Morphy Richards MRMP3GN Manuale utente
INSTRUCTION MANUAL
Model: MRMP3GN / MRMP3RD
Read these instructions carefully before
using this appliance for the rst time
STORE THESE INSTRUCTIONS CAREFULLY
Digital Multifunction Cooking Pot
For product hints and tips plus more join us at
facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau
www.morphyrichards.com.au
2
Model: MRMP3GN MRMP3RD
Colour: Green Red
Rated Voltage: 220-240V~50-60Hz
Rated Power: 1350-1600W
Max Capacity: 3L (Deep Pan)
External Dimensions (W x D x H): 450 x 283 x 225mm
Net Weight: 4.95kg
NAMES OF PARTS AND ACCESSORIES
SPECIFICATIONS
1. Lid Handle
2. Lid
3. Steam Tray
4. Deep Pan
6. Griddle Pan
5. Deep Pan Handle
7. Base Handle
10. Time Dial 8. Power/
Temperature DIal
9. Digital Touch
Screen
3
WARNING
To reduce the risk of fire, electric shock, injury to persons or
damage to property, follow basic precautions including the
following:
• If the power cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
• Keep the appliance and its cord out of reach of children.
• WARNING: Misuse of appliance could cause personal injury.
• WARNING: Avoid spillage on connector. This product
incorporates a heating element which is subject to residual
heat after use. Refer to the cleaning section for more
information.
• This appliance is not intended to be operated by means of an
external timer or a separate remote-control system.
• This appliance is not intended for use by persons with reduced
physical, sensory or mental capabilities or lack of experience
and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play
with this appliance.
• In the absence of supervision, the cleaning and maintenance
work should not be done by a child.
• Use of accessories not recommended or sold by the original
manufacturer may cause risks of fire, electric shock or
personal injury.
IMPORTANT SAFETY INSTRUCTIONS
4
• This appliance must be used in accordance with the
instructions and must not be used for other purposes.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Location
• For indoor use only. Do not use outdoors or near water.
• Do not place directly under kitchen wall cupboards when in
use, as it produces large amounts of steam. Avoid reaching
over the steamer when in use.
• Cooking appliances should be positioned in a stable situation.
Power cord
• The power cord should reach from the socket to the base unit
without straining the connections.
• Remove the plug from the socket, grasp the plug and pull out
the power cord, do not pull on the cord.
• Do not let the cord hang over the edge of the table or counter
and keep it away from any hot surfaces.
• Do not let the cord run across an open space e.g. between a
low socket and table.
• WARNING: This appliance is NOT to be used with extension
leads and/or power boards.
5
Personal safety
• The temperature of accessible surfaces may be high when the
appliance is operating.
• Do not touch hot surfaces. Use oven gloves or a cloth when
removing the lid or handling hot containers as hot steam will
escape.
• WARNING: To protect against fire, electric shock and personal
injury, do not immerse cord, plugs, or appliance in water or
other liquid.
• WARNING: Extreme caution must be used when moving
the appliance when containing hot food, water, or other hot
liquids.
• Unplug from the socket when not in use, before putting on or
taking off attachments, and before cleaning.
• Do not operate any appliance with a damaged lead or plug, or
after an appliance has malfunctioned, or has been dropped or
damaged in any way.
• Do not fill above the maximum level. If the appliance is over-
filled, boiling water may be ejected which can scald.
Other safety considerations
• To open, lift the lid off towards yourself but tilted away from
you.
• Do not use any of the appliance parts in a microwave or on
any cooking/heated surfaces.
• Do not place on or near a hot gas or electric burner, or in a
heated oven.
• When steaming, make sure the water does not fall below the
minimum level.
6
Treating scalds
• Run cold water over the affected area immediately. Do not
stop to remove clothing, get medical help quickly.
Electrical requirements
• Check that the voltage on the rating plate of your appliance
corresponds with your house electricity supply which must be
A.C.
