Keysight Technologies N9020B Manuale di installazione e funzionamento

Option BU1, 40 MHz to 85 MHz Analysis Bandwidth Upgrade

Option BU2, 40 MHz to 125 MHz Analysis Bandwidth Upgrade

Option BU3, 40 MHz to 160 MHz Analysis Bandwidth Upgrade

Keysight Technologies

N9020B MXA Signal Analyzer

Installation Note

Notices

The information contained in this document is subject to change without notice.

Keysight Technologies makes no warranty of any kind with regard to this material, including but

not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Keysight Technologies shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or use of this material.

Manual Part Number

N9020-90254

Edition

Edition 1, May 2016

Printed in USA/Malaysia

Published by:

Keysight Technologies, Inc.

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Installation Note N9020-90254 3

Option BU1/BU2/BU3, 40 MHz to 85/125/160 MHz Analysis Bandwidth Upgrade

Option BU1/BU2/BU3, 40 MHz to 85/125/160 MHz Analysis

Bandwidth Upgrade

Introduction

This installation note explains how to install the hardware and provides guidelines for adjustment

and verification for the following upgrade kits for MXA N9020B signal analyzers:

— Option BU1, Analysis Bandwidth Upgrade, 40 MHz to 85 MHz, Hardware and License

— Option BU2, Analysis Bandwidth Upgrade, 40 MHz to 125 MHz, Hardware and License

— Option BU3, Analysis Bandwidth Upgrade, 40 MHz to 160 MHz, Hardware and License

Installing this kit requires that the analyzer already have hardware and licenses installed to provide

analysis bandwidths up to 40 MHz. Other upgrade kits are available to upgrade analyzers that only

have analysis bandwidths up to 25 MHz.

Refer to http://www.keysight.com/find/mxa_upgrades for information of available upgrades.

Products Affected: N9020B MXA Signal Analyzer

Serial Numbers:

Options: B40, MPB (for frequency range options 508, 513, or 526)

To Be Performed By: (X) Keysight Service Center

(X) Personnel Qualified by Keysight

( ) Customer

Estimated Installation Time:

Estimated Adjustment Time:

Estimated Verification Time:

1.5 Hours

3.5 Hours

4Installation Note N9020-90254

Option BU1/BU2/BU3, 40 MHz to 85/125/160 MHz Analysis Bandwidth Upgrade

Software and test equipment is required for making adjustments and for performance verification

testing.

Information on how to obtain this software can be found at:

www.keysight.com/find/calibrationsoftware

The instrument must be readjusted and the performance tested to assure the instrument meets

specifications following the hardware installation. The X-Series Performance Verification and

Adjustment Software must be used. All adjustments are automated. This software is included in

the N7814A, Keysight X-Series Signal Analyzer Calibration Application software.

Installation Note N9020-90254 5

Option BU1/BU2/BU3, 40 MHz to 85/125/160 MHz Analysis Bandwidth Upgrade

Installation Kit Parts List

Quantity Description Keysight Part Number

1 A25 Wideband Analog IF N9020-60044

1 A26 Wideband Digital IF N9020-60311

1 Opt BU1/BU2/BU3 Cable Kit with Wire Markers

(includes cables W51 through W56, listed below)

N9020-60303

1 Cable Assembly, Flat Flexible 80-conductor 3-in-LG (W44) 8121-1854

1 Cable Assembly, Coaxial 700 mm LG (W20) 8121-1400a

with ends labeled ‘705’

and ‘6’

a.This cable is included in the Option BU1/BU2/BU3 Cable Kit with Wire Markers, p/n N9020-60303

1 Cable Assembly, Coaxial 530 mm LG (W51) 8121-1401a

with ends labeled ‘301’

and ‘718’

1 Cable Assembly, Coaxial 380 mm LG (W52) 8121-2288a

with ends labeled ‘102’

and ‘15’

1 Cable Assembly, Coaxial 380 mm LG (W54) 8121-2288a

with ends labeled ‘716’

and ‘14’

1 Cable Assembly, Coaxial 480 mm LG (W55) 8121-2290a

with ends labeled ‘805’

and ‘17’

1 Cable Assembly, Coaxial 710 mm LG (W56) 8121-2291a

with ends labeled ‘806’

and ‘726’

1 Cable Assembly, Coaxial 570 mm LG (W53) 8121-2292a

with ends labeled ‘901’

and ‘101’

2 Cable Tie 1400-0249

14 Screw, M3 x 0.5, (6 mm long), flathead 0515-1946

1 Entitlement Certificate 5964-5178

1 Entitlement Certificate Envelope 5967-7169

1 Installation Note This note

6Installation Note N9020-90254

Option BU1/BU2/BU3, 40 MHz to 85/125/160 MHz Analysis Bandwidth Upgrade

Tools Required

— T-10 TORX Driver

— T-20 TORX Driver

— Keysight Calibration and Adjustment Software, N7814A (revision E.16.00 or later)

