Notes:
1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect
data.
2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value,
the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device
reports according to MaxTime interval.
3)We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up
frequently and the battery will be drained soon.
4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle
of MinTime / MaxTime calculation is started.
6.Seat Occupancy Delay Configuration
There is a delay configuration specially designed for battery saving. The delay configuration logic includes DetectionTime and
DisableTime.
DisableTimeis the sampling period;
DetectionTime is the detecting period. (Please find further info regarding DisableTime and DetectionTime below.)
(1)When R313WA detects pressure caused by the occupancy of the seat, it will report 1 (indicating the seat is taken) and other
status (battery for example).
(2)The delay configuration will be triggered after the occupancy is detected.
Once the delay configuration is triggered, the device will enter the detecting and sampling period
(i.e. the DetectionTime and DisableTime.)
Note:
How long you set the DetectionTime and DisableTime will determine the number of the periods of DisableTime
R313WA will only report 0 (indicating the seat is unoccupied ) when the following is both fulfilled:
a. A DetectionTime is finished
b. No pressure is detected during the DisableTime (the default setting is 30 seconds, and it can be changed)
Note:
1. If DetectionTime and DisableTime are not set to the same, there will be multiple DisableTime periods, and all of them
should detect no pressure to fulfill this prerequisite.)