• WARNING: This appliance must be earthed.
• WARNING: This appliance is NOT to be used with extension
leads and/or power boards.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
7
DIGITAL CONTROL PANEL EXPLANATIONS
TIME DIAL - The operating times can be adjusted by rotating the
dial to the left or right. For the relevant functions below:
• COOK - Rotate clockwise increases 10 minute increments &
anti-clockwise decreases 1 minute increments (Max 2 hours).
• GRILL - Rotate clockwise increases 5 minute increments &
anti-clockwise decreases 1 minute increments (Max 60 mins).
• STEAM - Rotate clockwise increases 5 minute increments &
anti-clockwise decreases 1 minute increments (Max 60 mins).
• STEW - Rotate clockwise increases 10 minute increments &
anti-clockwise decreases 1 minute increments (Max 3 hours).
• PRESET - The Preset function operates ONLY with the STEAM
or STEW function. Rotate clockwise increases 30 minute
increments & anti-clockwise decreases 5 minute increments.
MENU BUTTON - Press to select the desired cooking function
from COOK, GRILL, STEAM or STEW.
START/STOP BUTTON - After selecting a cooking function in the
MENU and choosing a heating power or temperature setting with
the COOK/GRILL dial:
• Press START/STOP once briefly to start or pause cooking.
• Hold START/STOP button down for 2 seconds to stop cooking
and return to standby.
8
DIGITAL CONTROL PANEL EXPLANATIONS
PRESET BUTTON - The Preset button operates a countdown
program where the user can choose when the element starts
heating. It operates ONLY with the STEAM or STEW function.
• STEAM - After selecting STEAM from the MENU button,
rotate the TIME dial to the desired cooking duration (15 to 60
minutes). After setting the cooking time, press the PRESET
button and rotate the TIME dial to adjust when to start the
heating process (maximum preset time is 12 hours). Press
the START/STOP button to enter the PRESET mode and the
PRESET time starts to countdown. Note: The PRESET time
includes the selected cooking duration time.
• STEW - After selecting STEW from the MENU button, rotate
the TIME dial to the desired cooking duration (1.5 to 3 hours).
After setting the cooking time, press the PRESET button
and rotate the TIME dial to adjust when to start the heating
process (maximum preset time 12 hours). Press the START/
STOP button to enter the PRESET mode and the PRESET time
starts to countdown. Note: The PRESET time includes the
selected cooking duration time.
9
DIGITAL CONTROL PANEL EXPLANATIONS
COOK/GRILL DIAL - Depending on the function selected, the
operating power or temperature can be adjusted by rotating the
dial to the left or right. For the relevant functions below:
• COOK - Press the MENU button to select COOK and rotate the
COOK/GRILL dial clockwise to increase the heating wattage
from 200W to a maximum of 1600W or rotate anti-clockwise to
decrease the wattage. Each rotation increases or decreases
in 200W increments. The COOK indicator light will flash while
changing the power.
• GRILL - Press the MENU button to select GRILL and rotate
the COOK/GRILL dial clockwise to increase the heating
temperature from 140°C to a maximum of 220°C or rotate
anti-clockwise to decrease the temperature. Each rotation
increases or decreases in 5°C increments. The GRILL indicator
will flash while changing the temperature.
10
Before using this product for the first time, please:
• Wash the Deep Pan, Griddle Pan and Steam Tray accessories
in warm soapy water and dry before use.
• Before placing any accessory onto the element, make sure
there is no water between the accessory base and the heating
element (see below diagrams).
• Ensure any accessory placed on the element is fitted correctly
and stable.
• When heating for the first time expect a small amount of
smoke. This is normal and will not last for long.
BEFORE FIRST USE
COOKING TEMPERATURES
Heat Power Heat Temperature Examples
200-600W - Reheating food
800-1200W 140-180°C Pancakes, Rice,
Vegetables
1400-1600W 190-220°C Grilling Meat,
Steaming, Hot Pots