— Test equipment and computer supported by the X-Series Performance Tests and Adjustment

Software

— MXA Signal Analyzer Service Guide. This manual is available online at the following URL:

www.keysight.com/find/N9020B_service_guide

— Microsoft Windows based personal computer with internet access and USB port

— USB storage device with >2GB free memory

Initial Instrument Functionality Check

Power on the instrument and allow the instrument to boot up. Run an alignment and display the

measurement screen. (The instrument will probably display a spectrum analyzer screen and you will

see the instrument sweeping.)

There should be no alignment failures. If there are failures, investigate and fix the problem before

continuing.

Before you disassemble the instrument, turn the power switch to Standby. After the instrument

has completely shut down, unplug the instrument. Failure to unplug the instrument can result in

personal injury.

Electrostatic discharge (ESD) can damage or destroy electronic components. All work on

electronic assemblies should be performed at a static-safe workstation. Refer to the

documentation that pertains to your instrument for information about static-safe workstations

and ordering static-safe accessories.

Installation Note N9020-90254 7

Installation Procedure

Analyzer Information

1. Connect a power cord to the analyzer and turn on the analyzer.

2. After the analyzer has completed turning on, press System, Show System. Make note of the

following information from the Show System screen:

Product Number ________________

Serial Number ________________

Instrument S/W Revision ________________

3. Check for the presence of the options listed below in the Show System screen. Put a check

mark or “X” after each option listed below that appears in the Show System menu.

N9020B-503 ______

N9020B-508 ______

N9020B-513 ______

N9020B-526 ______

N9020B-BBA ______

N9020B-B40 ______

N9020B-DP2 ______

N9020B-MPB ______

Refer to the following conditions:

—If the analyzer is not equipped with N9020B-B40, do not proceed with the installation of

this upgrade kit. If N9020B-B40 is not installed, other upgrade kits are available to upgrade

to 85 MHz, 125 MHz, or 160 MHz analysis bandwidth.

—If the analyzer has N9020B-BBA, do not proceed with the installation of this kit. N9020B

analyzers with Option BBA do not have sufficient room to install the two additional boards

required for analysis bandwidths of 85 MHz and wider.

—If the N9020B-MPB is not already present and either frequency range option N9020B-508,

N9020B-513, or N9020B-526 is present, it will be necessary to upgrade the analyzer to add

option N9020B-MPB before installing this kit. Refer to

http://www.keysight.com/find/mxa_upgrades for details on how to upgrade to N9020B-

MPB.

Do not attempt to install this kit on an N9020A. Although much of the hardware is identical, the

licenses included in this kit will only work on an N9020B.

8Installation Note N9020-90254

Installation Procedure

Update Instrument Software

Updating the instrument software and installing the necessary licenses before installing the new

hardware will help ensure that the hardware installation was successful.

Go to the following website and determine whether or not the analyzer has the latest instrument

software already installed:

http://www.keysight.com/find/xseries_software

If the analyzer does not have the latest instrument software already installed, download and install

the latest version.

Installation Note N9020-90254 9

Installation Procedure

Licensing the New Options

License Installation Procedure over USB

1. Locate the Option Upgrade Entitlement Certificate (5964-5178) in the kit.

2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the

Certificate.

3. After redeeming the upgrade products from the Certificate(s), you will receive one or two

e-mails, each with an attached License File.

4. Locate a USB storage device. Perform a virus scan on this device before use.

5. Save the License File(s) to the root directory of the USB Storage Device.

6. Connect the USB Storage Device to one of the analyzer’s USB ports. Connect a mouse to

another USB port. Windows will detect the new hardware and may display the configuration

menu shown in Figure 1. This menu may be configured according to your preferences.

Figure 1 USB Storage Device Configuration Menu

10 Installation Note N9020-90254

Installation Procedure

7. The signal analyzer will automatically consume the License File. (This may take a few minutes)

When the License File is consumed the Keysight License Manager will display a “Successful

License Installation” message similar to the one shown in Figure 2. If the license file contains

multiple licenses, multiple “Successful License Installation” messages will appear. Wait until

all licenses have been consumed before removing the USB Storage Device.

Figure 2 Successful License Installation

If you will also be installing any of the following upgrade products:

N9020BU-MPB

N9020BU-CR3, 2nd IF Output

N9020BU-CRP, Arbitrary IF Output

Now would be the best time to install the licenses for these other upgrades. By installing the

licenses now, the adjustments and performance verifications for these other upgrades will also

be performed.
