INSTRUCTION MANUAL

Model#: 300322

Product images may vary slightly from actual product.

52" Compass LED

2 | KICHLER.COM

TABLE OF CONTENTS

SAFETY RULES …………………………………………………………………………....3

TOOLS REQUIRED …………………………..………………………………..………...4

PACKAGE CONTENTS ……………….....................……………………………...4

MOUNTING OPTIONS ………….................................................................5

HANGING THE MOTOR ASSEMBLY…………………………………………..6

ELECTRICAL CONNECTIONS…………..................................................9

FINISHING THE MOTOR INSTALLATION ………..….........................10

ATTACHING THE FAN BLADES ………………………….......................... 11

INSTALLING THE LIGHT PLATE ASSEMBLY……………..................12

INSTALLING THE LIGHT KIT AND ACRYLIC SHADE…….............13

OPERATING INSTRUCTIONS …………………………...........…………........14

TROUBLESHOOTING …………………………..................………………...……16

FCC INFORMATION......………………………………………………………...........17

52" Compass LED | 3

SAFETY RULES

READ AND SAVE THESE INSTRUCTIONS

CAUTIONCAUTION – RISK OF SHOCK –

Disconnect Power at the main circuit breaker panel or

main fuse box before starting and during the installation.

WARNING:WARNING: This fixture is intended for installation in

accordance with the National Electrical Code (NEC) and

all local code specifications. If you are not familiar with

code requirements, installation by a certified electrician is

recommended.

WARING:WARING: To reduce the risk of fire or electric shock, use

only the control provided with the fan.

WARNING:WARNING: To reduce the risk of fire, electric shock, or

Personal Injury, mount directly to a structural framing

member or to an outlet box marked “Acceptable For Fan

Support of up to 22.6kg(50 lbs)”. For outlet box mounting,

use mounting screws provided with the outlet box.

WARNING:WARNING: Do not operate reversing switch while fan

blades are in motion. Fan must be turned off and blades

stopped before reversing blade direction.

Avoid placing objects in the path of the blades.

To avoid personal injury or damage to the fan and other

items, be cautions when working around or cleaning the

fan.

10.

11.

Make sure the installation site you choose allows a

minimum clearance of 7 feet from the blades to the floor

and at least 30 inches from the ends of the blades to any

obstruction.

Do not use water or detergents when cleaning the fan or

fan blades. A dry dust cloth or lightly dampened cloth will

be suitable for most cleaning.

After making the electrical connections, spliced

conductors should be turned upward and pushed carefully

up into outlet box. The wires should spread apart with the

ground wire and white(common) wire to one side with the

black (load) wire to the other side of the outlet box.

Electrical diagrams are for reference only. Light kits that

are not packed with fan must be ETL Listed and marked

suitable for use with the model fan you are installing.

Switches must be ETL General Use Switches. Refer to the

instructions packaged with the light kits and switches for

proper assembly.

WARNING

TO REDUCE THE RISK OF PERSONAL INJURY. DO NOT

BEND THE BLADES DURING ASSEMBLY OR AFTER

INSTALLATION. DO NOT INSERT OBJECTS IN THE PATH

OF THE BLADES.

4 | KICHLER.COM

TOOLS REQUIRED

PACKAGE CONTENTS

Phillips screwdriver

Blade screwdriver

11 mm wrench

Step ladder

Wire cutters

Unpack your fan and check the contents . You should have the following items:

A. Mounting bracket

B. Ball / downrod assembly

C. Canopy

D. Canopy Hole Cover

E. Coupling Cover

F. Motor Body

G. Fan Blade (5)

H. Light Plate Assembly

I. Light Kit

J. Acrylic Shade

K .Remote Control Kit:

Remote Control (1)

Receiver (1)

Battery (1)

Wire Connectors (6)

Handset Control Holder (1)

L. Package hardware

1) Mounting hardware :

Wire Connector (3)

2)Blade attachment hardware :

Screws(15), Flat washer (15)

52" Compass LED | 5

MOUNTING OPTIONS

If there is not an existing UL (cUL for Canadian Installation ) listed

mounting box, then read the following instructions. Disconnect the

power by removing fuses or turning o circuit breakers.

