NUTRICHEF PKPRC15 Manuale utente

Electronic Pressure Cooker

User Manual

PKPRC15

NutrichefKitchen.com

Contents

Getting Started

Instructions for Use

Troubleshooting

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Important Safety Instructions

Parts List

Important Safety Instructions

Read this manual thoroughly before ﬁrst use, even if you are familiar with this

type of product. The safety precautions enclosed herein reduce the risk of

fire, electric shock and injury when correctly adhered to. Keep the manual

in a safe place for future reference. If applicable, pass these instructions on

to the next owner of the appliance.

Always follow basic safety precautions and accident prevention measures

when using an electrical appliance, including the following:

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY:

READ ALL INSTRUCTIONS CAREFULLY BEFORE USING YOUR APPLIANCE.

Ensure the unit is used on a stable, level and heat-resistant surface out

of the reach of children. If necessary place a chopping board or

heat resistant mat underneath the Pressure Cooker during use.

Always attach the connector end of the power cord into the appliance

before inserting the plug into the wall socket.

Do not touch the hot surfaces of the Pressure Cooker, use the handles only.

Never allow children to use this appliance, close supervision is necessary

when this appliance is in use near children.This appliance is not

intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

Do not operate the appliance with a damaged cord or plug, or after

the appliance malfunctions or has been damaged in any manner.

Do not let the cord hang over the edge of the table or counter.

Do not use this Pressure Cooker on or near a hot plate. Do not position it

under hanging kitchen cabinets as steam from the pressure release may

cause damage.

Always check the silicone sealing ring is correctly positioned before use.

Before placing the removable cooking pot into the unit ensure the

pot base and the internal heating plate are clean and free of any

food debris.

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Important Safety Instructions

10. Do not place food or liquid directly into the base of the unit. Only the

removable cooking pot is designed to contain food or liquid.

11. Never obstruct the pressure release valve.

12. Always check the pressure release valve to ensure it is not clogged

before use.

13. NEVER ATTEMPT TO OPEN THE LID WHEN THE UNIT IS UNDER PRESSURE.

Do not open the unit until the pressure has been released. If the lid is

difﬁcult to rotate do not force it, the unit is still under pressure and it can

be hazardous if forced. See Instructions for Use in the step-by-step guide.

14. Never operate the Pressure Cooker without food or liquid in the removable

cooking pot. Do not ﬁll the pot over 4/5 full.When cooking foods that

expand or foam such as dried vegetables, legumes, beans and grains

do not ﬁll the pot over ½ full. If overﬁlling occurs it may block the pressure

release valve and cause a build-up of pressure.

15. This Pressure Cooker cooks under pressure, improper use may result in

scalding. Follow the Instructions for Use on page 9 and make sure the lid

is closed properly before operating.

16. Be aware that certain foods can foam, froth and splutter which can block

the pressure release valve, these foods include apple sauce, cranberries,

pearl barley, oatmeal and other cereals, noodles, pasta and rhubarb.

Extra care should be taken when cooking anything containing these.

17. Do not touch the pressure release valve when in use. Only turn to release

the pressure after the unit has ﬁnished cooking.

18. Ensure there is sufﬁcient water in the removable cooking pot when

steaming; it should reach the minimum mark at least.

19. Do not use the Pressure Cooker for Deep Frying.

20. Do not use metal utensils as they will scratch the premium non-stick

coating on the removable cooking pot. Use the heat resistant plastic

utensils provided or use a wooden spoon.

21. To protect against electric shock, do not immerse the Pressure Cooker,

base unit, power cord or plug into water or any other liquid.

Do not use the appliance for other than its intended use, this is for

HOUSEHOLD USE ONLY.

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Electrical Safety

WARNINGS!

Read these instructions thoroughly before using this appliance

or connecting it to the mains supply.

This appliance must be grounded.

There are no user-serviceable parts inside this appliance. Always refer

servicing to qualif ed service personnel.The m ains lead of this product is not

replaceable by the user. If the mains lead is damaged, the entire appliance

should be returned to the place of purchase.

Do not allow this product to be exposed to rain or moisture during use

or storage.

Before switching on, make sure that the voltage of your electricity supply is the

same as that indicated on the product rating plate. Connecting it to any other

power source may cause damage.

