Magic mill MFD-7070 Manuale utente
-1-
INSTRUCTION MANUAL
FOOD DEHYDRATOR
MFD-7070
PLEASE READ THIS INSTRUCTION CAREFULLY BEFORE USING THE PRODUCT
-2-
Technical specification
Normal Voltage: 120V, 60Hz
Normal Power: 600W
Thermostat: 95°F-167°F
Mesh Tray:
Use for smaller items such as herbs and berries; and sticky items such as banana & tomatoes.
Non-stick sheet (Fruit Roll Tray)
Makes delicious fruit rolls naturally. When not using as Fruit Roll Tray, store at the bottom of the unit as a
crumb tray.
-3-
Getting started
Remove all the packaging materials from the product.
Place the packing inside the box and either store or dispose of responsibly
Safety Instruction
The following basic precautions should always be adhered to when using the electrical appliance.
PLEASE READ THIS INSTRUCTION CAREFULLY BEFORE USE AND RETAIN FOR FUTURE
REFERENCE
1. This appliance can be used by children aged from 8 years and above and persons with reduced ph
ysical, sensory or mental capabilities or lack of experience and knowledge if they have been given s
upervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be m
ade by children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children less than 8 years.
2. This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
3. This food dehydrator is designed for DOMESTIC USE ONLY and is not suitable for commercial use.
Do not use it for outdoors.
4. When using the food dehydrator ensures that it is on a flat, level and sturdy surface, ensure no risk
that it may fall .Also that it can take the weight of the unit during use.
5. Failure to follow all the instructions listed may result in electric shock, fire or serious personal
injury .The warnings, cautions and instructions discussed in this instruction manual cannot cover all
possible conditions and situations that may occur while the product in use
6. Do not leave the food dehydrator unattended during use.
7. Always keep the food dehydrator out of children as they are unable to recognize the hazards
associated with incorrect handling of electrical appliances.
8. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge. Unless they have been given
supervision or instruction concerning use of the appliances by a person responsible for their safety.
9. Before plugging the food dehydrator into the mains electrical supply, check that the voltage and
power supply comply with the specifications on the food dehydrator’s rating label.
10. Make sure that the food dehydrator is switched off and remove the plug from the mains electrical
supply when it is not in use; before it is cleaned and whilst it is being repaired.
11. Ensure that the food dehydrator and power cord is not hung over sharp edges and keep away from
hot objects and open flames; otherwise the plastic will melt and cause a fire.
12. Under no circumstances should the food dehydrator or plug be immersed in water or any other
liquid .Do not use the appliance with wet hands.
13. Check the food dehydrator and power cord regularly for damage.
14. Do not use the food dehydrator should there be damage to the plug or cord, following a malfunction,
-4-
or after it has been dropped or damaged in any way.
15. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarl
y qualified persons in order to avoid a hazard.
16. Repairs to the food dehydrator should only be performed by a qualified electrician .Improper repairs
may place the user at risk.
17. None of the product’s parts are dishwasher safe, unless explicitly specified otherwise.
18. Always turn the power off at the power outlet before you insert or remove a plug. Remove by
grasping the plug; do not pull on the cord.
19. Do not use your appliance with an extension cord unless this cord has been checked and tested by a
qualified technician or service person.
20. Never use an unauthorized attachment.
21. Avoid contact with moving parts. Keep hands, hair, clothing, spatulas and other utensils away during
operation to reduce the risk of injury to persons and/or damage to the machine.
22. Please don’t turn the draught of engine towards others or tinder.
23. Please don’t keep it beside anything heating. Please keep the plug away from pressing; otherwise it
will cause a fire or electric shock.
24. If you pass this appliance on to a third party, these operating instructions must also be handed over.
Caution:
zATTENTION! Do not run the appliance for more than 24hours in one single use. After 24 hours.
