OKLIFE PKL6063 Manuale utente

This manual contains information regarding the safety and operation of this product. Before you use, read and understand all

instructions, cautions and important safeguards. Failure to do so can result in serious injury or damage or product Page 1

OKL6063 INSTRUCTION MANUAL Page 2

INTRODUCTION

Oklife OKL6063 is a powerful Stainless Steel Juice Extractor with intelligent variable 9 Speed LCD Display

Control for efficient juice extraction of both hard and soft fruits.

OKL6063 TECHNICAL PARAMETER

Voltage: AC 120V, 60Hz

Motor Power: 800 Watts

Juice Mug size: 1 Quart

Feed chute: 3 inch diameter

UNPACKING THE UNIT

Remove the packing material carefully; your Juice extractor comes partially assembled in the packaging

box. Before using your juice extractor take out all the detachable parts and wash them in water to

remove dust and residue. Consult the cleaning section of the manual for proper cleaning instruction.

Remove and save all literature

Always place your juice extractor on a dry and level surface

OKL6063 INSTRUCTION MANUAL Page 3

JUICE EXTRACTOR NAMES AND PARTS

No.

Names and Parts

Food Pusher

Transparent cover

Juicer blade

Middle body

Transmitter

Locker

Main Body

Switch

Juice Mug

Residue Mug

IMPORTANT SAFEGUARDS WHEN USING ELECTRICAL APPLIANCES

1. READ ALL INSTRUCTIONS before using your OKLIFE Stainless Steel Juice Extractor

2. Always use juice extractor on a dry & level surface.

3. Do not let cord hang over edge of table or touch hot surfaces or become knotted.

4. Do not place on or near a hot gas or electric burner or any hot surface.

5. Close supervision is necessary when the appliance is operated near children. Do not allow children to use this

appliance.

6. Handle the appliance carefully; if the unit is dropped or bumped, it may cause the unit to malfunction.

7. To protect against electric shock, do not immerse cord, plug the main body/ motor base in water or other liquid.

OKL6063 INSTRUCTION MANUAL Page 4

8. Do not operate this appliance with a damaged cord or plug. If appliance malfunctions or has been damaged in any

manner, return the appliance to our service center for examination by calling the toll-free number on the cover of

this manual.

9. Always leave the appliance unplugged when not in use or during assembling.

10. Connect the appliance only to properly wired wall outlet; never connect to a loose AC wall outlet.

11. Only use recommended accessory attachments from the appliance manufacturer to avoid fire, electric shock or

injury to persons

12. Assemble all parts properly and completely before using machine. The unit will not turn on if it is not properly

assembled

13. Do not put your hands or any other object into food opening while the juicer is in operation.

14. Do not touch the small cutting blades in the base of the stainless steel filter basket.

15. This unit is suitable for juicing fruit (such as apple) and vegetable.

16. This product is for household use only

17. Do not use outdoors.

ADDITIONAL SAFEGUARDS

This appliance should always be operated on stable place and flat level place and according to the instruction

manual

This appliance comes with a safety protective switch; if the unit is not installed properly per instruction, the

appliance will not work

The appliance also comes with a thermal protective device against high temperature which will shut the device

down when the motor temperature is too high. The thermal protective device preserves your unit and prolongs

the life span and longevity of this unit. Power on the unit when the unit has cooled down in about 10 to 15

minutes.

Do not operate with damaged power cord, if the power cord is damaged, call your electrician or the toll free

number on the front cover of the manual.

Do not put your hand into the feed chute when operating the appliance

Always shut down the power before cleaning the residue mug

For effective juicing, slowly and gently press down the food pusher while juicing

ASSEMBLING INSTRUCTIONS FOR YOUR JUICE EXTRACTOR

CAUTION

MAKE SURE JUICE EXTRACTOR IS UNPLUGGED BEFORE STARTING TO ASSEMBLE

FOLLOW THE STEPS BELOW TO ASSEMBLE YOUR JUICE EXTRACTOR

Step 1

OKL6063 INSTRUCTION MANUAL Page 5

Place the Middle Body onto the Main Body and secure firmly.

Step 2

Set the Juicer Blade into the Transmitter and press to tighten

Step 3

Place the Transparent Cover onto the Middle Body and push down the locker into locking position.

The unit will not work if this step is not properly placed and locked.

Step 4

Slide the Residue Mug under the Middle Body residue spout.

Place Juice Mug under the Middle Body juice spout

Step 5

Connect the plug to the electrical wall unit and turn the Switch on, the motor starts to run and ready for

juicing.

Step 6

Insert fruits and vegetables into the open feed chute on the Transparent Cover.

Gently slide the Food pusher down the feed chute

CAUTION

Do not put your hands or any other objects into the feed chute when operating the unit

For effective juicing, slowly and gently press down the food pusher through the feed chute

NOTE

The Juice Extractor will not work until the Top lid of the Pulp Container is LOCKED properly

CARE AND CLEANING

For easy care, immediately after use, rinse each of the removable parts in warm water and allow parts to air dry

Removable parts to be rinsed: Food pusher, transparent cover, juicer blade, middle body, juice mug, residue

mug, and blade combination

Do not immerse the Main Body in water, only wipe with damp cloth.