This product may be f tted with a non-rewireable plug. If it is necessary

to change the fuse in the plug, the fuse cover must be ref tted. If the fuse

cover becomes loose or damaged, the plug must not be used until a suitable

replacement is obtained.

If the plug has to be changed because it is not suitable for your socket,

or due to damage, it should be cut off and a replacement f tted, following

the wiring instructions shown.

The old plug must be disposed of safely because inserting it into a 13 amp

socket could cause an electrical hazard.

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Parts List

Lid

4 3

Lid Handle

Pressure Release Valve

Pressure Safety Valve

Clear Silicone

Sealing Ring

Inner Steel Plate with Silicone

Washer and Metal Peg

Removable Cooking Pot

Upper Ring

Handles (with rest)

Condensation Collector

Outer Body

Heating Plate (inside)

Base

Control Panel

Power Cord

Rice Spoon

Measuring Cup

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Parts List (Cont.)

Pressure Safety Valve

Control Panel

Floating Valve with Sealing Ring

Pressure Release Valve Cover

Centre Post

Timer/ preset + functions

LED Display

Keep Warm/Cancel - functions

Rice

Porridge

Meat

21 20

Chicken

Tenderise/Beans

Soup

Fish

Steam

Fast Cooking

Long Cooking

Tenderise

/Beans

Rice

Porridge

Meat

Soup

Fish

Timer

Keep Warm

/Cancel

/Preset

Fast

Cooking

Chicken

Steam

Long

Cooking

Helpline No. UK/Northern Ireland 0345 467 6743

Web Support: customerservice@sensiohome.com

Rep. Ireland 07688 886 262

Model Number: KY-318

Getting Started

Before First Use

•

Before first use,remove all promotional labels and packaging materials.

•

Remove the lid by turning the handle clockwise and lifting the lid up and

off the appliance.

•

Remove the inner cooking pot and wash in hot soapy water.

Rinse and dry thoroughly.

To clean the sealing ring assembly on the lid remove the inner steel plate

from the inside the lid by pulling on the metal peg.Remove the silicone

rubber seal from around the steel plate and wash everything in hot

soapy water.Rinse and dry thoroughly.

•

Wipe the inside of the base and heating plate with a soft damp cloth

and dry everything thoroughly.

Reassemble the clean and dry silicone

rubber seal onto the steel plate and push

it onto the centre post on the underside

of the lid. MAKE SURE THE METAL PEG ON

THE INNER STEEL PLATE FACES OUT.

•

Replace the cooking pot back into

the base ensuring it sits f at on the

temperature sensor to ensure

correct contact.

N.B. DO NOT SUBMERGE THE BASE UNIT IN

WATER OR ANY OTHER LIQUID THIS IS TO

PREVENT AN ELECTRIC SHOCK.

WARNING: If the silicone rubber seal is not

fitted correctly onto the lid this will prevent

the lid from closing properly and will stop

the Pressure Cooker from operating

normally.

fig. 1

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Instructions for Use

Your Pressure Cooker allows you at the touch of a button to create

delicious meals in a fraction of the time it would take on the stove top or in

a slow cooker.The pre-programmed settings mean that you don’t have to

adjust time or pressure levels as the unit does it all for you.This type of cooking

is one pot cooking,instead of using lots of pots and pans,all preparation can be

carried out in one pot,you can brown meat and caramelise vegetables,

this not only easier but saves on the washing up!

Sautéing and Searing

It is possible to sauté vegetables or sear meat prior to cooking.Although this is

not strictly necessary and make take a little longer, the end results are often

better as browning meat and caramelising vegetables seals in moisture and

adds a great deal of f avour to the f nished meal.

Insert the power cord into the Pressure Cooker base and insert the plug

into the socket.A single beep will sound and 0000 will be displayed.

Insert the condensation collector onto the side

of the unit and secure into place.

fig. 2

Always make sure that the lid is removed from

the Pressure Cooker before sautéing or

searing,and remains off.

Press the Long Cooking function button,

the LED will now show P58

The unit will now begin to heat up.

Add a small amount of oil or butter to the

cooking pot.Take care when food is added

as hot oil may splatter.