Secure the outlet box directly to the building structure. Use

appropriate fasteners and building materials. The outlet box and its

support must be able to fully support the full weight of the fan (up to

50 lbs). Do not use plastic outlet boxes.

Figure 1, 2 and 3 are examples of dierent ways to mount the outlet

box.

NOTE:NOTE: If you are installing the ceiling fan on a sloped (vaulted) ceiling,

you may need a longer downrod to maintain proper clearance

between the tip of the blade and the ceiling. A minimum clearance of

12” is suggested for optimal operation.

NOTE:NOTE: Depending on the location you have selected for installation,

you may need to purchase and install a “Joist Hanger” for the support

of the outlet box. Make sure the joist hanger you purchase has been

designed for use with ceiling fans. (Fig.4)

Outlet box

ANGLED CEILING

MAXIMUM 18° ANGLE Provide strong

support

Ceiling

mounting

plate

Recessed

Outlet box

Fig. 2

Fig. 4

Fig. 3

Fig. 1

Outlet box

6 | KICHLER.COM

HANGING THE MOTOR ASSEMBLY

REMEMBERREMEMBER to turn off the power before you begin installation. This is

necessary for your safety and also the proper programming of the control

system. To properly install your ceiling fan, follow the steps below.

Step 1.Step 1. Before attaching fan to outlet box (not included), ensure the outlet box

is securely fastened to at least two points to a structural ceiling member

(a loose box will cause the fan to wobble). Install the screws and washers

included with the outlet box. NOTE:NOTE: Do not lock the screws completely, just

lock half.

Pass the 120 volt supply wires form the ceiling outlet box through the center

of the ceiling mounting bracket.(Fig. 5)

Step 2.Step 2. Align the slot holes on the mounting bracket with the screws, and

push the mounting bracket to the screws, then tighten the screws. (Fig. 6

and 7)

Fig. 5

Fig. 6

Fig. 7

Outlet Box

Washer

Screw

Mounting Bracket

52" Compass LED | 7

HANGING THE MOTOR ASSEMBLY

Step 3.Step 3. Remove the hairpin and clevis pin from the downrod assembly, retain

for later use.(Fig.8)

Step 4.Step 4. Loosen the two set screws on the motor coupling.(Fig. 9)

Step 5.Step 5. Place the coupling cover, canopy hole cover and canopy over the

coupling found on the top of the motor assembly. Carefully feed fan wires

from the motor assembly through the downrod, then insert the downrod into

the coupling.(Fig.10)

Fig. 10

Set Screw

Downrod

Canopy

Canopy Hole Cover

Coupling Cover

Coupling

Clevis Pin

Hair pin

Fig. 9

Fig. 8

8 | KICHLER.COM

HANGING THE MOTOR ASSEMBLY

Step 6.Step 6. Insert the clevis pin through the downrod and coupling found on the

motor assembly, and secure with the hair pin. Tighten set screws found on

the coupling. (Fig. 11 )

Step 7.Step 7. Now lift the motor body into position and place the hanger ball into

the mounting bracket. Rotate until the "Check Tab" has dropped into the

"Registration Slot" and seats firmly. (Fig. 12) The entire motor body should

not rotate if this is done correctly.

WARNING:WARNING: Failure to properly seat the "Check Tab" can damage the ceiling

fan during operation.

