Nostalgia Electrics HSB-590 Guida rapida

All products are trademarks of Nostalgia Products Group, LLC.

Worldwide design & utility patented or patents pending.

www.nostalgiaelectrics.com

(rev. 10/14/11)

HSB590 SERIES

Stainless Steel Margarator

Instructions and Recipes

ENGLISH

CONTENTS

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . 3

IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . 3

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . 5

HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . . . 6

HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . 8

RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . . 12

SAFETY

Appliance Speciﬁcations:

120 Volts, 60 Hz

150 Watts, ETL Approved

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and

on your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards

that can kill or hurt you and others.

All safety messages will follow the safety alert symbol.

All safety messages will tell you what the potential hazard

is, tell you how to reduce the chance of injury, and tell you

what can happen if the instructions are not followed.

ENGLISH

IMPORTANT PRECAUTIONS

NEVER immerse the Base or cord in water.1.

NEVER use near water.2.

NEVER leave unit unattended if used near children.3.

NEVER use a scouring pad on the appliance.4.

NEVER use an abrasive sponge or harsh cleaning5.

products on or inside of the appliance.

NEVER use for anything other than what this item was originally intended.6.

Avoid contact with moving parts.7.

DO NOT operate this appliance with a damaged cord or plug,8.

or in the event the appliance ever malfunctions.

DO NOT place parts in dishwasher.9.

Keep out of reach of children.10.

Unplug appliance from electrical outlet when not in use and before11.

cleaning. Remove plug by gripping the plug body and pulling out

of the outlet. Never yank or twist cord to unplug the unit.

This appliance is NOT A TOY.12.

This appliance is not intended for use by young children or13.

cognitively challenged individuals without supervision.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including:

Read all instructions before operating this appliance.1.

NEVER put ﬁngers or utensils into feed or discharge areas.2.

Keep hands and utensils out of container while blending to reduce3.

the risk of severe personal injury or damage to the appliance.

To protect against electrical shock do not immerse cord,4.

plug or main unit in water or other liquids.

Close supervision is necessary when any appliance is used by or near children.5.

Unplug from outlet when not in use and before removing parts for cleaning.6.

DO NOT operate any appliance with a damaged cord or plug or7.

if the appliance has been damaged in any manner. Return the

appliance to the nearest repair shop for examination or repair.

The manufacturer does not recommend the use of accessory8.

attachments. Use of attachments may cause injuries.

Blades are sharp. DO NOT touch.9.

DO NOT remove Lid when in use.10.

ENGLISH

DO NOT let the cord touch hot surfaces.11.

DO NOT place on or near a hot gas or electric burner, or in a heated oven.12.

Extreme caution must be used when moving this appliance with liquids inside.13.

This unit must be on a level surface to operate properly.14.

DO NOT use this appliance for other than its intended use.15.

DO NOT leave unit unattended while in use or when plugged into an outlet.16.

Check inside of the Blending Chamber for foreign objects prior to use.17.

A short power supply cord is provided to reduce the risk resulting18.

from becoming entangled or tripping over a long cord.

Extension cord can be used if care is exercised in use.19.

The marked electrical rating of an extension cord should be at20.

least as great as the electrical rating of the appliance.

This appliance has a polarized plug (one blade is wider than the other). To reduce the21.

risk of electrical shock, this plug is intended to ﬁt into a polarized outlet only one way.

This appliance comes equipped with an AC electrical power cord. It is22.

versatile and can be used indoors or outdoors. DO NOT use near water.

Always operate the appliance with cover in place.23.

Make sure the Blending Chamber is properly attached24.

to the Base before turning on unit.

SAVE THESE INSTRUCTIONS!

INTRODUCTION

Thank you for purchasing the STAINLESS STEEL MARGARATOR™from

Nostalgia Electrics™! The STAINLESS STEEL MARGARATOR™is a frozen

drink machine that will add thirst-quenching fun to any occasion!

The STAINLESS STEEL MARGARATOR™uses crushed ice or small ice cubes

from your freezer. It not only makes fantastic margaritas, but can also mix up

batches of your other favorite frozen drinks such as daiquiris and slushes for

the kids! This machine is designed for kitchen or home bar use but can also be

used in places such as family rooms, dorm rooms, ofﬁces and club houses.

Features include:

Patented dual swivel system that pulverizes and shaves ice,•

dispensing consistently smooth frozen drinks

Insulated container ups to 128 ounces of your favorite frozen beverage•

Clear Blending Chamber detaches from Base for easy clean up•

Convenient Cord Storage•

ENGLISH

Blending Chamber

Base

Lid

Spout

Stainless Steel

Grinding Cage

Clear

Window

PARTS & ASSEMBLY

Cord Location

The cord storage is located at the base of the unit:

Attaching and Removing the Grinding Cage

It is very important that the Stainless Steel Grinding Cage is

assembled properly in order for the unit to work.