For easy cleaning, we suggest you place a small plastic bag into the Residue Mug to collect residue.

CAUTION

Do not rinse or immerse the Main Body in water or any other liquid

Turn off the power before cleaning the residue mug

OKL6063 INSTRUCTION MANUAL Page 6

CAUTION

1. To have the best extracting effort and prolong the lifespan of the unit, please clean the

pulp container, filter and blade after extracting one cup of juice

2. To remove the stainless steel micromesh filter blade from the juicer after juicing, lift

the Middle Body upwards from the Main Body. The blade should come off easily

afterwards.

3. To prolong the lifespan of your unit, do not run the motor continuously for more than

three minutes

OKL6063 INSTRUCTION MANUAL Page 7

PROBLEM SOLVING

PROBLEM

LIKELY PROBLEM

SOLUTION

Unit will not work

Safety switch not connected or broken

Reassemble the machine to make

sure every part is locked well

Motor emits smoky smell when

juicing

Ran motor too long, motor overheat

Stop and let motor rest

Motor appears to stop when

juicing

Power is off, the fruit is probably too

hard to extract, or the fuse is burnt

because it ran too long

Recheck the power, remove hard

fruit and try with a softer fruit. If

it fails to work, return unit to

customer service center

Excess pulp building in the filter

basket

The pulp container maybe full

Clear the pulp container

Pulp too wet and insufficient

Fruit pushed too fast when juicing

Do not push fruit too fast

FREQUENTLY ASKED QUESTIONS

QUESTION: WHAT ARE THE KEY FEATURES OF OKLIFE OKL6063 9 SPEED STAINLESS STEEL JUICE EXTRACTOR?

ANSWER:

Oklife OKL6063 9 Speed Stainless Steel Juice Extractor juicer which uses high quality stainless steel blades with micro

mesh sieve to separate the juice from the solid part, the pulp. Oklife juice extractor is an electric juicer, which requires

less effort and it's an easy method of getting healthy fresh fruit and vegetable intake in just seconds. Oklife Juicer's

variable 9 speeds LCD display control gives you the flexibility and capability to select the desired speeds for juicing soft

fruits (speed levels 1 to 3), medium hard fruits (speed levels 3 to 7) and hard fruits (speed levels 8 to 9). The juice

extractor's powerful 800 watts motor allows for an exceptional high juice extraction rate. The juice extractor's wide feed

chute allows for easy insertion of whole fruits or multiple carrots at a time; thereby reducing juicing time and increasing

efficiency. Oklife Juicer is very easy to clean. It comes with a 2-year limited warranty.

QUESTION: WHAT ARE THE BENEFITS OF THE SPEED LEVELS?

ANSWER:

Okl6063 variable 9 - Speed LCD display control gives you the flexibility and capability to select the desired speeds for

juicing soft fruits and veggies (speed levels 1 to 3), medium hard fruits (speed levels 3 to 7) and hard fruits (speed levels

OKL6063 INSTRUCTION MANUAL Page 8

8 to 9). This feature allows for high juice extraction. Check out the speed level guide on most fruits and vegetables in the

instruction manual.

QUESTION: CAN I JUICE GREENS SUCH AS KALE, CILANTRO AND WHEATGRASS IN MY OKLIFE JUICER?

ANSWER:

YES. For best results, roll up or bunch up these greens and insert in your Oklife Juicer; you can then add any juicy fruits

such as pineapple as needed.

QUESTION: WHERE CAN I PURCHASE OKLIFE JUICER?

ANSWER:

Oklife Juicer is sold online through Amazon.com, Sears.com and shopoklife.com. Ordering is simple. Visit

www.oklifestore.com to take you to our online order center or contact our Customer Service line 866 936 9444 for all

inquiries.

QUESTION: DOES OKLIFE JUICER HAVE A LIMITED WARRANTY, RETURNS AND REPLACEMENT POLICY?

ANSWER:

Oklife OKL6063 9 Speed Stainless Steel Juice Extractor is warranted to be free of defects from workmanship and

materials for the period of two years from the date of original purchase. Should any trouble develop during the period of

two years, please call our customer service number 866 936 9444 for guidance. All warranty service and replacement

requires the original receipt as proof of the date of sale with original purchaser name.

TIPS ON TROUBLESHOOTING OKLIFE JUICER

QUESTION: MY OKLIFE JUICER WILL NOT TURN ON?

ANSWER:

1. Check and make sure the safety switch is connected and snapped into place.

2. Reassemble the machine to make sure every part is locked well.

3. Please call customer service or send a message to us through contact us page on our website if you were unable

to resolve the problem

QUESTION: WHY IS EXCESS PULP BUILDING IN THE FILTER BASKET?