Fig. 12

Fig. 11

Hairpin

Clevis Pin

Set Screw

Coupling

OK NO

Registration Slot

Mounting Bracket

Hanger Ball Check Tab

52" Compass LED | 9

ELECTRICAL CONNECTIONS

WARNING:WARNING: To avoid possible electrical shock, be sure you have turned offTo avoid possible electrical shock, be sure you have turned off

the power at the main circuit panel before wiring. Follow the steps belowthe power at the main circuit panel before wiring. Follow the steps below

to connect the fan to your household wiring. Use the wire connecting nutsto connect the fan to your household wiring. Use the wire connecting nuts

supplied with your fan. Secure the connector with electrical tape. Make suresupplied with your fan. Secure the connector with electrical tape. Make sure

there are no loose wire stands or connections.there are no loose wire stands or connections.

WARNING:WARNING: If your house wires are different colors than referenced in thisIf your house wires are different colors than referenced in this

manual, stop immediately. A professional electrician is recommended tomanual, stop immediately. A professional electrician is recommended to

determine proper wiring.determine proper wiring.

Step 1.Step 1. Insert the receiver into the mounting bracket, and keep flat inInsert the receiver into the mounting bracket, and keep flat in

opposition of ceiling.Cut o excess fixture wires approximately 6 to 9 inchesopposition of ceiling.Cut o excess fixture wires approximately 6 to 9 inches

above top of the downrod assembly. Strip insulation o 1/2 in. from the end ofabove top of the downrod assembly. Strip insulation o 1/2 in. from the end of

each fixture wire. (Fig. 13)each fixture wire. (Fig. 13)

Step 2.Step 2. Motor to Receiver Electrical Connections: Connect the BLACKMotor to Receiver Electrical Connections: Connect the BLACK

wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.

Connect the WHITE wire from the fan to the WHITE wire marked "TO MOTORConnect the WHITE wire from the fan to the WHITE wire marked "TO MOTOR

N" from the receiver. Connect the BLUE wire from the fan to the BLUE wireN" from the receiver. Connect the BLUE wire from the fan to the BLUE wire

marked "FOR LIGHT" from the receiver. Secure all the wire connections withmarked "FOR LIGHT" from the receiver. Secure all the wire connections with

the plastic wire connectors provided. (Fig. 14)the plastic wire connectors provided. (Fig. 14)

Step 3.Step 3. Remote Receiver to Outlet Box Electrical Connections: Connect theRemote Receiver to Outlet Box Electrical Connections: Connect the

BLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" fromBLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" from

the receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITEthe receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITE

wire marked "AC IN N" from the receiver. Secure all the wire connections withwire marked "AC IN N" from the receiver. Secure all the wire connections with

the plastic wire connectors provided. (Fig. 14)the plastic wire connectors provided. (Fig. 14)

Fig. 13a Fig. 13b

Fig. 14

Receiver Mounting Bracket

Green or bare copper (ground)

AC IN N(White)

AC IN L(Black)

Black ("AC IN L") White("AC IN N")

White("TO MOTOR N")

Ground wire

White (Neutral)

Receiver

Black ("TO MOTOR L")

Black (motor)

Blue(FOR LIGHT)

Blue(for light)

6 to 9 in.

10 | KICHLER.COM

ELECTRICAL CONNECTIONS

FINISHING THE MOTOR INSTALLATION

Step 4.Step 4. If your outlet box has a ground wire ( green or bare copper ) connectIf your outlet box has a ground wire ( green or bare copper ) connect

it to the fan ground wires : otherwise connect the fan ground wire to theit to the fan ground wires : otherwise connect the fan ground wire to the

mounting bracket. Secure the wire connection with a plastic nut provided.mounting bracket. Secure the wire connection with a plastic nut provided.

After connecting the wires, spread them apart so that the green and whiteAfter connecting the wires, spread them apart so that the green and white

wires are on one side of the outlet box and black and blue wires are on thewires are on one side of the outlet box and black and blue wires are on the

other side. (Fig. 14)other side. (Fig. 14)

NOTE:NOTE: Carefully tuck the wire connections up into the outlet box.Carefully tuck the wire connections up into the outlet box.