Unplug and let it cool down for at least 2 hours before operating again.
zDo not operate near gas spray cans.
zIncorrect operation and improper handling can lead to malfunction of the appliance and injuries to
the user.
zThe power cord can not be squeezed by something heavy or sharp, otherwise it will cause a fire or
electric shock.
zThe temperature of accessible surface may be HIGH when the appliance is operating.
zTo reduce the risk of electric shock, do not immerse or expose the product, flexible
cord or plug to rain, moisture or any liquid.
zDo not use the product near baths, basins or other vessels containing water or other
liquids, or when standing in or on damp or wet surfaces.
Don’t keep the device in the
watery environment;
z
Keep the device away the place of high temperature, ray and wetly.
z
Don’t operate the device with wet hands.
z
Please turn off the power supply in the watery environment.
zIn the event where the appliance is dropped into the water, turn off the power at the
power outlet and remove the plug immediately. DO NOT REACH INTO THE WATER
TO RETRIEVE IT.
zIt is important to note that the appliance will have to be inspected by a qualified
technician before using it again.
-5-
Feature of Dehydrator
This unit features an automatic fan, which circulates warm air producing a nice evenly dried device!
Dried foods are a great treat to snack on because they hold almost all of their nutritional value andflavor.
· Perfect way to preserve fruit, snacks, vegetables, bread, flowers and more.
· With ten stainless steel tray, each tray can’t over 0.6kgs food
· If you want to dry thicker food, you can take out one tray to make the height higher between two trays.
· Put the Non-stick sheet on bottom can collect the residue during dry food
· From the transparent window, you can see the food situation during drying.
Before Use:
Cleaning:
Before using the first time, wipe all parts of the appliance. Clean the 6 trays, and mesh, on-stick sheet
with a lightly moistened cloth.
Use detergent as needed. Don't put the main engine into water or other liquids!
After cleaning the unit must be run in for 30 minutes without placing anyfood for drying during this period.
Any smoke or smells produced during this procedure are normal. Please ensure sufficient
ventilation. After the running in period, rinse the racks in water and dry all parts. This act is only
necessary for the first time.
Unplug the dehydrator from the power supply and let it cool down before cleaning. Use a soft brush to
remove food sticking. Dry all parts before storing the dehydrator.
Do not clean the appliance with aggressive chemicals or abrasives in order not to damage the surface.
Assembling the appliance:
Make sure that the dehydrator sits steadily on a solid level surface. Stock the drying trays and connect
the plug with a wall socket. The dehydrator is now ready for use.
Usage Method
1. Put the clean food in the trays –Do not overload the trays and never overlap the food. Close the
damper door.
2. Plug dehydrator into wall outlet, the screen and button light up and there is a beep sound at the
beginning when it starts up. And the ON/OFF” light up, the screen shows “---“.
3. Press the “ON/OFF” button, The LED screen will show default time setting “10:00” and temp setting
-6-
“158”. Motor and fan start first, then heating element start working 5 seconds later. Set time begins
to count down, the signal “:” on LED screen flashes.
4. Press the “TEMP/TIME” button and LED screen shows the time value. According to actual needs,
press “+" or "-" button to change the drying time between "0:30” and “24:00". Press "+" or "-" button
once, the time increment or decrement is 30 minute/press. If press "+" or "-" button for long time,
then it automatically increases or decreases. After finish setting the drying time, system
automatically gets into operating mode in current time setup.
5. Press the “TEMP/TIME” button and LED screen shows the temp value. According to actual needs,
press "+" or "-" button to change the drying temp between "95” and “167". Press "+" or "-" button
once, the temp increment or decrement is 9/press. If press "+" or "-" button for long time, then it
automatically increases or decreases. After finish setting the drying temp system automatically
confirms to work in current temp setup. LED screen operating in time mode.
Note: Set low temperature for thin/small pieces of food or for a small load of food. Set high
temperature for drying thick/big pieces of food and large loads. The thermostat can also be used to
decrease the temperature as the food is near the end of its drying cycle making it easier to control
the final moisture level in the food.
6. During drying process, you can change or check the drying time. Press the “TEMP/TIME” button first,
then press the "+" or "-" button. Press “TEMP/TIME” button, you can check the setting time.
