Linksys LNE100M Manuale utente

EtherFast®10/100

Managed Network

Adapter

his powerful auto-negotiating 10/100 Mbps Ethernet

interfacecardfeaturesnetworkmanagementfunctionsto

save you time and hassle. Configure, check error rates,

and keep an inventory of your network resources from one cen-

tralized location.

The Wake-On-LAN function remotely "wakes up" any PC on the

network, so you can handle maintenance chores during off-

hours. The 802.1Q support lets you optimize your network traf-

fic by dividing the network into smaller Virtual LANs, while

packet delivery is prioritized using 802.1P signaling.

• Easy to Use Plug-and-Play 10/100 PCI Network Adapter

• Adapter settings can be managed via SNMP using stan-

dard MIB browser

• Full Duplex Capability at Up To 200Mbps

• Connects to Both 10Mbps Ethernet and 100Mpbs Fast

Ethernet Networks

• Power On your PC from anywhere on the network with

Wake-On-LAN Management

• Complete 802.1Q VLAN support for use in segmented

networks

• Support for IP Checksum offloading built-into the adapter

driver

• 802.1p tagging support for Quality of Service (QoS)

• Configuration utility allows for complete management of

the network adapter settings

EtherFast®10/100 Managed Network Adapter

Model No.: LNE100M

Manage your network without running from

desk to desk

Features

Benefits

• 10/100 Auto-negotiating Ethernet interface,

with SNMP-based management

• Configure and monitor your network from one

centralized location

• Power-on any PC from anywhere on the net-

work with Wake-On-LAN support

• Optimize your network traffic with 802.1Q

VLAN support and 802.1p traffic prioritization

Instant EtherFast®Series

Package ContentsSpecifications

Model No: LNE100M

Standards IEEE 802.3, IEEE 802.3u, PCI 2.2,ACPI

Ports: 1 RJ-45 Port

Cabling Type Category 5 Ethernet Cable

LEDs 100, Collision, FDX, Link/Act

Environmental

Dimensions 7.3 x 6” x 1.8” (186mm x 154mm x 48 mm)

Unit Weight 2.4 oz. (.07 kg)

Power 5W Maximum

Certifications FCC Class B, CE Class B,VCCI Class B

Operating Temp 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

EtherFast®10/100 Managed Network

Adapter

• One EtherFast 10/100 Managed Network

Adapter

• One Installation CD

• One Quick Installation Guide

• One User Guide included on the Installation

• One Registration Card

• 200Mhz or Faster Processor

• Available PCI 2.2 Slot

• CD-ROM Drive

• Windows 98/Me/NT 4.0/2000/XP

Minumum Requirements

DS-LNE100M-090402NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com