ANSWER:

1. The pulp container maybe full.

2. Clean the pulp container to remove excess pulp

QUESTION: WHY IS THE PULP TOO WET AND INSUFFICIENT

ANSWER:

1. Fruit may have been pushed too fast when juicing or the wrong speed may have been used when juicing.

2. Oklife Juicer has 9 speed LCD control which gives you the flexibility and capability to select the desired speed for

juicing soft fruits and veggies (speed levels 1 to 3), medium hard fruits and veggies(speed levels 3 to 7) and hard

fruits and veggies (speed levels 8 to 9).

3. Also, try not to push fruit or vegetable too fast.

QUESTION: CAN I WASH ALL OKLIFE JUICER PARTS IN THE DISHWASHER?

ANSWER:

OKL6063 INSTRUCTION MANUAL Page 9

1. All Removable parts such as the Food pusher, transparent cover, juicer blade, middle body, juice mug, residue

mug, and blade combination can be rinsed in water and are dishwasher safe (avoid using extremely high heat

on your dishwasher washing circle).

2. The only part that cannot be rinsed in water is the MAIN BODY which houses the motor; only wipe with damp

cloth.

QUESTION: WHAT IS THE SIZE OF THE FEED CHUTE?

ANSWER:

1. The feed chute is almost 3 inches wide in diameter and can take a whole apple or several carrots.

2. When juicing carrots, always be mindful of over stuffing the chute; use the food pusher when juicing carrots for

best juicing experience.

QUESTION: HOW DO I REMOVE THE MICROMESH FILTER BLADE FROM THE JUICER AFTER JUICING?

ANSWER:

The stainless steel micromesh filter blade sits right on top of the stainless steel middle body. The most efficient way to

remove the micromesh blade is by lifting the middle body upwards from the main body. The blade should come off

easily afterwards.

QUESTION: I NOTICED THAT THERE IS WATER INSIDE THE FOOD PUSHER WHEN I WASH IT IN THE DISHWASHER, HOW

DO I REMOVE THE WATER?

ANSWER:

The food pusher has a top cover. If you feel there is water inside the food pusher, open the lid right on top of the food

pusher. The water should come off.

QUESTION: WHY DOES JUICE COME OUT BETWEEN THE PULP CONTAINER AND THE COVER SOMETIMES WHEN I JUICE?

ANSWER:

1. OKL6063 Juicer comes with 9 variable speeds to address this issue. Soft fruits with high water content should be

juiced using lower speed levels, while hard fruits should be juiced using high speed levels. Check out the speed

level guide on most fruits and vegetables in the instruction manual.

2. You can also line the pulp container with a small plastic trash bag for easy cleaning.

3. If none of these solutions help, call customer support at 866-936-9444.

JUICING RECIPES

To get you started using your Juice Extractor; we have included delicious juicing recipes for your

delight. Enjoy!

Grapefruit Delight

2 or 3 apples

½ grapefruit

Remove the peel of the grapefruit but leave as much

Orange Lime

¼ to ½ lime

1 orange

Peel the orange but leave the white membrane to get

OKL6063 INSTRUCTION MANUAL Page 10

of the white membrane as possible. The white

membrane contains bioflavonoids. Remove the seeds

of the apple before juicing.

the bioflavonoids. You can juice the peel of the lime.

You can also juice the seeds

Sweet Cherry

1 large handful of pitted cherries

1 apple

2 slices of pineapple

Remove the seeds of the apple before juicing. If the

pineapple is organic, you can juice the rind for added

nutrition and flavor. If the cherries are organic, you

can also juice the cherry stems.

Grape Taste

1 bunch of grapes

4 to 6 strawberries

1 apple

Remove the seeds from the apple. Juice the stems of

the grapes if organic. If not, discard the stems.

Kiwi Surprise

2 to 3 kiwis

1 orange

Strawberries to taste

Peel the orange while leaving as much white

membrane on as possible. The white membrane

contains bioflavonoids. This drink is rich in vitamin C.

Papaya Magic

1 medium size papaya

1 apple

2 kiwis

Remove the seeds of the papaya before juicing as the

seeds can be bitter tasting. Remove the seeds of the

apple before juicing.

Pineapple

½ pineapple

If the pineapple is organic, then you can juice the

rind. If the pineapple isn't organic, then do not juice

the rind.

The rind contains a lot of beneficial nutrition including

the digestive enzyme known as "bromelain".

Sweet and Sour

¼ to ½ grapefruit

1 to 2 apples

Peel the grapefruit but leave the white membrane to

get the bioflavonoids. Remove the seeds of the apple.

Honey I’m Home

½ honeydew melon

If organic, juice the rind as well for extra nutrition and

flavor. You can also juice the seeds.

Pear Lemon

1 pear

¼ to ½ lemon

Juice the peel of the lemon for extra nutrition and

flavor. You can juice the seeds too.

Orange Juice

3 oranges

Pineberry

¼ to ½ pineapple

Add strawberries until desired taste is

Indice

Altri manuali OKLIFE Elettrodomestico da cucina

OKLIFE

OKLIFE OKL8890 Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