7. During drying process, press the “ON/OFF” button, all functions will be paused after 10 seconds.
Screen no display..
8. In standby mode, you can press the “ON/OFF” button directly to get into default mode ( TIME : 10
hours TEMP: 158). You also can change the drying time and temp if needed.
9. When the set time counts down to "0:00”, the heating element stops working first. The fan will
continue running for 10 seconds and the buzzer rings 20 times "beep" sound (1 time/second).
10. Unplug the unit from the power point.
Hints:
·This dehydrator includes 6trays and an overheat protection. The host contains heating elements,
motor, fan and thermostat.
·The air vents on the tray allow air to be circulated.
·Using a controlled heat temperature, Air from the back flow into each tray drying moisture..
·Depending on the moisture in the food itself and the humidity in the air, drying operation time can
change. Use the dryer in a dust free, well ventilated, warm and dry room. Well air ventilation is also
important.
· Fruit and vegetables dried in your food dehydrator will be different in appearance from those
sold in health food stores and supermarkets. This is due to your food dehydrator uses no
preservatives, no artificial coloring and only natural additives.
·Records of humidity, weight of produce before and after drying times, will be helpful to improving your
drying techniques for the future.
-7-
DEHYDRATOR
COOKBOOK
-8-
DRYING TIPS:
Drying time for pre-treatment fruit will vary according to the following
factors:
1) thickness of pieces or slices
2) number of trays with food being dried
3) volume of food being dried
4) moisture or humidity in your environment
5) your preferences of drying for each type of dried food
It is recommended to:
zCheck your food every hour.
zRotate and/or re-stack your trays if you notice uneven drying.
zLabel food with contents dried, date and weight before drying. It
will also be helpful to note the drying time for future reference.
zPretreated food will give the best effect in drying.
zCorrect food storage after drying also will help to keep food in
good quality and save the nutrients.
-9-
Temperature Settings Uses
95°F Herbs,Flowers,Dough
104°F Yogurt
113°F Soft Vegetables
122°F Hard Vegetables
131°F Citrus Peel
140°F Fruit
149°F Fish
158-167°F Meat Jerky, Fruit Rolls
Name Preparation
Dryness
test
Time,
hours
(approx.)
Apples
Peel, core and cut slices or rings
Pliable
5-6
Apricots
Cut in halves or in slices, remove pit
Pliable
12-
38
Bananas
Peel and cut into 3
-4mm slices
Crisp
8-38
Cherries
Pitting is optional, or pit when 50% dry
Leathery
8-34
Cranberries
Chop or leave whole
Pliable
6-26
Red Dates
Pit and slice
Leathery
6-26
Figs
Slice
Leathery
6-26
-10-
Grapes
Leave whol
e
Pliable
8-38
Nectarines
Cut in half, dry with skin side down. Pit
when 50% dry
Pliable
8-26
Orange rind
Peel in long strips
Brittle
8-16
Peaches
Pit when 50% dry. Halve or quarter
with cut side up
Pliable
10-
34
Pears
Peel and slice
Pliable
8-30
Strawberries
Cut into 3/8 inch slices, other berries
whole
No moisture
8-26
Artichokes
Cut into 1/3
-
inch strips. Boil about 10
minutes
Brittle
6-14
Asparagus
Cut into 1
-inch pieces
Brittle
6-14
Beans
Cut and steam blanch until translucent
Brittle
8-26
Beets
Blanch, cool, remove tops and roots,
slice
Brittle
8-26
Indice
Altri manuali Magic mill Elettrodomestico da cucina
Magic mill
Magic mill MSC1030 Manuale utente
Magic mill
Magic mill MFD-5000 Manuale utente
Magic mill
Magic mill MFD-500 Manuale utente
Magic mill
Magic mill MFD-1011 Manuale utente
Magic mill
Magic mill MFD-9100 Manuale utente
Magic mill
Magic mill MFD-6060 Manuale utente
Magic mill
Magic mill MFD-1010 Manuale utente
