553-3001-358

Meridian 1, Succession 1000, Succession 1000M

Meridian Integrated Conference

Bridge

Service Implementation Guide

MICB 3 Standard 1.00 October 2003

Test this out

Meridian 1, Succession 1000, Succession 1000M

Meridian Integrated Conference Bridge

Service Implementation Guide

Document Number: 553-3001-358

Product Release: MICB 3

Document Release: Standard 1.00

Date: October 2003

Produced in Canada

Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as

progress in engineering and manufacturing may warrant. This equipment has been tested and found to comply with the limits for a

Class A digital device pursuant to Part 15 of the FCC rules, and the radio interference regulations of Industry Canada. These limits

are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct the interference at their own expense.

SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

Meridian Integrated Conference Bridge Service Implementation Guide

Page 5 of 208

Revision history

October 2003 Standard 1.00. This document is a new document for Succession 3.0.

It was created to support a restructuring of the Documentation Library.

This document contains information previously contained in the

following legacy document, now retired: Meridian Integrated

Conference Bridge: Description, Installation, Administration, and

Maintenance (553-3001-102, 555-4001-135).

Page 6 of 208

553-3001-358 Standard 1.00 October 2003

Meridian Integrated Conference Bridge Service Implementation Guide

Page 7 of 208

Contents

About this document 9

Product description 15

Purpose 15

MICB description 15

Hardware overview 19

MICB operation 24

Engineering guidelines 31

Purpose 31

System requirements 31

System compatibility 33

Automatic call distribution resource allocation 33

LAN configuration 35

Installation and configuration 41

Purpose 41

Getting started 41

Succession 1000M, Succession 1000, and Meridian 1 configuration 42

Meridian SL-100 configuration 51

MICB installation and configuration procedures 61

MICB Installation Wizard 68

Browser User Interface 77

Purpose 77

Overview 77

Scheduling BUI 83

Chairperson operations 93

Administration BUI 98

Telephone User Interface 127

Purpose 127

Overview 127

TUI operation during an active conference 128

TUI services 138

Page 8 of 208

553-3001-358 Standard 1.00 October 2003

Maintenance 143

Purpose 143

Maintenance overview 143

Diagnostic tools 145

CLI command summary 149

MICB fault isolation and correction 152

Error message handling 154

Backup and restore procedures 158

Reports 165

Purpose 165

Overview 165

Short Connection Report 167

Meetings Log Report 168

Overbooking Report 170

Billing Report 172

Maintenance (Error) Report 179

Upgrades 183

Purpose 183

Overview 183

Planning for an upgrade 185

Upgrade procedures 186

Appendix A: Password security 193

Purpose 193

Access permissions 194

Unsuccessful login attempt handling 195

Password parameters summary 196

Reset passwords 197

Appendix B: Product integrity 201

Purpose 201

Environmental specifications 201

Regulatory standards 202

List of terms 205

Meridian Integrated Conference Bridge Service Implementation Guide

Page 9 of 208

About this document

This document is a global document. Contact your system supplier or

your Nortel Networks representative to verify that the hardware and

software described are supported in your area.

Subject

The subject of this document is the installation, configuration,

operation, and maintenance of the Meridian Integrated Conference

Bridge (MICB) as a part of the overall system. The MICB card allows

you to schedule and configure multiple simultaneous conferences.

You can install the MICB card in Succession 1000M, Succession 1000,

Meridian 1, or Meridian SL-100 systems. In the majority of places the

MICB operates the same way regardless of the system in which you

install it. When the information differs between systems, this guide

contains separate sections for the Meridian SL-100 and the

Succession 1000M, Succession 1000, and Meridian 1 (for example,

configuration information).

Note on legacy products and releases

This NTP contains information about systems, components, and

features that are compatible with Succession 3.0 Software. For more

information on legacy products and releases, click the

Technical Documentation link under Support on the Nortel Networks

home page:

http://www.nortelnetworks.com/

Applicable systems

This document applies to the following systems:

• Meridian 1 Option 11C Chassis

• Meridian 1 Option 11C Cabinet

• Meridian 1 Option 51C

• Meridian 1 Option 61

Page 10 of 208

553-3001-358 Standard 1.00 October 2003

• Meridian 1 Option 61C

• Meridian 1 Option 61C CP PII

• Meridian 1 Option 81

• Meridian 1 Option 81C

• Meridian 1 Option 81C CP PII

• Succession 1000

• Succession 1000M Cabinet

• Succession 1000M Chassis

• Succession 1000M Half Group

• Succession 1000M Single Group

• Succession 1000M Multi Group

Note that memory upgrades may be required to run Succession 3.0

Software on CP3 or CP4 systems (Options 51C, 61, 61C, 81, 81C).

System migration

When particular Meridian 1 systems are upgraded to run

Succession 3.0 Software and configured to include a Succession

Signaling Server, they become Succession 1000M systems. Table 1

lists each Meridian 1 system that supports an upgrade path to a

Succession 1000M system.

Table 1

Meridian 1 systems to Succession 1000M systems (Part 1 of 2)

This Meridian 1 system... Maps to this

Succession 1000M system

Meridian 1 Option 11C Chassis Succession 1000M Chassis

Meridian 1 Option 11C Cabinet Succession 1000M Cabinet

Meridian 1 Option 51C Succession 1000M Half Group

Meridian 1 Option 61 Succession 1000M Single Group

Meridian 1 Option 61C Succession 1000M Single Group

Meridian 1 Option 61C CP PII Succession 1000M Single Group

Meridian 1 Option 81 Succession 1000M Multi Group
