MP-Man MP-CS250 Manuale utente
MP-CS250
USERS GUIDE
www.mpmaneurope.com
Thank you for purchasing our latest product MP-CS250. Please read the instruction carefully
for safe use. We recommend you to keep this instruction manual for future reference.
CONTENT
PCDEVICE 1
NOTES 2
PRODUCT INTRODUCTION 3
FUNCTION INTRODUCTION 4
BUTTONS AND CONNECTIONS 5
BASICOPERATION 6
OPERATIONDETAILS 7
APPENDIX 21
TROUBLE SHOOTING 25
SPECIFICATION & ACCESSORIES 27
PC DEVICE
1. PC’s minimum system requirement
●WIN98/ME/2000/XP.
●Pentium 166MHz or above,
●USB port,
●32MB memory (64MB for WIN2000) or above,
●20MB hard disk space
●CD-ROM Drive
●Sound card
●Internet connection
2. Connect MP3 player to your PC
Using USB cable (it is supplied in the accessories) connect USB port terminal from
the player to USB port on PC correctly.
Notice: please power on the player before insert USB cable. Otherwise it will
influence the player’s function. Other USB cables than the provided USB cable
should not be used.
1
NOTES
Dear customer, thank you for choosing our product. Please read the following
instruction carefully before using the MP-CS250.
1. Don’t use in high temperature, high humidity environment, especially don't use in
places like bathroom. Between 0°c and +40°c is the best working temperature for
your MP-CS250.
2. Avoid putting the MP-CS250 at a place where the sunshine penetrates directly.
3. Inserting or removing the SD card should be done on the “power off “state.
4. Avoid touching the MP-CS250 with sharp objects.
5. Please don't dismantle the MP-CS250 without authorisation. Please contact with
distributor or our company, if any query.
6. Please don't change the battery yourself. Be carefull that the battery can explode if
put into fire.
7. Please don't use it when driving any type of vehicule.
2
PRODUCT INTRODUCTION
PRODUCT INTRODUCTION
1) Video function: supports MPEG-4 in ASF format, and much more other formats
(with converter supplied in the CDROM). The play effection is 320x240@30f/s
2) Audio play function: supports MP3/WMA/WAV.
3) Picture viewer function: supports JPEG. format.
4) Video recording / Av in: video encoder with line-in cable (supports PAL and
SECAM systems)
5) Video output / Av out（NTSC/PAL）
6) SD/MMC card slot: to extend the memory space (up to 1GB).
7) Built-in microphone: support Line-in voice recording.
8) Calendar, game, clock.
9) Multiple languages (Chinese/English) setting
10) Built-in Lithium battery
11) Built-in speaker
3
Function introduction Yes/no
Video play Yes
Video recording Yes
Music playing Yes
Photo browsing Yes
Digital recording Yes
TV input Yes
TV output Yes
Game Yes
Calendar Yes
Memory checking Yes
Multiple languages Yes
Key Lock function Yes
Screen protection Yes
FUNCTION INTRODUCTION
4
BUTTONS AND CONNECTIONS
LINE-IN（AV input）
SD/MMC CARD SLOT
RESET
MIC
INTERNAL SPEAKER
CHARGE
USB port
EARPHONE（AV output）
TFT screen
PLAY
MODE/SHUTTER
ESC
POWER ON
LOCK
MENU
HANDLING
* Press "ESC"button to escape current operation.
* Working state when the green light is on.
* In Charge when the red light is on.
5
BASIC OPERATION
Power on
Press Power On button, to enter the main menu of the
MP-CS250.
Power off
Press Power on button for 3 seconds to power off.
Charge operation
Connect the charger to the power, and connect the port to the MP-CS250 charge port.
At this moment, the MP-CS250 enters charge mode. It takes around 5 hours for
charging completely the MP-CS250. It is best to charge when it is off
Notice: charge operates at both on/off state. The red light is on when charging, it
will diseappear when charge is complete.
Connect PC operation.
Power on the player, then connect player with PC by USB cable .
6
BASIC OPERATION
When connecting the MP-CS250 to the PC you will find in “MY COMPUTER”
directory two REMOVABLE DISCS. The first one is flash memory disc, the second is
SD/MMC card memory.
OPERATIONDETAILS
I. VIDEO OPERATION:
1. Press power on button during 3 seconds to switch on the MP-CS250 and wait for
the player to enter stand-by interface.
2. Select “Video” function by using the buttons, and press “MENU ” to
confirm.
3. After entering the operating interface, press button to choose the video
content you want. Press play button to confirm.
4. Before pushing the play button press“ MENU” button to enter setting interface,
you will then be able to select EQ Mode, Play mode, File protection, Deleting file
operation etc...
5. Press to fast forward and fall back (x2, x4, x8 speed),
6. In play mode you can adjust the volume by pressing the“+”/“-”buttons.
7
OPERATION DETAILS
Writing Protect: Protect the selected file
File protection：
Release protection
Clock show
Power indication
Current song written
protection
HOLD state
Play Mode: REP ONE, REP ALL , RANDOM, NORMAL
(No display)
Audio setting:8KHz, 16KHz, 24KHz, 32KHz, 48KHz
8
