Shuts out the elements to

help preserve your wines.

KWine cooler shelves

Allows you to store

bottles properly.

LUser guide

Installation, use, and

helpful tips.

BBottom hinge (2 pieces)

Allows you to switch the

door opening from right

to left.

DWashers (2 pieces)

Fastens the handle to

the door.

FExtra screws for top and

bottom hinges (4 pieces)

Fastens the hinges to the

wine cooler body.

HWine cooler body

Keeps your wines at the

proper temperature.

JWine cooler handle

Easy to open.

PRODUCT OVERVIEW

1Upper hinge

2Light switch

3Temperature control (up)

4Temperature display

5Temperature control (down)

6Temperature setting switch

7Light

8Fan

9Carbon ﬁlter

Temperature sensor

11 Exhaust

12 Shelf

13 Exhaust

Stabilizing feet

15 Door gasket

Glass panel

17 Handle

18 Lower hinge

GET TO KNOW YOUR WINE COOLER

INSTALLING YOUR WINE COOLER

INSTALLATION

IMPORTANT INSTALLATION NOTES:

• Before installing your wine cooler, allow to stand

upright for 3 hours.

• Once the unit is installed and turned on, allow 24 hours

before use for the temperature to stabilize.

• Clean the interior of the unit with warm water and a

soft cloth, and make sure it is dry.

• Place only on a level surface that will support the

full weight once Wine Cooler is completely full. You

can ensure the unit is level by placing a small ball on

top and checking to make sure it does not roll in any

direction.

• Position in a dry, well-ventilated space with

temperatures between 41° - 90° F (5° - 32° C).

• Ensure that the ventilation panel on the bottom front of

your wine cooler remains unobstructed.

• Do not use without feet: the unit requires 2" of ground

clearance.

• If you are discarding an old unit, remove its door and

leave shelves in place to avoid an entrapment hazard.

INSTALLING THE DOOR HANDLE:

• The unit has been shipped with the door handle J

securely stored inside, attached to the shelves.

• The default door-opening option of your wine cooler

will have it swinging open from left to right. If you need

to reverse this door swing, please follow the separately

listed instructions on the next page.

• Gently pull the door gasket back from

the screw holes where you will attach

the handle.

• Use the two included screws Cand

washers Din order to fasten the door

handle to the frame of the door.

INSTALLATION

TO REVERSE THE DOOR-OPENING:

CAUTION: Do not attempt to complete this step by yourself.

This task requires two people, as otherwise the door could fall,

resulting in possible damage to the product or your person.

• Follow the previous steps for installing the door handle.

• Fully open the door.

• Pull out the rubber stoppers Efrom the screwholes on the left

upper and lower corners.

• Install the L-shaped piece Bof the lower left hinge, using the

3 screws Gprovided.

Upper left corner Lower left corner

INSTALLATION

• With your helper holding the door, unscrew and remove the

upper door hinge.

• Working together, carefully lift the door o of its bottom hinge.

Carefully set the door down in secure

position.

• In order to avoid scratching the door

upon re-installation in its new position,

unscrew and remove the bottom right

hinge.

• Flip it around. The handle will now be

on the right side of the door.

• Seat the door (in its new position)

on the bottom hinge.

• Install the other piece of the lower left hinge B, using two of the

other screws Fprovided.
