Panasonic JS-950 Series Manuale utente

POS Workstation

User’s Manual

Model No. JS-950 Series

ontents

For USA / For CANADA / For EU / For

Russia / For Taiwan / For Korea

English

Read Me First …..………….. 6

1.Getting Started …….……..

2.Operation ……………….…

3.Appendix …………………..

Deutsch

Einführung ……….……….. 31

1.Vorbereitung ……………..

2.Betrieb …………………....

3.Anhang ……………….…..

Français

Lisez-moi d'abord …..…….. 57

1. Pour commencer ………..

2. Opération …………….…

3. Annexe …………………..

Español

Lea esto primero …..…….. 82

1. Operaciones iniciales …..

2. Operación …………….…

3. Apéndice ………………..

Русско

Сначала прочитайте …. 107

1. Начало работы …….……..

2. Эксплуатация ………….…

3. Приложение ……………..

한국어

먼저 읽어 주십시오 ….... 134

1. 시작하기 …….……..

2. 조작 ……………….…

3. 부록 …………………..

臺灣

使用前須知 …..……….. 159

1. 開始使用 …….……..

2. 操作 ……………….…

3. 附錄 …………………..

■For USA

For USA

Federal Communications Commission Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.

This equipment generates, uses and can radiate radio frequency energy and, If not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own

expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

Mercury caution

This product has a fluorescent lamp that contains mercury. Dispose may be regulated in your

community due to environmental considerations. For disposal or recycling information, please

contact your local authorities, or the Electronic Industries Alliance:

http://www.eiae.org

Ce produit possede une lampe fluorescente contenant du mercure. Ceci est a mettre au rebut

selon la regulation locale dans votre communaute en raison des considerations a prendre pour

la protection de l'environnement. Pour obtenir les informations relatives a la mise au rebut ou au

recyclage, veuillez prendre contact avec les autorites locales ou Electronic Industries Alliance:

http://www.eiae.org

Battery

This product contains a CR Coin Cell Lithium Battery which contains Perchlorate

Material-special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/Perchlorate.

■For CANADA

■For EU

For EU

This is a class A product. In a domestic environment, this product may cause radio interference

in which case the user may be required to take adequate measures.

Importer’s name and address to follow EU rules:

Panasonic Testing Centre

Panasonic Service Europe, a division of

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, F. R. Germany

■For Russia

For CANADA

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

■For Korea

제품 추가 정보

1. 모델명칭(Model) : JS-950WS

2. 인증번호(Safety Approval No.) : XXXXXXXXXX

3. 제조날짜(Manufacturing Date) :

본체 밑면의 시리얼 번호를 참조하시기 바랍니다.(Please check S/N.)

yymXXXXXX

yy: 년도 표시(yy means year) (2007=07, 2008=086,…….)

m: 월 표시(m means month)

A: 1 월 B: 2 월 C: 3 월 D: 4 월 E: 5 월 F: 6 월

H: 7 월 J: 8 월 K: 9 월 L: 10 월 M: 11 월 N: 12 월

4. 인증 받은 자의 상호 : Panasonic Korea Ltd.

5. 제조자 및 제조국 : Matsushita Electric Industrial Co., Ltd / 일본

주의사항

Class A 급(산업용) 기기입니다.

본 제품은 산업용 전자파적합 등록 기기입니다. 본 기기를 산업용 용도 외

다른 목적으로 판매 또는 구매 시, 가정용 용도에 맞게 변경해 주시기 바랍니다.

■For Taiwan

甲類

此設備經測試證明符號BSMI（經濟部標準檢驗局）之甲類數位裝置的限制規定。這些限制的目

的是為了在商業環境中使用此設備時，能提供合理的保護以防止有害的干擾。此設備會產生、使

用並散發射頻能量：如果未導照製造廠商的指導手冊來安裝和使用，可能會干擾無線電通訊。請

勿在住宅區使用此設備。

警告使用者：

這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，

在這種情況下，使用者會被要求采取某些適當的對策。

安全：電池處理

警告：新電池安裝不正解會有爆炸的危險。更換電池時，請僅使用相同或製造商建議的同

等類型電池。請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機構以獲取有關最近的

廢棄電池存放站的地址。

您的電腦使用鋰幣電池。鋰幣電池為長效用電池，很有可能您永遠都不需要更換它。然而，

如果確實需要更換，請參閱您的電腦說明文件。

請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機構以獲取有關最近的廢棄電

池存放站的地址。

安全：電池聲明（台灣）

廢電池請回收

English

Read Me First

Introduction

Thank you for purchasing the JS-950 series Panasonic POS Workstation.

