Marshall Amplification ACTON II Bluetooth Manuale utente

ACTON II VOICE WITH THE GOOGLE ASSISTANT BUILT-IN

USER MANUAL

004.

BOX CONTENTS

001. MARSHALL ACTON II VOICE WITH THE GOOGLE ASSISTANT BUILT-IN

002. QUICK START GUIDE

003. IMPORTANT SAFETY INSTRUCTIONS

004. MAINS LEAD

004.

001. 002. 003.

005.

GENERAL DESCRIPTION

001. AUX INPUT FOR 3.5 mm JACK

002. SOURCE INDICATORS

003. SOURCE BUTTON

004. VOLUME KNOB

005. BASS KNOB

006. TREBLE KNOB

007. MICROPHONES

008. PLAY/PAUSE BUTTON

009. MICROPHONE BUTTON

009.

007.

004.

005.

006.

008.

001.

002.

003.

006.

012. 013.

009.

010. 011.

GENERAL DESCRIPTION CONTINUED

009. BASS PORT

010. BACKPLATE

011. USB SERVICE PORT

012. MAINS INPUT

013. MAINS LEAD

NOTE: DATE CODE

AND SERIAL NUMBER

STICKER LOCATED HERE.

007.

PLUGGING IN THE ACTON II VOICE

IMPORTANT: ALWAYS ENSURE THAT THE MAINS LEAD, MAINS PLUG AND

SPEAKER ARE COMPATIBLE WITH YOUR MAINS SUPPLY AND WALL SOCKET.

001. CONNECT THE MAINS LEAD INTO THE MAINS INPUT ON THE SPEAKER.

002. CONNECT THE MAINS PLUG TO THE WALL SOCKET.

CAUTION: ALWAYS UNPLUG THE MAINS

LEAD FROM THE WALL SOCKET BEFORE

DISCONNECTING IT FROM THE SPEAKER.

001. 002.

008.

SETTING UP THE ACTON II VOICE

CONFIGURE THE SPEAKER FOR Wi-Fi®WITH THE GOOGLE HOME APP. THE

APP IS AVAILABLE FROM THE APP STORE AND GOOGLE PLAY.

001. DOWNLOAD THE GOOGLE HOME APP AND FOLLOW THE IN-APP

INSTRUCTIONS TO SET UP YOUR SPEAKER.

DOWNLOAD ON THE GET IT ON

009.

USING THE GOOGLE ASSISTANT BUILT-IN

THE ACTON II VOICE HAS THE GOOGLE ASSISTANT BUILT-IN. YOU CAN PLAY

MUSIC, FIND ANSWERS ON GOOGLE SEARCH, MANAGE EVERYDAY TASKS,

AND EASILY CONTROL SMART DEVICES AROUND YOUR HOUSE, SIMPLY BY

USING YOUR VOICE.

LISTEN TO YOUR FAVOURITE SONG, FIND A DELICIOUS BROWNIE RECIPE, OR

CHECK YOUR COMMUTE TO WORK.

JUST START BY SAYING OK GOOGLE.

• OK GOOGLE, HOW'S THE WEATHER?

• OK GOOGLE, TURN UP THE VOLUME.

• OK GOOGLE, REWIND 15 SECONDS.

Ok Google

010.

CAUTION: MAKE SURE THAT

THE VOLUME IS SET TO LOW

ON BOTH THE SPEAKER AND

THE MUSIC PLAYER BEFORE

USING THE SPEAKER.

SELECTING AUDIO SOURCE

THERE ARE MANY WAYS TO CONNECT TO YOUR ACTON II VOICE, EITHER

WIRELESSLY OR BY CABLE.

• - Wi-Fi STREAMING VIA CHROMECAST

• - WIRELESS Bluetooth®CONNECTION

• AUX - 3.5 mm STEREO JACK

001. PUSH THE SOURCE BUTTON TO TOGGLE BETWEEN Wi-Fi, Bluetooth

AND AUX AUDIO SOURCE.

002. A LIT INDICATOR SHOWS WHICH SOURCE IS SELECTED.

001. 002.

011.

USING ACTON II VOICE WITH Chromecast built-in

Chromecast built-in IS A PLATFORM THAT LETS YOU STREAM YOUR

FAVOURITE MUSIC FROM YOUR SMARTPHONE, TABLET OR COMPUTER

RIGHT TO YOUR SPEAKER. IT IS AVAILABLE IN MOST MUSIC APPS ON THE

MARKET.

001. CONNECT YOUR DEVICE TO THE SAME Wi-Fi NETWORK AS YOUR

SPEAKER.

002. PLAY MUSIC IN YOUR FAVOURITE MUSIC APP.

003. TAP THE Chromecast built-in ICON IN YOUR MUSIC APP AND SELECT

YOUR ACTON II VOICE .

002. 003.

001.

ACTON II VOICE

012.

CONNECTING VIA Bluetooth®(PAIRING)

001. SELECT Bluetooth AS THE INPUT. PUSHING THE SOURCE BUTTON

TOGGLES THE INPUT SOURCES.

002. PUSH AND HOLD THE SOURCE BUTTON FOR 2 SECONDS.

THE Bluetooth INDICATOR STARTS TO BLINK.

003. ENABLE Bluetooth ON YOUR DEVICE (SMARTPHONE, TABLET,

COMPUTER).

004. SELECT ACTONII VOICE FROM THE Bluetooth LIST AND ACCEPT

PAIRING.

THE Bluetooth INDICATOR ON THE SPEAKER STOPS BLINKING AND

REMAINS LIT WHEN THE UNITS ARE CONNECTED.

THE ACTON II VOICE STORES UP TO EIGHT Bluetooth DEVICES

AND TRIES TO CONNECT TO THE LAST CONNECTED DEVICE FIRST.

FOR EXAMPLE, IF THE SPEAKER HAS BEEN CONNECTED TO THE

DEVICES: A –B –C –D –E –F –G –H DEVICE H IS GIVEN FIRST

PRIORITY, WHILE DEVICE A IS GIVEN LAST PRIORITY. EVERY TIME IS

SELECTED, THE SPEAKER WILL PERFORM AN AUTO CONNECTION OF

DEVICES WITHIN ITS RANGE.

001.

0:02

002.

003. 004.

ACTON II VOICE
