Multitech TalkAnytime TA2410 Manuale utente

TalkAnytime

Click-to-Talk Media Server

Cabling Guide

Digital Models: TA2410 &

TA3010

TalkAnytime®Cabling Guide

2 Multi-Tech Systems, Inc.

Cabling Guide

TalkAnytime®Click-to-Talk Media Servers

Digital Models (T1 and E1): TA2410 and TA3010

82100220L Rev. A

This publication may not be reproduced, in whole or in part, without prior expressed

Multi-Tech Systems, Inc. makes no representations or warranty with respect to the

contents hereof and specifically disclaims any implied warranty of merchantability or

fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves

the right to revise this publication and to make changes from time to time in the

content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes. Check Multi-Tech’s web site for current

versions of our product documentation.

Revision Date Description

A 11/29/06 Initial release.

Trademarks

Multi-Tech, TalkAnytime, and the Multi-Tech logo are registered trademarks of

Multi-Tech Systems, Inc. MultiVOIP is a trademark of Multi-Tech Systems, Inc. All

other brand and product names mentioned in this publication are trademarks or

registered trademarks of their respective companies.

Patents

This Product is covered by one or more of the following U.S. Patent Numbers:

6151333, 5757801, 5682386, 5.301.274; 5.309.562; 5.355.365; 5.355.653;

5.452.289; 5.453.986. Other Patents Pending.

GENERAL CONTACT TECHNICAL SUPPORT

Country By E-mail By Phone

France support@

multitech.fr (+33) 1-64

61 09 81

India support@

multitechindia.

com

(+91) 124-

2340780

Europe,

Asia,

Africa

support@

multitech.co.uk (+44) 118

959 7774

Multi-Tech

Systems, Inc.

2205 Woodale Drive

Mounds View,

Minnesota

55112, USA

(763) 785-3500

(800) 328-9717

Fax: 763-785-9874

www.multitech.com

U.S.,

Canada,

All Others

support@

multitech.com (800) 972-

2439; (763)

717-5863

TalkAnytime®Cabling Guide

Multi-Tech Systems, Inc. 3

Introduction

This guide shows you how to make the cable connections to set up your

digital TalkAnytime®unit. See the TalkAnytime User Guide included on the

TalkAnytime CD for more information. The “Quick Start Instructions” chapter shows

how to get the TalkAnytime unit up and running with a basic configuration.

Safety Warnings

Lithium Battery Caution

A lithium battery on the voice/fax channel board provides backup power for the

timekeeping capability. The battery has an estimated life expectancy of ten

years.

When the battery starts to weaken, the date and time may be incorrect. If the

battery fails, the board must be sent back to Multi-Tech Systems for battery

replacement.

Warning: There is danger of explosion if the battery is incorrectly

replaced.

Ethernet Ports Caution

Caution: The Ethernet ports and command ports are not designed to

be connected to a Public Telecommunication network.

Safety Warnings Telecom

•Use this product only with UL- and CUL-listed computers (US).

•Never install phone wiring during a lightning storm.

•Never install a phone jack in a wet location unless the jack is specifically

designed for wet locations.

•Never touch uninsulated phone wires or terminals unless the phone line has

been disconnected at the network interface.

•Use caution when installing or modifying phone lines.

•Avoid using a phone during an electrical storm; there is a risk of electrical

shock from lightning.

•Do not use a phone in the vicinity of a gas leak.

•To reduce the risk of fire, use only 26 AWG or larger telephone line cord.

•This product must be disconnected from power source and telephone

network interface when servicing.

Safety Recommendations for Rack Instructions

•Ensure proper installation of the TalkAnytime unit in a closed or multi-unit

enclosure by following the recommended installation as defined by the

enclosure manufacturer. Do not place the TalkAnytime unit directly on top

of other equipment or place other equipment directly on top of the

TalkAnytime unit.

TalkAnytime®Cabling Guide

4 Multi-Tech Systems, Inc.

Safety Recommendations for Rack Instructions (cont’d)

•If installing the TalkAnytime unit in a closed or multi-unit enclosure, ensure

adequate airflow within the rack so that the maximum recommended

ambient temperature is not exceeded.

•Ensure that the TalkAnytime unit is properly connected to earth ground via a

grounded power cord. If a power strip is used, ensure that the power strip

provides adequate grounding of the attached apparatus.

•Ensure that the mains supply circuit is capable of handling the load of the

TalkAnytime unit. See the power label on the equipment for load

requirements.

•Maximum ambient temperature for the TalkAnytime unit is 60 degrees

Celsius (140°F) at 20-90%s non-condensing relative humidity.

•This equipment should only be installed by properly qualified service personnel.

•Only connect like circuits. In other words, connect SELV (Secondary Extra

Low Voltage) circuits to SELV circuits and TN (Telecommunications

Network) circuits to TN circuits.

•To reduce the risk of shock, all access doors should be closed during

normal operation of the equipment.

TalkAnytime®Cabling Guide

Multi-Tech Systems, Inc. 5

TA-2410/3010 Package Contents

•One TalkAnytime®TA2410 or TA3010 unit

•One power cord

•One command cable (RJ45-to-DB9 connectors)

•Two rack-mount brackets and four mounting screws

•One printed Cabling Guide

•One TalkAnytime CD containing software and user documentation.

Cabling

Guide

TalkAnytime R

TalkAnytimeR

TalkAnytime®Cabling Guide

6 Multi-Tech Systems, Inc.

Quick Hookup for TA2410 & TA3010

TalkAnytime®Cabling Guide

Multi-Tech Systems, Inc. 7

Earth Ground Connection & Power-Up

Product

Ground

Screw

Grounding connectors

must be secured

permanently to

product ground screw

and earth ground screw.

Earth Ground Screw:

Connected to

Permanent Earth Ground

of Building’s

Electrical System

Ground

Wire:

Size 18AWG

or thicker

TalkAnytime

Unit

GND

Ground Connection. Ensure that the unit is securely and permanently

connected to an earth ground (GND) with a ground wire of 18 gauge (18

AWG) or thicker. The ground wire needs to be installed between the

grounding screw on the TalkAnytime chassis and a permanent earth ground.

Whether the unit is used in a rack or on a desktop, you must verify that the

earth ground connection is permanent and reliable. In order for the ground

connection to be considered permanent, the grounding wire must connect to

the earth ground of the building's electrical wiring system and the ground

connection must use a screw terminal or other reliable means of fastening.

The ground connection must not be as easily disconnected as, for example, a

power cord.

Power-Up. The TalkAnytime unit’s fan is on whenever the power cord is

connected to a power source. Turn on power to the TalkAnytime circuitry by

placing the ON/OFF switch on the back panel to the ON position. Wait for

the Boot LED to go off before proceeding. This may take a few minutes.

TalkAnytime Configuration

When the cabling connections above have been made, go to the “Quick Start

Instructions” chapter of the User Guide (on your TalkAnytime CD) for detailed

instructions about configuration.

82100220L