This manual describes the instructions for the POS Workstation.

Please read this manual carefully before using this product.

List of JS-950 series Product

Name Model NO. Remarks

Main Block POS Workstation JS-950WS-040 CPU:3.2GHz,Memory:512MB

Touch Display Unit JS-950D2R010 12” resistive Touch screen

Touch Display Unit JS-950D2C010 12” capacitive Touch screen

Touch Display Unit JS-950D5R010 15” resistive Touch screen

Display

Block

Touch Display Unit JS-950D5C010 15” capacitive Touch screen

Storage module Unit JS-950H35010 3.5HDD module

Storage module Unit JS-950H25010 2.5HDD module

Storage module Unit JS-950H2C010 2.5HDD with CF module

Storage

Block

Storage module Unit JS-950HCF010 Dual CF module

MSR Unit JS-950MG-010 Magnetic strip reader module

Dallas Key Reader Unit JS-950DP-010 Dallas KEY Reader module

ID module

Block Fingerprint Sensor Unit JS-950FS-010 Fingerprint Sensor module

Rear Display Unit JS-950RD-010 Rear Display module 2line

Rear Display Unit JS-950RD-020 Rear Display module 4line

Rear

Display

Block 2nd Display Unit JS-950SD-010 2nd Display module 8.4” resistive TP

AC cord kit JS-950KT-W10 AC cord kit W

AC cord kit JS-950KT-UM0 AC cord kit UM

AC cord kit JS-950KT-UH0 AC cord kit UH

AC cord kit JS-950KT-E10 AC cord kit E

AC cord kit JS-950KT-F10 AC cord kit F

AC cord kit JS-950KT-A10 AC cord kit A

AC cord kit JS-950KT-Z10 AC cord kit Z

AC cord kit JS-950KT-J10 AC cord kit J

AC cord kit JS-950KT-H10 AC cord kit H

AC cord Kit

AC cord kit JS-950KT-K10 AC cord kit K

1. Getting Started

■Precautions

[ POS Workstation: JS-950 series ]

IMPORTANT

Install a socket outlet adjacent to the equipment so that it will be easily

accessible.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

1. Avoid Radio Frequency Interference

Do not place the POS Workstation near a television or radio receiver.

2. Avoid Stacking

Do not place heavy objects on the POS Workstation.

3. Keep Small Objects Away

Do not insert paper clips or other small objects into POS Workstation.

There is the risk of heat, fire or explosion.

4. Keep Dry

There is the risk of heat, fire or explosion.

5. Do Not Disassemble the POS Workstation

Do not attempt to disassemble the POS Workstation. There is the risk of heat, fire

or explosion.

6. Do Not Touch the Plug with Wet Hands.

There is the risk of electric shock.

7. Be Certain to Plug Fully Into the Outlet.

There is the risk of electric shock or fire.

8. When Unplugging, Make Sure to Hold the Body of the Plug.

If the power strip is damaged, there is a risk of electric shock, short circuit or fire.

9. Do Not Use a Damaged Power-code or Plug.

There is the risk of electric shock or fire.

10. Clean the Dust off the Plug, Periodically.

There is the risk of heat or fire.

11. Be Certain to Plug Fully Into the Outlet.

There is the risk of electric shock or fire.

12. When Unplugging, Make Sure to Hold the Body of the Plug .

If the power strip is damaged, there is a risk of electric shock, short circuit or fire.

13. Do not use the POS Workstation outdoors.

This product assumes the indoor use. There is the risk of breakdown.

14. Do not put the POS Workstation on a slope and an unstable place.

It causes the injury by falling.

<NOTE>

Do not open the Rear cover and Filter cover while the POS Workstation is operating.

■Name of each part & function