NOTE:NOTE: Fan must be installed at a maximum distance of 30 feet from theFan must be installed at a maximum distance of 30 feet from the

transmitting unit for proper signal transmission between the transmittingtransmitting unit for proper signal transmission between the transmitting

unit and the fan’s receiving unit.unit and the fan’s receiving unit.

Step 1.Step 1. Remove one of the two shoulder screws in the mounting bracket.Remove one of the two shoulder screws in the mounting bracket.

Loosen the second shoulder screw without fully removing it. (Fig. 15)Loosen the second shoulder screw without fully removing it. (Fig. 15)

Step 2.Step 2. Assemble canopy by rotating key slot in canopy over shoulderAssemble canopy by rotating key slot in canopy over shoulder

screw in mounting bracket. Reinstall the shoulder screw that was previouslyscrew in mounting bracket. Reinstall the shoulder screw that was previously

removed, then retighten two shoulder screws securely. (Fig.16)removed, then retighten two shoulder screws securely. (Fig.16)

Fig. 15

Fig. 16

Canopy

Shoulder Screw

Mounting Bracket

Indice

Lingue:

Altri manuali Kichler Lighting Fan

Kichler Lighting

Kichler Lighting Select Canfield 300107 Manuale utente

Kichler Lighting

Kichler Lighting 330163 Manuale utente

Kichler Lighting

Kichler Lighting Wilton Manuale utente

Kichler Lighting

Kichler Lighting Cameron 310204WH Manuale utente

Kichler Lighting

Kichler Lighting FERRON Manuale utente

Kichler Lighting

Kichler Lighting 52" Chiara LED Manuale utente

Kichler Lighting

Kichler Lighting Deckard Manuale utente

Kichler Lighting

Kichler Lighting Selectlight fixture Manuale utente

Kichler Lighting

Kichler Lighting Select Sutter Place Manuale utente

Kichler Lighting

Kichler Lighting ETL Manuale utente

Kichler Lighting

Kichler Lighting Larissa Manuale utente

Kichler Lighting

Kichler Lighting POLA Manuale utente

Kichler Lighting

Kichler Lighting Lacey Manuale utente

Kichler Lighting

Kichler Lighting Rivetta Manuale utente

Kichler Lighting

Kichler Lighting XETY LED Manuale utente

Kichler Lighting

Kichler Lighting Basics 404 Manuale utente

Kichler Lighting

Kichler Lighting Szeplo II Manuale utente

Kichler Lighting

Kichler Lighting 300457 Manuale utente

Kichler Lighting

Kichler Lighting Verdi Manuale utente

Kichler Lighting

Kichler Lighting ELLYS Manuale utente

Kichler Lighting

Kichler Lighting 52" Basics Pro Manuale utente

Kichler Lighting

Kichler Lighting Renew Select Manuale utente

Kichler Lighting

Kichler Lighting 310125 Manuale utente

Kichler Lighting

Kichler Lighting Cortez Manuale utente

Manuali Fan popolari di altre marche

ELTA FANS

ELTA FANS H03VV-F Manuale utente

Hunter

Hunter 20714 Manuale di istruzioni

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuale utente

Hunter

Hunter Caraway Manuale di istruzioni

Panasonic

Panasonic FV-15NLFS1 Manuale utente

Kompernass

Kompernass KH 1150 Manuale utente

VES

VES FALA100/12V/TR Manuale utente

Vertiv

Vertiv Liebert DCD Manuale utente

Westinghouse

Westinghouse GFP Series Manuale utente

Venmar

Venmar KUBIX HRV PLUS Series Manuale utente

Maico

Maico ECR 31 Manuale utente

Sonnenkonig

Sonnenkonig Dinky Manuale utente

S&P

S&P ECOWATT HXBR Manuale utente

Wider

Wider IMP03369BH Manuale utente

Panasonic

Panasonic F-60DHN Manuale utente

Hinkley

Hinkley HIGHLAND Manuale utente

Broan

Broan 766BN Manuale utente

Premium

Premium PFS16022 Istruzioni per il montaggio