The Stainless Steel Grinding Cage is1.

attached to the inside of the Blending

Chamber with a round Plastic Collar.

Place the Stainless Steel Grinding2.

Cage with the smooth end

(opposite of end with three tabs)

into the Plastic Collar and twist

until the notch of the Stainless

Steel Grinding Cage locks into the

protrusion on the Plastic Collar.

Turn the assembled Stainless Steel Grinding Cage with Plastic Collar over, so3.

Plastic Collar is on the top to insert into the base of Blending Chamber.

Looking down into the interior of the Blending Chamber, you will

Screws

Stainless Steel

Grinder

Plastic Collar

ENGLISH

see two stainless steel screws. This is where the clips attached

to the Plastic Collar lock the grinding mechanism down.

When putting the Plastic Collar into position, align5.

the Tabs with the indents in the base of the Blending

Chamber. With ﬁrm but gentle pressure, press the

Plastic Collar down until the Clips “click” into place.

Once everything is in place, make sure the Clips6.

are pushed inward toward the screws to lock the

unit into position and lift slightly to ensure the

Stainless Steel Grinding Cage is in fact locked

into position properly and will not release. Lock

and unlock Clips carefully to avoid breaking.

NOTE: IF THE PLASTIC COLLAR IS NOT LOCKED PROPERLY

THE UNIT WILL GRIND BUT WILL NOT DISPENSE.

Now you are ready to enjoy cold, refreshing margaritas and

drinks from your STAINLESS STEEL MARGARATOR™!

HOW TO OPERATE

Before ﬁrst use, remove all packaging materials and detach Blending Chamber from1.

Base by sliding the three UNLOCK/LOCK switches to the UNLOCK position.

Pour warm, soapy water into the Blending Chamber and2.

dispense all of the soapy water through the Spout.

After dispensing all warm, soapy water, rinse by pouring clean water3.

into the Blending Chamber and dispense clean water through the Spout

until no soapy residue remains and water comes out clean.

Wipe down the STAINLESS STEEL MARGARATOR™ exterior with a clean,4.

non-abrasive cloth or sponge. Dry interior and exterior thoroughly with

dry, non-abrasive cloth or sponge. DO NOT put the Base in water.

After drying, ﬁrmly attach Blending Chamber to Base by placing the5.

Blending Chamber on top of Base so that Spout faces forward and

slide the three LOCK/UNLOCK switches to the LOCK position.

If Blending Chamber is attached properly, it will be aligned6.

with Base so that the Spout is over the Drip Tray.

Find a stable surface near an electrical outlet before starting. Make sure the cord is1.

away from any water source. It is acceptable to use an extension cord if needed.

DO NOT place the STAINLESS STEEL MARGARATOR™2.

near the edge of a table or countertop.

Fill the Blending Chamber with ice and ingredients to3.

the Max Fill line. DO NOT exceed the Max Fill line.

To make a batch of margaritas, ﬁll Blending Chamber4.

with ice up to the Max Fill line and then pour three

parts concentrated mix (approximately 45 oz.) to 1 part

Tequila (approximately 15 oz.). For a slushier mix, less

liquid or more ice is recommended. It is NOT recommended that you use fruit.

Plastic Collar

Clips

Tabs

ENGLISH

Place Lid on unit and line up arrows on5.

Lid and Blending Chamber. This is a

safety feature and the unit will not turn on

without the Lid in the correct position.

You can add additional liquid at6.

any time by opening the Clear

Window in the Lid. Add more

liquid after mixing to reach desired consistency.

Plug in unit and turn ON by ﬂipping the switch upward to ON position.7.

Blend for approximately 10 minutes or until mixture8.

has reached the desired consistency.

While the unit is still on, place glass underneath the Spout and dispense9.

the beverage by lifting the Spout handle up. It is recommended to place

a towel or other cloth on the table or countertop underneath the Spout

to protect against any drips. NOTE: the Spout has a locking upright

position for ﬁlling multiple drink glasses or a pitcher of drinks.

If the Spout drips after dispensing, place a glass or container underneath10.

Spout and open and close the valve by pushing down on the Spout

Handle once or twice quickly. Small ice chips can sometimes get

caught in the gasket, preventing it from closing completely.

Turn off the unit when desired consistency is achieved and it will11.

keep your beverage cold until ready to dispense again.

Always dispense beverage with the appliance turned ON. Allow the unit to12.

run for 8 seconds to mix before dispensing if unit has been sitting. When

you have ﬁnished, turn side knob to OFF position and unplug unit.