Tenderise

Rice

Porridge

Meat

0P58

/Beans

Place food to be sautéed/seared into the

cooking pot,if cooking a large batch of

meat,this should be done in small batches.

Make sure you stir food with heat resistant,

non-scratch utensils.

Soup

Timer

/Preset

Keep Warm

/Cancel

Fish

The thermostat inside the unit will click on and

off during cooking to maintain temperature this

is normal.

Fast

Cooking

Chicken

Steam

Long

Cooking

When finished sautéing or searing,press the

cancel button.

Fig. 3 3

Helpline No. UK/Northern Ireland 0345 467

6743

Web Support:

customerservice@sensiohome.com

Rep. Ireland 07688 886

262

Model Number: KY-

318

Instructions for Use (Cont.)

Pressure Cooker Settings

Fig. 4

By cooking under pressure it raises the temperature of the

liquid and steam inside to well above boiling point and

results in food being cooked up to 70% faster.This method

of cooking retains more vitamins and minerals and natural

flavours are enhanced. It also means that less energy

is used because cook times are so quick saving you both

time and money.

Minimum

1/5 full

Place the removable cooking pot into the base unit.

Maximum

4/5 full

Ensure the lid is assembled and the clear silicone

sealing ring is in place (see fig.1).

Insert the Condensation Collector on the side of the

unit (see fig.2).This will collect any steam or water that

collects around the edge of the unit.

Maximum

USING FOOD

Make sure that amount of food and liquid combined

reaches the 1/5 mark on the inside of the cooking pot,

but never more than the 4/5 mark on

WHEN

THAT

WILL

EXPAND

3/5 full

the cooking pot (see fig.4).

fig. 5

When cooking food that expands

such as rice,dried beans,grains

and legumes do not f ll more than

the 3/5 mark on the cooking pot

(see fig.4).

Close and lock the lid by using

the handle,close the lid in an

anti-clockwise direction by aligning

the ARROWS.The lid should be

aligned with the handles.

fig. 6

This should be effortless (see fig.5).

Make sure the pressure release

valve is in the correct position by

aligning up the pressure symbol

with the arrow (see fig.6).

Helpline No. UK/Northern Ireland 0345 467 6743

Web Support: customerservice@sensiohome.com

Rep. Ireland 07688 886 262

Model Number: KY-318

Indice

Altri manuali NUTRICHEF Elettrodomestico da cucina

NUTRICHEF

NUTRICHEF PKNESPRESO65 Manuale utente

NUTRICHEF

NUTRICHEF NCIM30 Manuale utente

NUTRICHEF

NUTRICHEF PKMFR14 Manuale utente

NUTRICHEF

NUTRICHEF NCPIZOVN Manuale utente

NUTRICHEF

NUTRICHEF PKOPR15 Manuale utente

NUTRICHEF

NUTRICHEF PKPC235BK Manuale utente

NUTRICHEF

NUTRICHEF PKBRTP50 Manuale utente

NUTRICHEF

NUTRICHEF PKBRTP299 Manuale utente

NUTRICHEF

NUTRICHEF PKFD16 Manuale utente

NUTRICHEF

NUTRICHEF PKVS40BK Manuale utente

NUTRICHEF

NUTRICHEF NCFD20S Manuale utente

NUTRICHEF

NUTRICHEF PKCWC120 Manuale utente

NUTRICHEF

NUTRICHEF PKPZM12 Manuale utente

NUTRICHEF

NUTRICHEF PKBRTP60 Manuale utente

NUTRICHEF

NUTRICHEF PCRM12 Manuale utente

NUTRICHEF

NUTRICHEF PKCHMT17 Manuale utente

NUTRICHEF

NUTRICHEF PKFG16 Manuale utente

NUTRICHEF

NUTRICHEF NCDH6S Manuale utente

NUTRICHEF

NUTRICHEF PKBRTP99 Manuale utente

NUTRICHEF

NUTRICHEF PKVS15BK Manuale utente

NUTRICHEF

NUTRICHEF PSLWPMP50 Manuale utente

NUTRICHEF

NUTRICHEF PKWTR15 Manuale utente

NUTRICHEF

NUTRICHEF PKFDSRC10WT Manuale utente

NUTRICHEF

NUTRICHEF PKFD18WT Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
