Multitech MTASR3-200 Manuale utente

Remote Access Device

Remote Access Server

with Integrated

WAN Devices

Model MTASR3-200

Quick Start Guide

S000334B Revision B

RASFinder Model MTASR3-200

This publication may not be reproduced, in whole or in part, without

prior expressed written permission from Multi-Tech Systems, Inc.All

rights reserved.

Multi-Tech Systems, Inc.makes no representations or warranties

with respect to the contents hereof and specifically disclaims any

implied warranties of merchantability or fitness for any particular

purpose.Furthermore, Multi-Tech Systems, Inc.reserves the right

to revise this publication and to make changes from time to time in

the content hereof without obligation of Multi-Tech Systems, Inc.to

notify any person or organization of such revisions or changes.

Record of Revisions

Revision Description

AReplaces printed Quick Start 82072506 (5/31/00).

(2/25/04) Manual revised to remove coax cable connection.

BUpdated the Technical Support contact list and

(6/20/07) warranty statement and corrected the pin out for the

command cable.Updated CD image.

Patents

This Product is covered by one or more of the following U.S.

Patent Numbers:

5.301.274; 5.309.562

;

5.355.365; 5.355.653;

5.452.289;5.453.986

.Other Patents Pending.

TRADEMARK

The Multi-Tech logo and RASFinder are trademarks of Multi-Tech

Systems,Inc.Windowsisa registeredtrademarkofMicrosoftCorpora-

tion in the United States and other countries.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(763) 785-3500 or (800) 328-9717

Fax 763-785-9874

Tech Support (800) 972-2439

Internet Address: http://www.multitech.com

iii

Contents

Introduction.................................................................................... 4

Related Documentation ................................................................. 4

Safety Warnings ............................................................................ 5

Unpacking your RASFinder ........................................................... 6

Cabling your RASFinder ................................................................ 7

InstallingYour RASFinder Software ............................................... 9

IP Routing Setup ................................................................... 14

Setting UpYour Remote User Database...................................... 17

Setting Up Remote Access Dial In User Server (RADIUS).......... 25

Final Routing Setup .................................................................... 28

RASFinder MTASR3-200 Quick Start Guide

Introduction

Welcome to Multi-Tech's RASFinder™, Model MTASR3-200, a

dial-up Remote Access Server (RAS) with three built-in 56K

modems for connecting telecommuters and mobile users to a

corporate LAN. A secondary capability of the RASFinder is LAN-

to-LANrouting.

In its basic (remote access) function, the RASFinder supports up

to three concurrent dial-in sessions and IP or IPX remote access.

It also provides dial-out and faxing support for PC users on a

Novell IPX network.

The RASFinder features a 10BaseT port for local LAN connection,

a Command Port for configuration, and three internalV.90

modems*.System management is provided through the command

port using bundled Windows®based software which provides

easy-to-use configuration menus.

Remote Access Device

Figure 1. RASFinder Model MTASR3-200

Note: Although these modems are capable of 56K bps download

performance, line impairments, public telephone infrastructure and

other external technological factors currently prevent maximum 56

Kbpsconnections.

Related Documentation

The MTASR3-200 Quick Start Guide is intended to be used by

qualified systems administrators and network managers. This

quick start guide provides the necessary information for a qualified

person to unpack, cable, load software, and configure the unit for

properoperation.

Introduction

Safety Warnings

1. Never install phone wiring during a lightning storm.

2. Never install phone jacks in wet locations unless

the jack is specifically designed for wet locations.

3.This product is to be used with UL and cUL listed computers.

4. Never touch uninsulated phone wires or terminals unless

the phone line has been disconnected at the network

interface.

5. Use caution when installing or modifying phone lines.

6. Avoid using a phone (other than a cordless type) during an

electrical storm. There may be a remote risk of electrical

shock from lightning.

7. Do not use the phone to report a gas leak in the vicinity of

the leak.

8. To reduce the risk of fire, use only No.26 AWG or larger

Telecommunication line cord.

RASFinder MTASR3-200 Quick Start Guide

Unpacking your RASFinder

Remove all items from the box.See Figure 2.

MADEINU.S.A

MADE IN U.S.A

RD TD CL LK RD TD CD NS DS RD TD CD

V35

Remote Access Device

www.multitech.com

Voice/Fax over IP Networks

200

Remote Access Device

Figure 2. UnpackingYour RASFinder

Cabling

Cabling your RASFinder

Cabling your RASFinder involves making the proper WAN,

Ethernet, Command Port, and Power connections. Figure 3 shows

the back panel connectors and the associated cable connections.

TThe following procedure provides step-by-step instructions for

connecting the cables to your RASFinder.

WAN Connections

Power Connection

Ethernet Connection

LINK3 LINK2 LINK1 ETHERNET C MMAND P WER

10BASET 10BASE2

Command Cable

(supplied)

User-Supplied Cable

DB 5 (male) to

DB9 (female)

Figure 3. Cable Connections

1. Connect the RASFinder to a PC using the short RJ-45 to

DB9 (female) cable provided with your unit.Plug the RJ-45

end of the cable into the Command Port of the RASFinder

and the other end into the PC's serial port.See Figure 3.

2. Connect an RJ-45 (UTP) cable to the 10 BASE-T

connector on the back of the RASFinder. Connect the

other end of the cable to your LAN.

3. Connect one end of an RJ-11 cable to each of the LINK

Connectors on the RASFinder (labeled LINK 1,

LINK 2, and LINK 3) and connect the other end to the

phone jacks (as shown in Figure 3).

RASFinder MTASR3-200 Quick Start Guide

4. Connect one end of the power supply to a live AC outlet

and connect the other end to the RASFinder as shown in

Figure 3.The power connector is a 6-pin circular DIN

connector.

5. Turn on power to the RASFinder by setting the backpanel

ON/OFF switch to the ON position.Wait for the Fail LED

on the RASFinder to go OFF before proceeding.This may

take a couple of minutes to go OFF.

At this time your RASFinder is completely cabled and

powered on.

Proceed to the next section to install the RASFinder software.

Software

Installing Your RASFinder Software

The RASFinder software is set up to default to a Remote Access

Server (RAS) application.Within the RAS application, you can

configure the RASFinder to communicate with either a Radius

Server for centralized network security or a proprietary Remote

User Data base utility to establish your remote user profiles.You

can also configure the RASFinder as a router for LAN-to-LAN

routing.

The RASFinder CD-ROM contains your RASFinder software, this

Quick Start, and the User Guide.The RASFinder CD-ROM is auto-

detectable, and should start automatically when inserted into your

CD-ROM drive. After configuring your RASFinder, you can view

the User Guide by clicking theView Manuals icon and selecting

either the Quick Start or User Guide.

1. Insert the RASFinder CD-ROM into the CD-ROM drive on your

local PC.The CD-ROM should start automatically;however, it

may take 10 to 20 seconds for the RASFinder screen to

appear.

If the RASFinder Splash screen does not appear automatical-

ly, click My Computer, right-click the CD-ROM drive icon, then

click (Autorun or AutoPlay).

RASFinder MTASR3-200 Quick Start Guide

2. When the RASFinder screen appears, click the Install RAS

Software button.

3. The welcome screen is displayed.

Press Enter or click Next> to continue.

4. The Choose Destination Location dialog box is displayed.

Follow the onscreen instructions to install your RASFinder

software.

You can either choose a different Destination Location for your

RASFinder software by clicking Browse, or select the default

destination by pressing Enter or clicking Next>.

It is recommended that you accept the default folder,

C:\RASFind.xxx