ON OFF

ENGLISH

HELPFUL TIPS

UNIT IS NOT TURNING ON

If the unit is not turning on, make sure that it is fully•

and properly plugged into the outlet.

Blending Chamber must be ﬁrmly attached to Base or unit will not turn on.•

BEVERAGE IS NOT DISPENSING

Add more liquid to Blending Chamber if vacuum•

occurs around shaving cage during use.

If the beverage is not dispensing, make sure that the•

Stainless Steel Grinding Cage did not get loose.

Make sure that there is enough liquid left inside.•

Make sure that switch is ﬂipped up to the ON position.•

Make sure that there aren't any ice chips stuck inside the Spout. Open and•

close the valve by pushing down on the Spout Handle once or twice quickly.

CLEANING & MAINTENANCE

After using your STAINLESS STEEL MARGARATOR™, disconnect from1.

electrical outlet. Remove plug by gripping the plug body and pulling

out of the outlet. Never yank or twist cord to unplug the unit.

Dispense all remaining liquid from the Blending Chamber.2.

Remove Blending Chamber from Base and ﬁll Blending Chamber with clean3.

water. Dispense all of the water through the Spout until liquid runs clear.

Wipe inside and outside of Blending Chamber with a wet, non-abrasive4.

cloth or sponge and dry thoroughly with a soft, non-abrasive towel.

Wipe Base with a dry, non-abrasive cloth.5.

DO NOT submerge Blending Chamber or Base in water. When6.

needed, use a damp, non-abrasive cloth to wipe exterior.

DO NOT put any parts in the dishwasher.7.

Once washing and drying is complete, reassemble your STAINLESS8.

STEEL MARGARATOR™. Wind the cord and return to the

convenient storage location in the bottom of the Base. Now your

STAINLESS STEEL MARGARATOR™ is ready to use again.

To prolong the life of your STAINLESS STEEL MARGARATOR™, be sure9.

to follow the cleaning instructions after every use and make sure that the

Spout is ﬂushed thoroughly while washing the unit to prevent build up.

NEVER use abrasive cleaners or towels on the Base to maintain

10.

the original stainless steel ﬁnish and prevent scratches.

You may need to occasionally remove and clean the Stainless Steel Grinding Cage.11.

Refer to the directions in the Parts & Assembly section to perform this function.

Altri manuali per HSB-590

Indice

Altri manuali Nostalgia Electrics Elettrodomestico da cucina

Nostalgia Electrics

Nostalgia Electrics MSB64 Series Manuale utente

Nostalgia Electrics

Nostalgia Electrics EQM-200 Guida rapida

Nostalgia Electrics

Nostalgia Electrics CSD-250 Manuale utente

Nostalgia Electrics

Nostalgia Electrics OFP-501 Manuale utente

Nostalgia Electrics

Nostalgia Electrics CARNIVAL CCM-Series Manuale utente

Nostalgia Electrics

Nostalgia Electrics JFD100 Series Guida rapida

Nostalgia Electrics

Nostalgia Electrics CCP-200 Guida rapida

Nostalgia Electrics

Nostalgia Electrics TPM100 Guida rapida

Nostalgia Electrics

Nostalgia Electrics APHBKT8 Series Guida rapida

Nostalgia Electrics

Nostalgia Electrics KPM508 Manuale utente

Nostalgia Electrics

Nostalgia Electrics LPF-210 Manuale utente

Nostalgia Electrics

Nostalgia Electrics Homecraft HCMF4BK Manuale utente

Nostalgia Electrics

Nostalgia Electrics RETRO SERIES RKP630 Manuale utente

Nostalgia Electrics

Nostalgia Electrics Margatartor MSB-64 Manuale utente

Nostalgia Electrics

Nostalgia Electrics Vintage SCM-802 Manuale utente

Nostalgia Electrics

Nostalgia Electrics MINI RETRO POPCORN MAKER RHP-310 Guida rapida

Nostalgia Electrics

Nostalgia Electrics LPM-529 Manuale utente

Nostalgia Electrics

Nostalgia Electrics Chocolate Fondue Fountain CFF990 Guida rapida

Nostalgia Electrics

Nostalgia Electrics HCM700 Series Guida rapida

Nostalgia Electrics

Nostalgia Electrics GCM600 Series Guida rapida

Nostalgia Electrics

Nostalgia Electrics RMDM800 Guida rapida

Nostalgia Electrics

Nostalgia Electrics CCP-510 Manuale utente

Nostalgia Electrics

Nostalgia Electrics CLBS3AQ Manuale utente

Nostalgia Electrics

Nostalgia Electrics SP440 SERIES Guida rapida

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
